protech ProX-1215 User Manual

Half-size cpu board with vga / lan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
Prox-1215 M3
ProX-1215
VIA EDEN Half-size
Embedded Card
With VGA/LAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProX-1215 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech ProX-1215

Summary of Contents for protech ProX-1215

  • Page 1 USER’S MANUAL ProX-1215 VIA EDEN Half-size Embedded Card With VGA/LAN Prox-1215 M3...
  • Page 2 Copyright Notice Prox-1215 Half-size CPU Board With VGA / LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end-users in installing and setting up the system. The information contained in this document is subject to change without any prior notice.
  • Page 3 Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specifications ........... Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ........... How to Set the Jumpers ..........COM Port Connector ............ RS232/422/485 (COM2) Selection .......
  • Page 5 Contents 2-30 Solid-State Disk Socket …..........2-21 2-31 SSD Memory Mapping Selection ……………………. 2-22 2-32 LVDS LCD Connector ………………………………. 2-23 2-33 LVDS Panel Power Selection ……………………… 2-24 CHAPTER 3 SOFTWARE UTILITIES Introduction …............... VIA 4 IN 1 Service Pack Driver ……………………. VGA Driver Utility …...........
  • Page 6 Contents APPENDIX B TECHNICAL SUMMARY Block Diagram ................. Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O & Memory Map ..............APPENDIX C TROUBLESHOOTING Troubleshooting for Error Messages ........Troubleshooting for POST Code ..........
  • Page 7 Contents...

  • Page 8: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for Prox-1215. It also outlines the System specifications. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for a Quick Start. Page:1-1...

  • Page 9: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our Prox-1215, Half Size CPU Board enhanced with VGA/LAN, is fully PC / AT/ATX compatible. The Prox-1215 provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the system.

  • Page 10: System Specifications

    PS/2 keyboard with mini DIN connector or one external 5-pin boxheader connector with mini DIN cable Supports Y-Cable. MOUSE CONNECTOR : PS/2 mouse connector with mini DIN connector when keyboard use external 5-pin connector. BUS SUPPORT : PC/104 Bus External PCI Bus ′ Page: 1-3 Prox-1215 USER S MANUAL...
  • Page 11 Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte FIFOs; COM1 for RS-232; COM2 for RS-232/422/485 COM1 with 9-pin D-SUB connector on board COM2 with one 2x5-pin boxheader connector on board Infrared Communications port option on the COM2. ′ Page: 1-4 Prox-1215 USER S MANUAL...
  • Page 12 82C59 x 2 INTERRUPT LEVELS : OPERATING TEMPERATURE : 0 to 60°C (32°F to 140°F) INPUT POWER REQUIREMENT : AT power: +5V ±5%. +12V ±5%. ATX power: +5VSB ±5%. +5V ±5%. +12V ±5%. ′ Page: 1-5 Prox-1215 USER S MANUAL...

  • Page 13: Safety Precautions

    3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-6 Prox-1215 USER S MANUAL...

  • Page 14: Chapter 2 Hardware Configuration

    HARDWARE CHAPTER CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. This section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector‘s Pin Assignments Page 2-1...

  • Page 15: Jumper & Connector Quick Reference Table

    UTP1 AT Power Connector ..……………...………………… ATX Power Connector ………………………………... AT/ATX Power Selection ..…………………………. Solid-State Disk Socket ……………………………….. SSD Memory Mapping Selection ……………………… LVDS LCD Connector ……………………………… LVDS1 LVDS Panel Power Selection …………………………. JP10 ′ Page: 2-2 Prox-1215 USER S MANUAL...

  • Page 16: Component Locations

    Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS Prox-1215 Connector, Jumper and Component locations ′ Page: 2-3 Prox-1215 USER S MANUAL...

  • Page 17: How To Set The Jumpers

    PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagram looks like and what they represent. ′ Page: 2-4 Prox-1215 USER S MANUAL...
  • Page 18 Chapter 2 Hardware Configuration JUMPER DIAGRAMS JUMPER SETTINGS ′ Page: 2-5 Prox-1215 USER S MANUAL...

