  • Page 1 USER MANUAL BE-0996 3.5” SBC Intel Core i5-7300U / ® i3-7100U / Pentium 4415U Series SoC ® BE-0996 M1...
  • Page 2 BE-0996 ® 3.5” SBC Intel Core i5-7300U / ® i3-7100U / Pentium 4415U Series SoC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Jan. 2019. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Packing List ................2-2 BE-0996 Specifications ............. 2-3 Safety Precautions ..............2-5 Hardware Configuration ..............3-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE ..3-2 COMPONENT LOCATIONS ............. 3-3 3.2.1...
  • Page 5 3.4.8 HD Audio Connector (AUDIO1) ........3-16 3.4.9 ATX Power Input Connector (ATX1) ........ 3-17 3.4.10 Speaker Connectors (SPK_L_OUT1, SPK_R_OUT1) ..3-18 3.4.11 Digital Input / Output Connector (JDIO1) ......3-19 3.4.12 Front Panel Connector (JFP1) ........3-20 3.4.13 CPU Fan Connector (CPU_FAN1) ........3-21 3.4.14 SATA 3.0 Connector (SATA1) ..........
  • Page 6 ® Intel Management Engine Components Installer Installation .. 4-7 ® Installing Intel Serial I/O Driver Utility ........4-8 BIOS SETUP ..................5-1 Introduction ................5-2 Accessing Setup Utility .............. 5-3 Main ................... 5-6 Advanced .................. 5-8 5.4.1 Advanced – CPU Configuration ........5-9 5.4.2 Advanced –...
  • Page 7 Save & Exit ................5-39 Appendix A Technical Summary ..........A-1 BE-0996 Block Diagram ................A-2 Interrupt Map ....................A-3 I/O Map ....................A-14 Memory Map ...................A-16 Configuring WatchDog Timer ..............A-18 Flash BIOS Update .................A-20...

  • Page 8: Revision History

    Revision History The revision history of BE-0996 User Manual is described below: Version No. Revision History Page No. Date Initial Release 2019/01...

  • Page 9: Introduction

    Introduction This chapter provides the introduction for BE-0996 as well as the framework of the user manual. The following topic is included: • About This Manual BE-0996 SERIES USER MANUAL Page: 1-1...

  • Page 10: About This Manual

    It is not intended for general users. The following section outlines the structure of this user manual. Chapter 1 Introduction This chapter provides the introduction for BE-0996 as well as the framework of the user manual. Chapter 2 Getting Started This chapter describes the package contents and outlines BE-0996 specifications.

  • Page 11: Getting Started

    Getting Started This chapter provides the information for BE-0996 motherboard. It describes the package contents and outlines the motherboard specifications. The following topics are included: • Package List • BE-0996 Specification • Safety Precautions Experienced users can go to Chapter 3 Hardware Configuration on page 3-1 for a quick start.

  • Page 12: Packing List

    If you discover any of the items listed below are damaged or list, please contact your local distributor immediately. Item Q’ty BE-0996 Quick Reference Guide Manual / Driver DVD Mini Jumper (2.0 mm) SATA & SATA Power Cable (150mm) BE-0996 SERIES USER MANUAL Page: 2-2...

  • Page 13: Be-0996 Specifications

     1 x full-sized mPCIe slot (with SATA / USB signal) For Pentium SKU:  1 x full-sized mSATA slot (with SATA signal only)  1 x full-sized mPCIe slot (with PCIe / USB signal) only)  1 x I C port C Port BE-0996 SERIES USER MANUAL Page: 2-3...
  • Page 14 Chapter 2 Getting Started Environment Operating Temperature  0°C ~ 60°C (32°F~ 140°F) Storage Temperature  -40°C ~ 80°C (-40°F~ 185°F) Humidity  20%~ 95% BE-0996 SERIES USER MANUAL Page: 2-4...

  • Page 15: Safety Precautions

    Always disconnect power when the system is not in use. Disconnect power source when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. BE-0996 SERIES USER MANUAL Page: 2-5...

  • Page 16: Hardware Configuration

    This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Component Locations • Connector Configuration and Jumper Settings • Connector Pin Assignments BE-0996 SERIES USER MANUAL Page: 3-1...

  • Page 17: Jumper & Connector Quick Reference Table

    SATA1 SATA Power Connector JHDD_PWR1 LVDS Connector JLVDS1 Panel Inverter Connector JINV1 Mini PCI Express Slot M_PCIE1 mSATA Connector M_SATA1 I2C Wafer JI2C1 Battery Wafer JBAT1 SPI Connector DDR4 SO-DIMM Memory Socket 1 DIMM1 BE-0996 SERIES USER MANUAL Page: 3-2...

  • Page 18: Component Locations

    12V/24V WARNING: Always disconnect the power cord when you are working with connectors and jumpers on BE-0996. Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components. Make sure BE-0996 is properly grounded.

