Summary of Contents for Grundig GWNE37E432
- Page 1 Washing Machine User Manual GWNE37E432 Document Number: 2820528970_EN/ 02-10-20.(11:02)
- Page 2 Please read this user manual first! Dear Customer, Thank you for preferring a Grundig product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important instructions for safety Auxiliary functions ....29 and environment Functions/Programmes Selected by Pressing the Function Buttons for 3 General safety ..... 4 Seconds . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. General safety • This product can be used by children at and above 8 years old and by persons whose physical, sen- sory or mental capabilities are not fully developed or who lack experience and knowledge provided... -
Page 5: Product Safety
• Connect the product to a grounded outlet pro- tected by a 16 A fuse. Have the grounding instal- lation made by a qualified electrician. Our com- pany shall not be liable for any damages that will arise when the product is used without ground- ing in accordance with the local regulations. -
Page 6: Intended Use
• Follow the instructions on the textile tags and on the detergent package. • Place the product on a rigid, flat and level surface. • Do not place it on a long-pile rug or similar sur- faces. • Do not place the product on a high platform or near the edge on a cascaded surface. -
Page 7: Children's Safety
Children's safety • Packaging materials are dangerous to children. Keep packaging materials in a safe place away from reach of the children. • Electrical products are dangerous to children. Keep children away from the product when it is in use. Do not let them to tamper with the prod- uct. -
Page 8: Compliance With The Weee Directive
Compliance with the WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal do- mestic and other wastes at the end of its service life. -
Page 9: Your Washing Machine
Your washing machine Overview 1- Power cable 2- Top panel 3- Control panel 4- Filter cap 5- Adjustable feet 6- Loading door 7- Detergent drawer 8- Drain hose... -
Page 10: Package Contents
Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronic water shut-off b- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual 7- Blind plug***... -
Page 11: Technical Specifications
Technical specifications Supplier name or trademark GRUNDIG GWNE37E432 Model name 7138244200 Rated capacity (kg) Maximum spin speed (rpm) 1400 Built-in Height (cm) Width (cm) Depth (cm) Single Water inlet / Double Water inlet • / - • Available Electrical input (V/Hz) -
Page 12: Installation
Installation Appropriate installation location • Place the machine on a rigid floor. Refer to the nearest Authorised Do not place it on a long pile rug Service Agent for installation of the or similar surfaces. product. To make the product ready •... -
Page 13: Removing The Transportation Locks
Removing the Keep the transportation transportation locks safety bolts in a safe place to reuse when the washing WARNING: Do not remove machine needs to be moved the transportation locks again in the future. before taking out the Never move the product packaging reinforcement. -
Page 14: Connecting To The Drain
• Open the taps completely after • To prevent flowing of dirty water making the hose connection back into the machine and to to check for water leaks at the allow for easy discharge, do not connection points. If any leaks immerse the hose end into the occur, turn off the tap and dirty water or do not drive it in the... -
Page 15: Electrical Connection
• Adjust the feet until the product • The voltage specified in the stands level and balanced. "Technical specifications" section must be equal to your mains voltage. • Do not make connections via extension cables or multi-plugs. WARNING: Damaged power cables must be •... -
Page 16: Preparation
Preparation Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures ... -
Page 17: Preparing Laundry For Washing
Preparing laundry for washing Tips for energy and water saving • Laundry items with metal Following information will help you attachments such as, underwired use the product in an ecological and bras, belt buckles or metal energy/water-efficient manner. buttons will damage the machine. •... -
Page 18: Correct Load Capacity
Correct load capacity The loading door is locked The maximum load capacity depends while a programme is on the type of laundry, the degree of running. The door can only soiling and the washing programme be opened a while after the desired. - Page 19 • In a programme with prewash, Adjusting detergent amount do not put liquid detergent into The amount of washing detergent the prewash compartment to be used depends on the amount (compartment nr. „1“). of laundry, the degree of soiling and •...