  • Page 19: Com Port Connector

    The COM1 Connector assignments are as follows : ASSIGNMENT COM1 RI / +5V / +12V selectable COM2 : COM2 Connector The COM2 Connector assignments are as follows : ASSIGNMENT RS-232 RS-422 RS-485 COM 2 RTS- RTS+ CTS+ RI/+5V/+12 CTS- ′ Page: 2-6 Prox-1215 USER S MANUAL...

  • Page 20: Rs232/422/485 (Com2) Selection

    1-3, 4-6, 7-8, 9-10 11-12, 13-14, 15-16 RS-485 17-18, 19-20 *** Manufactory default --- RS-232. 2-6. KEYBOARD/MOUSE CONNECTOR KB1 : Keyboard/Mouse Connector The jumper settings are as follows: ASSIGNMENT KBDATA MSDATA KBVCC KBCLK MSCLK ′ Page: 2-7 Prox-1215 USER S MANUAL...

  • Page 21: Keyboard/Mouse Selection

    JUMPER SETTING JUMPER TYPE (pin closed) ILLUSTRATION KEYBOARD/Y-Cable PS/2 MOUSE *** Manufactory default -- AT Keyboard 2-8. EXTERNAL KEYBOARD CONNECTOR EXKB1 : External Keyboard Connector. The pin assignments are as follows: ASSIGNMENT KBCLK KBDATA ′ Page: 2-8 Prox-1215 USER S MANUAL...

  • Page 22: Inverter Connector

    PW_LED J1 (1-3) : Power LED Connector The pin assignment is as follows: ASSIGNMENT PW_LED 2-11. RESET CONNECTOR J1 (9-10) : Reset Connector. The pin assignments are as follows : ASSIGNMENT GROUND RESET ′ Page: 2-9 Prox-1215 USER S MANUAL...

  • Page 23: Hard Disk Drive Led Connector

    J1 (5-6) : Power Button for ATX power. The pin assignments are as follows: ASSIGNMENT GROUND PW_BN 2-14. EXTERNAL BUZZER CONNECTOR EXT_BUZ J1 (7-8) : External Buzzer Connector The pin assignments are as follows: ASSIGNMENT E_BUZ ′ Page: 2-10 Prox-1215 USER S MANUAL...

  • Page 24: Fan Connector

    FAN1 : FAN Connector The pin assignments are as follows: FAN1 ASSIGNMENT +12V FAN speed monitor 2-16. IRDA CONNECTOR IR1 : IrDA (SIR) Connector The pin assignments are as follows: ASSIGNMENT IRRX IRTX ′ Page: 2-11 Prox-1215 USER S MANUAL...

  • Page 25: Vga Connector

    Chapter 2 Hardware Configuration 2-17. VGA CONNECTOR VGA1 : VGA Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE I2CCK HSYNC VSYNC I2CDA ′ Page: 2-12 Prox-1215 USER S MANUAL...

  • Page 26: Lcd Connector

    Chapter 2 Hardware Configuration 2-18. LCD CONNECTOR LCD1 : LCD Connector The pin assignments are as follows : ASSIGNMEN ASSIGNMENT LCD_VCC5 LCD_VCC5 FPVS FPDEN FPHS FPCLLK LCD_VCC3 LCD_VCC3 ENABKL ENVDD +12V +12V ′ Page: 2-13 Prox-1215 USER S MANUAL...

  • Page 27: Universal Serial Bus Connector

    USBDT0+ 5V_SB USBDT1− USBDT1+ 2-20. CLEAR CMOS SELECTION JP8 : Clear CMOS Selection The selections are as follows: JUMPER JUMPER SETTING FUNCTION ILLUSTRATION (pin closed) Normal Clear CMOS *** Manufacturing Default – Normal. ′ Page: 2-14 Prox-1215 USER S MANUAL...

  • Page 28: Floppy Disk Drive Connector

    34-pin flat cable to attach the FDD on the board, the other side attaches to two FDDs. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT DRVDEN0 DRVDEN1 INDEX MTR0 DRV1 DRV0 MTR1 STEP WDATA WGATE TRK0 WRPRT RDATA DSKCHG ′ Page: 2-15 Prox-1215 USER S MANUAL...