  • Page 19: Jumper Setting Of Be-0996Ra-**N

    Pins 3, 6: ON Pins 4, 5: ON 800x600 Channel S/6bit Pins 1, 8: ON Pins 2, 7: ON Pins 3, 6: ON Pins 4, 5: ON 3.3V (default) JLVDS1 ATX1 JFP1 JUSB1 Disable Enable (default) DIMM1 CPU_FAN1 BE-0996 SERIES USER MANUAL Page: 3-4...

  • Page 20: Bottom View Of Be-0996Ra-**N

    Chapter 3 Hardware Configuration 3.2.3 Bottom View of BE-0996RA-**N BE-0996 SERIES USER MANUAL Page: 3-5...

  • Page 21: I/O View Of Be-0996Ra-**N

    Chapter 3 Hardware Configuration 3.2.4 I/O View of BE-0996RA-**N LAN1 LAN2 4 x USB 2.0 Ports 2 x USB 3.0 Ports HDMI BE-0996 SERIES USER MANUAL Page: 3-6...

  • Page 22: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. BE-0996 SERIES USER MANUAL Page: 3-7...
  • Page 23 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this BE-0996 SERIES USER MANUAL Page: 3-8...

  • Page 24: Setting Connectors And Jumpers

    Chapter 3 Hardware Configuration 3.4 Setting Connectors and Jumpers 3.4.1 COM2 Connector Pin9 Definition Selection Guide (JP_COM2) Jumper Location: JP_COM2 Description: COM2 Port pin9 RI/+5V/+12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM2 JP_COM2 JP_COM2 BE-0996 SERIES USER MANUAL Page: 3-9...

  • Page 25: Com Connector (Com1, Com2)

    RS-485+ DTR# DSR# RTS# CTS# Note: COM2: Pin 9 is selectable for RI, +5V or +12V by JP_COM2 jumper setting. Default setting is RI. Please see “COM2 PIN9 Definition Selection Guide” for selection details. BE-0996 SERIES USER MANUAL Page: 3-10...

  • Page 26: Dual Usb 2.0 Port (Usb2, Usb3)

    USB 2.0 connector signals: ASSIGNMENT ASSIGNMENT USBP3N USBP4N USBP3P USBP4P USB2/ USB3 Port Location: USB3 (rear I/O) Description: Dual USB 2.0 Port (Type A) USB 2.0 connector signals: ASSIGNMENT ASSIGNMENT USBP5N USBP6N USBP5P USBP6P BE-0996 SERIES USER MANUAL Page: 3-11...

  • Page 27: Internal Usb 2.0 Connector (Jusb1)

    Connector Location: JUSB1 Description: Internal USB 2.0 Connector USB 2.0 connector signals: ASSIGNMENT ASSIGNMENT (option) USBP7N USBP10N USBP7P USBP10P JUSB1 Note: The functions of JUSB1 option pins are only supported on Core-i5 / i3 SoC boards. BE-0996 SERIES USER MANUAL Page: 3-12...

  • Page 28: Dual Usb 3.0 Ports (Usb1)

    Dual USB 3.0 Ports (USB1) Port Location: USB1 (rear I/O) Description: Dual USB 3.0 Port USB 3.0 connector signals: ASSIGNMENT ASSIGNMENT TX1_DP USBP1N TX1_DN USBP1P RX1_DP RX1_DN TX2_DP USBP2N TX2_DN USB1 USBP2P RX2_DP RX2_DN BE-0996 SERIES USER MANUAL Page: 3-13...

  • Page 29: Lan1, Lan2 Ports (Lan1, Lan2)

    Right Side LED Green Color On 10/100Mbps LAN Speed Indicator Orange Color On Giga LAN Speed Indicator No LAN switch/hub connected Left Side LED Yellow Color Blinking LAN Message Active No LAN Message Active BE-0996 SERIES USER MANUAL Page: 3-14...

  • Page 30: Dp And Hdmi Port (J1)

    ASSIGNMENT DP_C_DATA0+ DP_C_DATA0- DP_C_DATA1+ DP_C_DATA1- HDMI DP_C_DATA2+ DP_C_DATA2- DP_C_DATA3+ DP_C_DATA3- DP_C_AUX_ENJ DP_C_AUX+ DP_C_AUX- DP_VCC3_3 Pin Assignment for HDMI Port Connector: ASSIGNMENT ASSIGNMENT DP0_HDMI_P2 DP0_HDMI_N2 DP0_HDMI_P1 DP0_HDMI_N1 DP0_HDMI_P0 DP0_HDMI_N0 DP0_HDMI_CLKP DP0_HDMI_CLKN DP0_HDMI_SCL DP0_HDMI_SDA VCC5_HDMI DP0_HDMI_HPD_IN BE-0996 SERIES USER MANUAL Page: 3-15...

  • Page 31: Hd Audio Connector (Audio1)

    Chapter 3 Hardware Configuration 3.4.8 HD Audio Connector (AUDIO1) Connector Location: AUDIO1 Description: HD Audio Connector for Line In/Line Out/Mic In. PIN ASSIGNMENT PIN ASSIGNMENT MIC1-L MIC1-R HD_LINE-IN-L_L HD_LINE-IN-R_L AUDIO1 LINE-OUT-L LINE-OUT-R BE-0996 SERIES USER MANUAL Page: 3-16...

  • Page 32: Atx Power Input Connector (Atx1)

    Chapter 3 Hardware Configuration 3.4.9 ATX Power Input Connector (ATX1) Connector Location: ATX1 Description: ATX Power Input Connector ASSIGNMENT ASSIGNMENT +12V / +24V +12V / +24V ATX1 BE-0996 SERIES USER MANUAL Page: 3-17...

  • Page 33: Speaker Connectors (Spk_L_Out1, Spk_R_Out1)

    Chapter 3 Hardware Configuration 3.4.10 Speaker Connectors (SPK_L_OUT1, SPK_R_OUT1) Connector Location: SPK_L_OUT1 Description: Speaker Out Connector (Left side) PIN ASSIGNMENT AMP_OUTL+ AMP_OUTL- SPK_L_OUT1 Connector Location: SPK_R_OUT1 Description: Speaker Out Connector (Right side) PIN ASSIGNMENT AMP_OUTR+ AMP_OUTR- SPK_R_OUT1 BE-0996 SERIES USER MANUAL Page: 3-18...

  • Page 34: Digital Input / Output Connector (Jdio1)

    Digital Input / Output Connector (JDIO1) Connector Location: JDIO1 Description: Digital Input / Output Connector ASSIGNMENT ASSIGNMENT DIN_0 DOUT_0 DIN_1 DOUT_1 DIN_2 DOUT_2 DIN_3 DOUT_3 DIN_4 DOUT_4 DIN_5 DOUT_5 JDIO1 DIN_6 DOUT_6 DIN_7 DOUT_7 BE-0996 SERIES USER MANUAL Page: 3-19...

  • Page 35: Front Panel Connector (Jfp1)

    Chapter 3 Hardware Configuration 3.4.12 Front Panel Connector (JFP1) Connector Location: JFP1 Description: Front Panel Connector ASSIGNMENT ASSIGNMENT HDD LED+ PWR LED+ HDD LED- PWR LED- Power Button Reset Button JFP1 BE-0996 SERIES USER MANUAL Page: 3-20...
  • Page 36 Chapter 3 Hardware Configuration 3.4.13 CPU Fan Connector (CPU_FAN1) Connector Location: CPU_FAN1 Description: CPU Fan Connector CPU Fan Connector signals: ASSIGNMENT VCC12 CPU_FAN1 BE-0996 SERIES USER MANUAL Page: 3-21...

  • Page 37: Sata 3.0 Connector (Sata1)

    Chapter 3 Hardware Configuration 3.4.14 SATA 3.0 Connector (SATA1) Connector Location: SATA1 Description: Serial ATA (SATA) 6GB/s Connector SATA1 Serial ATA 6GB/s Connector (SATA1) signals: ASSIGNMENT TXPC TXNC RXNC RXPC BE-0996 SERIES USER MANUAL Page: 3-22...

  • Page 38: Sata Power Connector (Jhdd_Pwr1)

    Chapter 3 Hardware Configuration 3.4.15 SATA Power Connector (JHDD_PWR1) Connector Location: JHDD_PWR1 Description: Serial ATA Power Connector SATA Power Connector signals: ASSIGNMENT JHDD_PWR1 BE-0996 SERIES USER MANUAL Page: 3-23...

  • Page 39: Lvds Connector (Jlvds1)

    LVDS Connector (JLVDS1) Connector Location: JLVDS1 Description: LVDS Connector ASSIGNMENT ASSIGNMENT +3.3V/+5V LVDS_CLKBM LVDS_CLKBP LVDS_YBM2 LVDS_YBP2 LVDS_YBM1 LVDS_YBP1 LVDS_YBP3 LVDS_YBM3 LVDS_YBP0 LVDS_YBM0 LVDS_CLKAP LVDS_CLKAM LVDS_YAP2 LVDS_YAM2 LVDS_YAP1 LVDS_YAM1 LVDS_YAP0 LVDS_YAM0 LVDS_YAP3 LVDS_YAM3 JLVDS1 +3.3V/+5V +3.3V/+5V BE-0996 SERIES USER MANUAL Page: 3-24...

  • Page 40: Panel Inverter Connector (Jinv1)

    Chapter 3 Hardware Configuration 3.4.17 Panel Inverter Connector (JINV1) Connector Location: JINV1 Description: Panel Inverter Connector ASSIGNMENT +12V Backlight PWM Backlight Enable JINV1 BE-0996 SERIES USER MANUAL Page: 3-25...