  • Page 29: Hard Disk Drive Connector

    ASSIGNMENT IDERST PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 DDREQA -DIOWA -DIORA HDRDYA PULL LOW -DDACKA IRQ14 PDA1 PD_80P PDA0 PDA2 -PDCS1 -PDCS3 HDLED1 ′ Page: 2-16 Prox-1215 USER S MANUAL...

  • Page 30: Printer Connector

    As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT AUTFE ERROR INIT SLCTIN BUSY SLCT ′ Page: 2-17 Prox-1215 USER S MANUAL...

  • Page 31: Reset/Nmi/Clear Watchdog Selection

    JUMPER SETTING JUMPER (pin closed) ILLUSTRATION RESET CLEAR WATCHDOG 2-25. IRQ12 RELEASE SELECTION JP5 : IRQ12 Release Selection. The selections are as follows: JUMPER SELECTION JUMPER SETTING ILLUSTRATION IRQ12 Release Open PS/2 Mouse Closed ′ Page: 2-18 Prox-1215 USER S MANUAL...

  • Page 32: Lan Connector

    The pin assignments are as follows: ASSIGNMENT ISOLATED GND ISOLATED GND PULL HI LED-Green (Speed) PULL HI LED-Yellow (Link) 2-27. AT POWER CONNECTOR PW1 : Power Connector The pin assignments are as follows : ASSIGNMENT +12V -12V ′ Page: 2-19 Prox-1215 USER S MANUAL...

  • Page 33: Atx Power Connector

    As a reminder, when you choose to use the ATX function, please be sure to set the corresponding configuration found in BIOS setup such 1. Inside the “POWER MANAGEMENT” setting, set the ACPI function to enable. ′ Page: 2-20 Prox-1215 USER S MANUAL...

  • Page 34: Solid-State Disk Socket

    Chapter 2 Hardware Configuration 2-30. SOLID-STATE DISK SOCKET SSD: 32pin Disk-on-chip Socket The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SA12 SA10 SA11 ′ Page: 2-21 Prox-1215 USER S MANUAL...

  • Page 35: Ssd Memory Mapping Selection

    ROM SSD can be install as one of user’s hard disk drive. The SSD Memory Mapping Selections are as follows: JUMPER SETTING SSD Memory Map JUMPER (pin closed) ILLUSTRATION D0000H-D1FFFH 9-10 D4000H-D5FFFH 11-12 D8000H-D9FFFH 9-10 DC000H-DDFFFH 11-12 *** Manufactory default --- D0000h-D1FFFh. ′ Page: 2-22 Prox-1215 USER S MANUAL...

  • Page 36: Lvds Lcd Connector

    Chapter 2 Hardware Configuration 2-32. LVDS CONNECTOR LVDS1 : LVDS Connector. LVDS1 The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LCD_VCC LCD_VCC LCD_VCC ′ Page: 2-23 Prox-1215 USER S MANUAL...

  • Page 37: Lvds Panel Power Selection

    Chapter 2 Hardware Configuration 2-33. LVDS PANEL POWER SELECTION JP10 : LVDS Panel Power Selection. The selections are as follows: JUMPER SELECTION JUMPER SETTING ILLUSTRATION LVDS_VCC3 LVDS_VCC5 ′ Page: 2-24 Prox-1215 USER S MANUAL...

  • Page 38: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, sound driver, and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility Sound Driver Utility Watchdog Timer Configuration Page: 3-1...

  • Page 39: Introduction

    Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our Prox-1215 package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc, please...

  • Page 40: Flash Bios Update

    Utility Disk for system BIOS and VGA BIOS update. 3-3-2. To update VGA BIOS for LCD Flat Panel Display: As Prox-1215 user, you have to update the VGA BIOS for your specific LCD flat panel you are going to use. For doing this, you need two files.
  • Page 41 File Name to Program: C30bxxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. ′ Page:3-4 Prox-1215 USER S MANUAL...

  • Page 42: Lan Driver Utility

    Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction Prox-1215 Embedded Board is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 95/98/2000/XP program 2. Win NT program 3.
  • Page 43 Last step to select OK and close NETWORK SETUP. Select SKIP if only one adapter is installed on this computer. For more information on installation procedure, please refer to TXT directory found on LAN DRIVER UTILITY. ′ Page:3-6 Prox-1215 USER S MANUAL...
  • Page 44 (5) Change the “Install Driver” directory to the “VIA Audio Driver directory”. Then press “OK” button. (6) If it correct, you will see a pop window, which shows “VIA PCI Audio Controller”. Press “OK” button to process installing. (7) Restart the computer. ′ Page:3-7 Prox-1215 USER S MANUAL...