  • Page 41: Mini Pci Express Slot (M_Pcie1)

    Mini PCI Express is the successor of the Mini PCI card and provides an increased data throughput. The cards have a detached network interface and are equipped with one lane. They are used in particular in embedded designs or compact box PCs. BE-0996 SERIES USER MANUAL Page: 3-26...
  • Page 42 Connector (M_SATA1) Connector Location: M_SATA1 Description: mSATA Slot ASSIGNMENT ASSIGNMENT 3.3V mSATA1_RX_DP 3.3V mSATA1_RX_DN M_SATA1 mSATA1_TX_DN mSATA1_TX_DP USB2_P9_DN USB2_P9_DP 3.3V 3.3V 3.3V Note: The USB function is only supported on Core-i5 / i3 SoC boards. BE-0996 SERIES USER MANUAL Page: 3-27...

  • Page 43: I2C Wafer (Ji2C1)

    Chapter 3 Hardware Configuration 3.4.20 I2C Wafer (JI2C1) Connector Location: JI2C1 Description: I2C Wafer ASSIGNMENT I2C0_SCL I2C0_SDA JI2C1 3.4.21 SPI Connector (JP7) Connector Location: JP7 Description: SPI Connector ASSIGNMENT ASSIGNMENT 3.3V MISO MOSI BE-0996 SERIES USER MANUAL Page: 3-28...

  • Page 44: Spi Override Protection Selection (Jp1)

    Chapter 3 Hardware Configuration 3.4.22 SPI Override Protection Selection (JP1) Jumper Location: JP1 Description: SPI Override Protection Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Disable (Default Setting) Enable Close BE-0996 SERIES USER MANUAL Page: 3-29...

  • Page 45: Battery Wafer (Jbat1)

    Chapter 3 Hardware Configuration 3.4.23 Battery Wafer (JBAT1) Connector Location: JBAT1 Description: Battery Wafer ASSIGNMENT VBAT+ JBAT1 BE-0996 SERIES USER MANUAL Page: 3-30...

  • Page 46: Slide Switch For Lvds Resolution Selection (Sw1)

    Description: LVDS Resolution/Channel/Color Bit Selection SELECTION SETTING 1024 x 768 Channel S/8bit (Default Setting) 800 x 600 Channel S/6bit 1024 x 768 Channel S/6bit 1280 x 768 Channel S/6bit 1280 x 800 Channel S/6bit BE-0996 SERIES USER MANUAL Page: 3-31...
  • Page 47 Chapter 3 Hardware Configuration SELECTION SETTING 1280 x 960 Channel S/6bit 1280 x 1024 Channel D/8bit 1366 x 768 Channel S/6bit 1366 x 768 Channel S/8bit 1440 x 900 Channel D/8bit 1400 x 1050 Channel D/8bit BE-0996 SERIES USER MANUAL Page: 3-32...
  • Page 48 Chapter 3 Hardware Configuration SELECTION SETTING 1600 x 900 Channel D/8bit 1680 x 1050 Channel D/8bit 1600 x 1200 Channel D/8bit 1920 x 1080 Channel D/8bit 1920 x 1200 Channel D/8bit BE-0996 SERIES USER MANUAL Page: 3-33...

  • Page 49: Lvds Vcc Selection (Jp5)

    Chapter 3 Hardware Configuration 3.4.25 LVDS VCC Selection (JP5) Jumper Location: JP5 Description: LVDS VCC Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) BE-0996 SERIES USER MANUAL Page: 3-34...

  • Page 50: Backlight Pwm Level Selection (Jp6)

    Chapter 3 Hardware Configuration 3.4.26 Backlight PWM Level Selection (JP6) Jumper Location: JP6 Description: Backlight PWM Level Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) BE-0996 SERIES USER MANUAL Page: 3-35...

  • Page 51: V3P3 Mpcie Selection (Jp9)

    Chapter 3 Hardware Configuration 3.4.27 V3P3 MPCIE Selection (JP9) Jumper Location: JP9 Description: V3P3 MPCIE Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION VCC3_3 (Default Setting) V3P3A BE-0996 SERIES USER MANUAL Page: 3-36...

  • Page 52: Clear Cmos Data Selection (Jcmos1)

    Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Open Normal (Default Setting) JCMOS1 Clear CMOS Close Data JCMOS1 Note: Please make sure the main power is off before you clear CMOS. BE-0996 SERIES USER MANUAL Page: 3-37...

  • Page 53: Software Utilities

    Chipset Software Installation Utility • Installing Graphics Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility ® • Installing Intel Management Engine Components Installer ® • Installing Intel Serial I/O Driver Utility BE-0996 SERIES USER MANUAL Page: 4-1...

  • Page 54: Introduction

    Chapter 4 Software Utilities 4.1 Introduction Enclosed with the BE-0996 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename Purpose (Assume that DVD-ROM drive is D:) ® D:\BE-0996_V1.0\Platform\ Intel...

  • Page 55: Installing Intel ® Chipset Software Installation Utility

    The utility pack is to be installed only for Windows 10 (64-bit), and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to BE-0996 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located (depending on your OS platform).

  • Page 56: Installing Graphics Driver Utility

    DP and HDMI interfaces and make the system work simultaneously. To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to BE-0996 and insert the driver disk. Enter the Graphics folder where the driver is located (depending on your OS platform).

  • Page 57: Installing Lan Driver Utility

    Enhanced with LAN function, BE-0996 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to BE-0996 and insert the driver disk. Enter the LAN folder where the driver is located (depending on your OS platform).

  • Page 58: Installing Sound Driver Utility

    Chapter 4 Software Utilities 4.5 Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to BE-0996 and insert the driver disk. Open the Sound folder where the driver is located (depending on your OS platform).

  • Page 59: Intel ® Management Engine Components Installer Installation

    ® Installation Instructions for Intel Management Engine Components Installer Connect the USB DVD-ROM device to BE-0996 and insert the driver disk. Enter the ME folder where the driver is located. Select Windows 10 (64-bit) for your OS platform. Click Setup.exe file for ME driver installation.

  • Page 60: Installing Intel ® Serial I/O Driver Utility

    4.7 Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to BE-0996 and insert the driver disk. Open the Serial I/O folder where the driver is located. Select Windows 10 (64-bit) for your OS platform.

  • Page 61: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu • BE-0996 SERIES USER MANUAL Page: 5-1...

  • Page 62: Introduction

    Chapter 5 BIOS Setup 5.1 Introduction The BE-0996 uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 63: Accessing Setup Utility

    POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: BE-0996 SERIES USER MANUAL Page: 5-3...
  • Page 64 English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. BE-0996 SERIES USER MANUAL Page: 5-4...
  • Page 65 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. BE-0996 SERIES USER MANUAL Page: 5-5...

  • Page 66: Main

    System Date Month, day, year Sets the system date. The format is [Day Month/ Date/ Year]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. The “Day” is BE-0996 SERIES USER MANUAL Page: 5-6...
  • Page 67 Options Description/Purpose automatically changed. System Time Hour, minute, second Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. BE-0996 SERIES USER MANUAL Page: 5-7...

  • Page 68: Advanced

    Sub-Menu System Super IO Chip Parameters Configuration Hardware Monitor Sub-Menu Monitor hardware status F81866 Watchdog Sub-Menu F81866 Watchdog Parameters. Enables the system to wake from S5 using S5 RTC Wake Settings Sub-Menu RTC alarm. BE-0996 SERIES USER MANUAL Page: 5-8...

  • Page 69: Advanced - Cpu Configuration

    Displays CPU ID number. Displays the CPU Microcode Microcode Revision No changeable options Revision. Speed No changeable options Displays the CPU speed. Number of Processors No changeable options Displays the CPU number of the BE-0996 SERIES USER MANUAL Page: 5-9...
  • Page 70 Intel (VMX) - Disabled When enabled, VMM can utilize the Virtualization - Enabled additional hardware capabilities Technology provided by Vanderpool Technology. BE-0996 SERIES USER MANUAL Page: 5-10...

  • Page 71: Advanced - Sata Configuration

    - Disabled Port 0 - 1 Enables or Disables SATA Port Device. - Enabled Enables or Disables Hot Plug function - Disabled Hot Plug to designate a SATA port device as - Enabled hot-pluggable. BE-0996 SERIES USER MANUAL Page: 5-11...

  • Page 72: Advanced - Pch-Fw Configuration

    Description/Purpose ME Firmware Version No changeable options Displays the ME Firmware Version. ME Firmware Mode No changeable options Displays the ME Firmware Mode. ME Firmware SKU No changeable options Displays the ME Firmware SKU. BE-0996 SERIES USER MANUAL Page: 5-12...

  • Page 73: Advanced - Trusted Computing

    SHA256 PCR Bank - Disabled Enables or Disables SHA256 PCR - Enabled Bank. Pending operation - None Schedules an operation for the Security Device. Note: Your - TPM Clear computer will reboot during restart in BE-0996 SERIES USER MANUAL Page: 5-13...
  • Page 74 • TPM 2.0: Restricts support to TPM 2.0 devices. • Auto: Supports both TPM 1.2 and TPM 2.0 with the default set to TPM 2.0 devices if not found. TPM 1.2 devices will be enumerated. BE-0996 SERIES USER MANUAL Page: 5-14...

  • Page 75: Advanced - Acpi Settings

    - S3 (Suspend to RAM) button is pressed. Lock Legacy - Disabled Enables or Disables Lock of Legacy Resources - Enabled Resources. - Disabled S3 Video Repost Enables or Disables S3 Video Repost. - Enabled BE-0996 SERIES USER MANUAL Page: 5-15...