  • Page 45: Watchdog Timer Configuration

    I/O port 441H, the system will run the command to stop the Watchdog function. In Prox-1215 watchdog function, you must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog.

  • Page 46: Chapter 4 Award Bios Setup

    CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults...

  • Page 47: Introduction

    4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The Prox-1215 half size Embedded Board is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system.

  • Page 48: Entering Setup

    You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 Prox-1215 USER S MANUAL...

  • Page 49: The Standard Cmos Features

    < Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 Prox-1215 USER S MANUAL...
  • Page 50 Auto: The BIOS automatically determines the optimal mode. Normal: Maximum number of cylinders, heads, sectors supported are 1024, 16 and 63. Large: For drives that do not support LBA and have more than 1024 cylinders. ′ Page: 4-5 Prox-1215 USER S MANUAL...
  • Page 51 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 Prox-1215 USER S MANUAL...
  • Page 52 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table ′ Page: 4-7 Prox-1215 USER S MANUAL...

  • Page 53: The Advanced Bios Features

    F7:Optimized Defaults BIOS Features Setup Menu The “BIOS FEATURES SETUP” allow you to configure your system for basic operation. The user can select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. ′ Page: 4-8 Prox-1215 USER S MANUAL...
  • Page 54 You may enable / disable this item to define whether the system will look for a floppy disk drive to boot at power-on, or proceed directly to the hard disk drive. BOOT UP NUMLOCK STATUS: Select power on state for NumLock. ′ Page: 4-9 Prox-1215 USER S MANUAL...
  • Page 55 Setup freely. OS SELECT FOR DRAM >64MB : Select the operating system that is running with greater than 64MB or RAM on the system. You may choose OS2 or Non-OS2. ′ Page: 4-10 Prox-1215 USER S MANUAL...
  • Page 56 Video Shadow will increase the video speed. C8000-CBFFF SHADOW ~ DC000-DFFFF SHADOW: These categories determine whether option ROMs will be copied to RAM. An example of such option ROM would be support of on-board SCSI. ′ Page: 4-11 Prox-1215 USER S MANUAL...

  • Page 57: Advanced Chipset Features

    The parameter allows you to configure the system based on the specific features of the installed chipset. The chipset manages bus speed and access to system memory resources, such as DRAM and the external cache. ′ Page: 4-12 Prox-1215 USER S MANUAL...
  • Page 58 This should be enabled if your system has a USB installed on the system board and you want to use it. Even when so equipped, if you add a higher performance controller, you will need to disable this feature. ′ Page: 4-13 Prox-1215 USER S MANUAL...
  • Page 59 IO CHANNEL CHECK NMI: This field enables or disables IO channel check NMI. Before selecting this function, the user should check first that NMI function is enabled as described in chapter 2 (Reset/NMI/Clear Watchdog Selection). ′ Page: 4-14 Prox-1215 USER S MANUAL...

  • Page 60: Integrated Peripherals

    The onboard IDE drive interfaces supports IDE pre-fetching for faster drive accesses. If you install a primary and or secondary add-in IDE interface, set this field to Disabled if the interface does not support pre-fetching. ′ Page: 4-15 Prox-1215 USER S MANUAL...
  • Page 61 UART 2 MODE: This item allows you to select which mode for the Onboard Serial Port 2. IR FUNCTION DUPLEX: This item allows you to select the IR half/full duplex function. ′ Page: 4-16 Prox-1215 USER S MANUAL...
  • Page 62 ECP MODE USE DMA: Select a DMA channel for the parallel port for use during ECP mode. PARALLEL PORT EPP TYPE: Select EPP port type 1.7 or 1.9 as required by your parallel peripheral. ′ Page: 4-17 Prox-1215 USER S MANUAL...

  • Page 63: Power Management Setup

    Users are allowed to enable or disable the Advanced Configuration and Power Management (ACPI). POWER MANAGEMENT: This item allows the user to select the type or degree of power saving and is directly related to HDD Power Down, Doze Mode and Suspend Mode. ′ Page: 4-18 Prox-1215 USER S MANUAL...
  • Page 64 In effect, the system remains alert for anything that occurs to a device, which is configured as ON, even when the system is in a power down mode. ′ Page: 4-19 Prox-1215 USER S MANUAL...
  • Page 65 When Enabled, you can set the date and the time at which the RTC alarm awakens the system from Suspend mode. PRIMARY INTR: When set to Off, IRQ Activity Monitoring is set to BIOS default. When set to On, user may select the desired setting. ′ Page: 4-20 Prox-1215 USER S MANUAL...

  • Page 66: Pnp/Pci Configuration

    This section covers technical items, which is strongly recommended for experienced users only. PNP OS INSTALLED: This item allows you to determine install PnP OS or not. ′ Page: 4-21 Prox-1215 USER S MANUAL...
  • Page 67 DMA channel. PCI/VGA PALETTE SNOOP: Leave this field at disabled. ASSIGN IRQ FOR USB: Enable or Disable to assign IRQ for USB. ASSIGN IRQ FOR VGA: Enable or Disable to assign IRQ for VGA. ′ Page: 4-22 Prox-1215 USER S MANUAL...

  • Page 68: Pc Health Status

    CURRENT CPU TEMPERATURE: This item shows you the current CPU temperature. CURRENT CPUFAN SPEED: This item shows you the current CPUFAN speed. VCORE: This item shows you the current system voltage. ′ Page: 4-23 Prox-1215 USER S MANUAL...

  • Page 69: Frequency/Voltage Control

    This setup menu allows you to specify your settings for frequency/voltage control. AUTO DETECT DIMM/PCI CLK: This item allows you to enable or disable auto detect DIMM/PCI Clock. SPREAD SPECTRUM: This item allows you to enable or disable the spread spectrum modulate. ′ Page: 4-24 Prox-1215 USER S MANUAL...

  • Page 70: Load Fail-Safe Defaults

    When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-25 Prox-1215 USER S MANUAL...

  • Page 71: Password Setting

    PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-26 Prox-1215 USER S MANUAL...

  • Page 72: Save & Exit Setup

    You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-27 Prox-1215 USER S MANUAL...

  • Page 73: Exit Without Saving

    ►Integrated Peripherals Set Password ►Power Management Setup Quit Without Saving (Y/N)? N ►PnP/PCI Configura Saving ►PC Health Status Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Data ′ Page: 4-28 Prox-1215 USER S MANUAL...