  • Page 76: Advanced - F81866 Super Io Configuration

    F81866 Super IO Configuration Screen BIOS Setting Options Description/Purpose Sets the parameters of Serial Port 1 Serial Port 1 Configuration Sub-Menu (COMA). Sets the parameters of Serial Port 2 Serial Port 2 Configuration Sub-Menu (COMB). BE-0996 SERIES USER MANUAL Page: 5-16...
  • Page 77 Selects IRQ and I/O resource - IO=3F8h; IRQ=4; settings for Serial Port 1. - IO=3F8h; IRQ=3,4,5,7,10,11,12; - IO=2F8h; IRQ=3,4,5,7,10,11,12; - IO=3E8h; IRQ=3,4,5,7,10,11,12; - IO=2E8h; IRQ=3,4,5,7,10,11,12; Mode Selects COM mode. - RS-232 - RS-422 - RS-485 BE-0996 SERIES USER MANUAL Page: 5-17...
  • Page 78 Selects IRQ and I/O resource - IO=2F8h; IRQ=3; settings for Serial Port 2. - IO=3F8h; IRQ=3,4,5,7,10,11,12; - IO=2F8h; IRQ=3,4,5,7,10,11,12; - IO=3E8h; IRQ=3,4,5,7,10,11,12; - IO=2E8h; IRQ=3,4,5,7,10,11,12; Mode - RS-232 Selects COM mode. - RS-422 - RS-485 BE-0996 SERIES USER MANUAL Page: 5-18...

  • Page 79: Advanced - Hardware Monitor

    Displays the voltage level of VCORE VCORE No changeable options in supply. Displays the voltage level of VSB5V VSB5V No changeable options in supply. Displays the voltage level of VCC5V VCC5V No changeable options in supply. BE-0996 SERIES USER MANUAL Page: 5-19...

  • Page 80: Smart Fan Mode Configuration

    CPU Fan Smart Fan Control - Auto Duty-Cycle Mode Fan. Manual mode fan control. Users can Manual Duty Mode Numeric (from 1 to 100) write expected duty cycle (PWM fan type) from 1 to 100. BE-0996 SERIES USER MANUAL Page: 5-20...

  • Page 81: Advanced - F81866 Watchdog

    Enables/Disables F81866 Watchdog Enable Watchdog - Enabled timer settings. - 1s Watchdog timer unit Watchdog timer unit. - 60s Numeric Count for Timer (Seconds) The number of count for Timer. (from 10 to 255) BE-0996 SERIES USER MANUAL Page: 5-21...

  • Page 82: Advanced - S5 Rtc Wake Settings

    Allows enabling scheduled S5 to S0 - Fixed Time (option enabled). - Dynamic Time • Fixed Time: System will wake on the hr::min::sec specified. • Dynamic Time: System will wake on the current time + Increase minute(s). BE-0996 SERIES USER MANUAL Page: 5-22...
  • Page 83 Wake up minute Multiple options Sets a minute for scheduled power-on ranging from 0 to 59 event. Wake up second Multiple options Sets a second for scheduled power-on ranging from 0 to 59 event. BE-0996 SERIES USER MANUAL Page: 5-23...
  • Page 84 + Increase minute(s). Wake up minute increase Multiple options Sets a period of time (in minutes) ranging from 1 to 5 after which the board wakes up from S5 state. BE-0996 SERIES USER MANUAL Page: 5-24...

  • Page 85: Advanced - Graphic Output Protocol Policy

    Menu Path The Graphic Output Protocol Policy allows users to configure the monitor output policy. Graphic Output Protocol Policy Screen BIOS Setting Options Description/Purpose Output Select - Default Output Interface. - DP + HDMI BE-0996 SERIES USER MANUAL Page: 5-25...

  • Page 86: Advanced - Usb Configuration

    Menu Path Advanced > USB Configuration The USB Configuration allows users to enable/disable legacy USB support. USB Configuration Screen BIOS Setting Options Description/Purpose - Disabled Legacy USB Support Enables/Disables Legacy USB support. - Enabled BE-0996 SERIES USER MANUAL Page: 5-26...

  • Page 87: Advanced - Network Stack Configuration

    Ipv4 PXE Support disabled, Ipv4 PXE boot option will not - Enabled be created. Enables Ipv6 PXE Boot Support. If - Disabled Ipv6 PXE Support disabled, Ipv6 PXE boot option will not - Enabled be created. BE-0996 SERIES USER MANUAL Page: 5-27...
  • Page 88 PXE boot wait time Numeric (from 0 to 5) to abort after the Esc key is pressed. Number of times that the media presence Media detect count Numeric (from 1 to 50) will be checked. BE-0996 SERIES USER MANUAL Page: 5-28...

  • Page 89: Chipset

    This menu allows users to configure advanced Chipset settings such as such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Sub-Menu System Agent (SA) Parameters. Configuration PCH-IO Configuration Sub-Menu PCH Parameters. BE-0996 SERIES USER MANUAL Page: 5-29...

  • Page 90: Chipset - System Agent (Sa) Configuration

    I/O devices in virtualized environment. Memory Configuration Sub-Menu Displays the DRAM information on the platform. BE-0996 SERIES USER MANUAL Page: 5-30...

  • Page 91: Chipset - Sa Configuration - Memory Configuration

    No changeable options Displays the total memory. Memory Timings No changeable options Displays the Memory (RAM) timings (tCL-tRCD-tRP-tRAS) and latency. • CAS Latency (tCL) - This is the most important memory timing. CAS stands BE-0996 SERIES USER MANUAL Page: 5-31...
  • Page 92 (tRAS = tCL + tRCD + tRP). Displays if Channel 0 Slot 0 socket is Channel 0 Slot 0 No changeable options populated/enabled or not. Size No changeable options Displays the total memory size. BE-0996 SERIES USER MANUAL Page: 5-32...