  • Page 74: Appendix A Expansion Bus

    APPENDIX EXPANSION BUS This appendix indicates you the pin assignments. Section includes: PC-104 Connector Pin Assignment PCI BUS Pin Assignment Page: A-1...
  • Page 75 -12V LA19 IRQ15 LA18 IRQ14 +12V LA17 DACK0 IOCHRDY MEMR DRQ0 SMEMW MEMW DACK5 SMEMR DRQ5 DACK6 DRQ6 DACK3 DACK7 DRQ3 DRQ7 DACK1 DRQ1 MASTER REFRESH KEY PIN IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2 BALE Page: A-2 Prox-1215 USER‘S MANUAL...
  • Page 76 AD09 AD31 AD30 AD08 C/BE0# AD29 +3.3V AD07 +3.3V AD28 +3.3V AD06 AD27 AD26 AD05 AD04 AD25 AD03 +3.3V AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +3.3V +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 Prox-1215 USER‘S MANUAL Page: A-3...
  • Page 77 Appendix A Expansion Bus Page: A-4 Prox-1215 USER‘S MANUAL...
  • Page 78 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...
  • Page 79 1 SO-DIMM AND PCI/AGP CNTL MODULES CONTROLLER Floppy LAN1 82C686B K.B./Mouse IDE1 ISA BUS CONTROLLER Parallel Port COM1~2 RJ45 Volt. Sensor Temp. Sensor FLASH IrDA Port Sensor BIOS Watchdog PCI BUS PC104 M-SYSTEM (DISK-ON-CHIP) ′ Page: B-2 Prox-1215 USER S MANUAL...
  • Page 80 Standard 101/102-key or Microsoft Natural PS/2 Keyboard Cascade for IRQ 8-15 Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock ACPI Available Available PS/2 Mouse Numeric data processor IDE1 Available ′ Page: B-3 Prox-1215 USER S MANUAL...
  • Page 81 Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: B-4 Prox-1215 USER S MANUAL...
  • Page 82 System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available / Sound Blaster Floppy Available / ECP Cascade for DMA controller 1 Available Available Available ′ Page: B-5 Prox-1215 USER S MANUAL...
  • Page 83 Direct memory access controller 091-093 Motherboard resources 094-09F Direct memory access controller 0A0-0A1 Programmable interrupt controller 0A2-0BF Motherboard resources 0C0-0DF Direct memory access controller 0E0-0EF Motherboard resources 0F0-0FF Numeric data processor 1F0-1F7 Primary IDE Channel ′ Page: B-6 Prox-1215 USER S MANUAL...
  • Page 84 VIA Bus Master IDE Controller 400-41F VIA Rev 5 or later USB Universal Host Controller 800-81F VIA Rev 5 or later USB Universal Host Controller 800-8FF Realtek RTL8139 Family PCI Fast Ethernet NIC #2 ′ Page: B-7 Prox-1215 USER S MANUAL...
  • Page 85 Appendix B Technical Summary ′ Page: B-8 Prox-1215 USER S MANUAL...
  • Page 86 APPENDIX TROUBLE- SHOOTING This section outlines the error messages that may occur when you operate the system. It also gives you some tips on how to solve the problems. Section includes: Troubleshooting for Error Messages Troubleshooting for POST Code Page: C-1...
  • Page 87 When you can‘t find the boot device, insert a system disk into Drive A and press < Enter >. Make sure both the controller and cables are all in proper positions, also make sure the disk is formatted correct device. Then reboot the system. ′ Page: C-2 Prox-1215 USER S MANUAL...
  • Page 88 Memory has been added or removed since the last boot. In EISA mode use Configuration Utility to re-configure the memory configuration. In ISA mode enter Setup and enter the new memory size in the memory fields. ′ Page: C-3 Prox-1215 USER S MANUAL...
  • Page 89 When this error occurs that requires you to reboot.. Press any key and the system will reboot. SYSTEM HALTED : Indicates the present boot attempt has been aborted and the system must be rebooted. Press and hold down the CTRL and ALT keys and press DEL. ′ Page: C-4 Prox-1215 USER S MANUAL...
  • Page 90 08 : Test the first 256K DRAM. 09 : 1. Program the configuration register of Cyrix CPU according to the MODBINable Cyrix Register Table. 2. OEM specific cache initialization (if needed). ′ Page: C-5 Prox-1215 USER S MANUAL...
  • Page 91 -CPU brand, type & speed. -Test system BIOS checksum (Non-compress Version only). 0F : DMA channel 0 test. 10 : DMA channel 1 test. 11 : DMA page registers test. 14 : Test 8254 Timer 0 Counter2. ′ Page: C-6 Prox-1215 USER S MANUAL...
  • Page 92 MODBINable Auto-Table. 41 : Initialize floppy disk drive controller. 42 : Initialize Hard drive controller. 43 : If it is a PnP BIOS, initialize serial & parallel ports. 45 : Initialize math coprocessor. ′ Page: C-7 Prox-1215 USER S MANUAL...
  • Page 93 Note : if L2 cache is already turned on in POST 3D, this part will be skipped. 2. Set the boot up speed according to Setup setting. 3. Last chance for Chipset initialization. 4. Last chance for Power Management initialization (Green BIOS only). 5. Show the system configuration table. ′ Page: C-8 Prox-1215 USER S MANUAL...
  • Page 94 (PnP BIOS only). 2. Clear memory that have been used. 3. Boot system via INT 19H. FF : System Booting. this means that the BIOS already pass the control right to the operating system. ′ Page: C-9 Prox-1215 USER S MANUAL...
  • Page 95 Appendix C Troubleshooting PRINTED IN TAIWAN ′ Page: C-10 Prox-1215 USER S MANUAL...