  • Page 93: Chipset - Pch-Io Configuration

    Default: Enabled. State After G3 - Power On Specifies the Power On/Off state that the - Power Off system will go into when the power is re-applied following a power failure (G3 state). BE-0996 SERIES USER MANUAL Page: 5-33...

  • Page 94: Chipset - Pch-Io Configuration - Pci Express Configuration

    BIOS Setting Options Description/Purpose Displays the LAN assigned PCIE PCIE Port assigned to LAN No changeable options Port. Mini PCIe/ mSATA combo - Mini PCIe Mini PCIe/ mSATA combo port port - mSATA selection. BE-0996 SERIES USER MANUAL Page: 5-34...

  • Page 95: Security

    Setup utility. Security Screen BIOS Setting Options Description/Purpose Administrator Password can be 3-20 Specifies the administrator password. Password alphanumeric characters. Password can be 3-20 User Password Specifies the user password. alphanumeric characters. BE-0996 SERIES USER MANUAL Page: 5-35...
  • Page 96 2. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. 3. Press <Enter> again when the password confirmation box appears. BE-0996 SERIES USER MANUAL Page: 5-36...

  • Page 97: Boot

    Selects the NumLock state after the NumLock State - Off system is powered on. • On: Enables the NumLock function automatically after the system is powered on. • Off: Disables the NumLock function after the system is powered on. BE-0996 SERIES USER MANUAL Page: 5-37...
  • Page 98 - [Drive(s)] Allows users to set the system boot order. #1~#n - Disabled Note that in the menu displayed, you will only see the device with the highest priority for a specific boot device type. BE-0996 SERIES USER MANUAL Page: 5-38...

  • Page 99: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen BE-0996 SERIES USER MANUAL Page: 5-39...
  • Page 100 Saves the changes done so far as User No changeable options Defaults Defaults. Restore User Restores the User Defaults to all the BIOS No changeable options Defaults settings. Boot Override - [Drive(s)] Forces to boot from selected [drive(s)]. BE-0996 SERIES USER MANUAL Page: 5-40...

  • Page 101: Appendix A Technical Summary

    Appendix A Technical Summary This appendix will give you a brief introduction of the allocation maps for BE-0996 resources. The following topics are included: • BE-0996 Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer •...

  • Page 102: Be-0996 Block Diagram

    80 PORT for Debug TPS51716 Connector For DDR4 FINTEK CPU FAN*1 F8143 A [RS232] COM1 LPC SIO HW monitor PIN HEADER F81866AD-I 12V, 5V, 5VSB, VCORE F8143 A COM2 [RS232/422/485] PIN HEADER COM2 support 5V/12V BE-0996 SERIES USER MANUAL Page: A-2...

  • Page 103: Interrupt Map

    IRQ 76 Microsoft ACPI-Compliant System IRQ 77 Microsoft ACPI-Compliant System IRQ 78 Microsoft ACPI-Compliant System IRQ 79 Microsoft ACPI-Compliant System IRQ 80 Microsoft ACPI-Compliant System IRQ 81 Microsoft ACPI-Compliant System IRQ 82 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-3...
  • Page 104 IRQ 119 Microsoft ACPI-Compliant System IRQ 120 Microsoft ACPI-Compliant System IRQ 121 Microsoft ACPI-Compliant System IRQ 122 Microsoft ACPI-Compliant System IRQ 123 Microsoft ACPI-Compliant System IRQ 124 Microsoft ACPI-Compliant System IRQ 125 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-4...
  • Page 105 IRQ 162 Microsoft ACPI-Compliant System IRQ 163 Microsoft ACPI-Compliant System IRQ 164 Microsoft ACPI-Compliant System IRQ 165 Microsoft ACPI-Compliant System IRQ 166 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-5...
  • Page 106 IRQ 256 Microsoft ACPI-Compliant System IRQ 257 Microsoft ACPI-Compliant System IRQ 258 Microsoft ACPI-Compliant System IRQ 259 Microsoft ACPI-Compliant System IRQ 260 Microsoft ACPI-Compliant System IRQ 261 Microsoft ACPI-Compliant System IRQ 262 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-6...
  • Page 107 IRQ 299 Microsoft ACPI-Compliant System IRQ 300 Microsoft ACPI-Compliant System IRQ 301 Microsoft ACPI-Compliant System IRQ 302 Microsoft ACPI-Compliant System IRQ 303 Microsoft ACPI-Compliant System IRQ 304 Microsoft ACPI-Compliant System IRQ 305 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-7...
  • Page 108 IRQ 342 Microsoft ACPI-Compliant System IRQ 343 Microsoft ACPI-Compliant System IRQ 344 Microsoft ACPI-Compliant System IRQ 345 Microsoft ACPI-Compliant System IRQ 346 Microsoft ACPI-Compliant System IRQ 347 Microsoft ACPI-Compliant System IRQ 348 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-8...
  • Page 109 IRQ 385 Microsoft ACPI-Compliant System IRQ 386 Microsoft ACPI-Compliant System IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System IRQ 389 Microsoft ACPI-Compliant System IRQ 390 Microsoft ACPI-Compliant System IRQ 391 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-9...
  • Page 110 IRQ 428 Microsoft ACPI-Compliant System IRQ 429 Microsoft ACPI-Compliant System IRQ 430 Microsoft ACPI-Compliant System IRQ 431 Microsoft ACPI-Compliant System IRQ 432 Microsoft ACPI-Compliant System IRQ 433 Microsoft ACPI-Compliant System IRQ 434 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-10...
  • Page 111 IRQ 471 Microsoft ACPI-Compliant System IRQ 472 Microsoft ACPI-Compliant System IRQ 473 Microsoft ACPI-Compliant System IRQ 474 Microsoft ACPI-Compliant System IRQ 475 Microsoft ACPI-Compliant System IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System BE-0996 SERIES USER MANUAL Page: A-11...
  • Page 112 IRQ 4294967289 Intel(R) I211 Gigabit Network Connection IRQ 4294967288 Intel(R) I211 Gigabit Network Connection IRQ 4294967287 Intel(R) I211 Gigabit Network Connection IRQ 4294967286 Intel(R) I211 Gigabit Network Connection IRQ 4294967285 Intel(R) I211 Gigabit Network Connection BE-0996 SERIES USER MANUAL Page: A-12...
  • Page 113 Standard SATA AHCI Controller IRQ 4294967294 Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #6 - A115 Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). BE-0996 SERIES USER MANUAL Page: A-13...

  • Page 114: I/O Map

    Communications Port (COM2) 0x000003F8-0x000003FF Communications Port (COM1) 0x000004D0-0x000004D1 Programmable interrupt controller 0x00000680-0x0000069F Motherboard resources 0x00000A00-0x00000A0F Motherboard resources 0x00000A10-0x00000A1F Motherboard resources 0x00000A20-0x00000A2F Motherboard resources 0x00000D00-0x0000FFFF PCI Express Root Complex 0x0000164E-0x0000164F Motherboard resources 0x00001800-0x000018FE Motherboard resources BE-0996 SERIES USER MANUAL Page: A-14...
  • Page 115 Mobile Intel(R) Processor Family I/O SMBUS 0x0000F040-0x0000F05F - 9D23 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F090-0x0000F097 Standard SATA AHCI Controller 0x0000FF00-0x0000FFFE Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources BE-0996 SERIES USER MANUAL Page: A-15...

  • Page 116: Memory Map

    0x90000000-0xDFFFFFFF PCI Express Root Complex 0xFE035000-0xFE035FFF Intel(R) Management Engine Interface 0xFED40000-0xFED44FFF Trusted Platform Module 2.0 0xDF130000-0xDF13FFFF Intel(R) USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) 0xDF14A000-0xDF14A0FF Mobile Intel(R) Processor Family I/O SMBUS - 9D23 BE-0996 SERIES USER MANUAL Page: A-16...
  • Page 117 PCI Express Root Complex 0xDC000-0xDFFFF PCI Express Root Complex 0xE0000-0xE3FFF PCI Express Root Complex 0xE4000-0xE7FFF PCI Express Root Complex 0xE8000-0xEBFFF PCI Express Root Complex 0xEC000-0xEFFFF PCI Express Root Complex 0xF0000-0xFFFFF PCI Express Root Complex BE-0996 SERIES USER MANUAL Page: A-17...

  • Page 118: Configuring Watchdog Timer

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. BE-0996 SERIES USER MANUAL Page: A-18...
  • Page 119 ;------------------------------- Enable Watch PME-------------------------------------------- 0FAh dx, al dx, al ;------------------- Set second as counting unit and start counting -------------------- 0F5h dx, al 0F7h dx, al ;---------------------------- Exit the extended function mode ------------------------------ 0AAh dx, al BE-0996 SERIES USER MANUAL Page: A-19...

  • Page 120: Flash Bios Update

    (3) The system will go into the BIOS setup menu. (4) Select [Boot] menu and set the USB storage device as the 1 boot device. (5) Press <F4> key to save the configuration and restart the system to boot into EFI Shell environment. BE-0996 SERIES USER MANUAL Page: A-20...
  • Page 121 /?” to view the definition of each control option. The recommended options for BIOS ROM update include the following parameters: Program main BIOS image. /B: Program Boot Block. /N: Program NVRAM. /X: Don’t check ROM ID. BE-0996 SERIES USER MANUAL Page: A-21...
  • Page 122 Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. BE-0996 SERIES USER MANUAL Page: A-22...
  • Page 123 Appendix A Technical Summary BE-0996 SERIES USER MANUAL Page: A-23...

Table of Contents