- Page 20 If the product is equipped with a Tablet detergents may liquid detergent part: leave residues in the • When you want to use liquid detergent compartment. If detergent, pull the apparatus you encounter such a case, towards yourself. The part that place the tablet detergent falls down will serve as a barrier between the laundry, close...
-
Page 21: Tips For Efficient Washing
• Oxygen based bleaches can be Tips for efficient washing used together with detergents; Clothes however, if its thickness is not Light colours and whites the same with the detergent, (Recommended put the detergent first into the temperature range based compartment nr. -
Page 22: Displayed Program Time
Clothes Clothes Delicates/Woollens/Silks Powder and liquid detergents recommended (Recommended for colors can be used at temperature range based dosages recommended on soiling level: cold -30 for heavily soiled clothes. °C) Heavily It is recommended to use Prefer liquid detergents Soiled powder detergents to clean produced for delicate clay and soil stains and the... -
Page 23: Operation
Operation Control panel 1 - Programme selection display 8 - Auxiliary function button 3 2 - Cover lock LED indicator 9 - Auxiliary function button 2 3 - Child lock LED indicator 10 - Auxiliary function button 1 4 - Display 11 - Spin Speed Adjustment button 5 - Programme follow-up indicators 12 - Temperature Adjustment button... -
Page 24: Programme And Consumption Table
Programme and consumption table Auxiliary functions Temperature Programme °C Cold-90 1400 2,150 • • • • Cotton Cold-90 1,600 1400 • • • • Cold-90 0,800 1400 • • • • 40 *** 40-60 52,0 0,950 1400 40 **,*** 3,5 40-60 38,0 0,650 1400 Eco 40-60... - Page 25 “The auxiliary functions in the table may vary according to the model of your machine.“ “Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.”...
-
Page 26: Programmes
Programmes Although it washes longer than all other programmes, it provides high • Cotton energy and water savings. Actual You can wash your durable cotton water temperature may be different laundry (sheets, bedlinen, towels, from the stated wash temperature. bathrobes, underwear etc.) in When you load the machine with this programme. - Page 27 • GentleCare • Outdoor / Sport You can wash your delicate You can use this programme to wash clothes such as cotton/synthetic sports and outdoors garments that blended knitwear or hosiery in this contain cotton/synthetics mix and programme. It washes with more water repellent covers such as gore- delicate washing action.
-
Page 28: Special Programmes
You can find stain groups based on To decrease the temperature, press quick function below: the Temperature Adjustment button. Temperature will decrease gradually. When quick function is selected: If the programme has not Blood reached the heating step, you can change the temperature Chocolate Coffee without switching the... -
Page 29: Auxiliary Function Selection
Auxiliary function selection An auxiliary function which Select the desired auxiliary functions is not compatible with the before starting the programme. programme cannot be When this programme and a selected. (See „Programme relevant auxiliary function that can and consumption table“) be selected together with it are Some programmes have selected, the related indicator light... -
Page 30: Functions/Programmes Selected By
Functions/Programmes Selected To deactivate the Child Lock: * Press and hold 2nd auxiliary function by Pressing the Function button for 3 seconds. "Child Lock Buttons for 3 Seconds On" disappears from the screen after "3_2_1" countdown in the programme • Drum Clean selection screen on the panel. -
Page 31: Starting The Programme
Starting the programme • Open the loading door, place the laundry and put detergent, etc. • Start the programme with Start/ • Select the washing programme, Pause button. temperature, spin speed and, if • Programme follow-up light required, the auxiliary functions. showing the startup of the •... -
Page 32: Cancelling The Programme
Changing the auxiliary function, If you want to open the speed and temperature loading door after you have Depending on the step the cancelled the programme programme has reached, you can but it is not possible to open cancel or activate the auxiliary the loading door since the functions;... -
Page 33: Quick User Manual Preparing The Machine
Quick User Manual End of programme End symbol appears when the Preparing the machine programme is completed. • Check if the hoses are connected If you do not press any button for 10 tightly. minutes, the machine will switch to •... -
Page 34: Maintenance And Cleaning
Maintenance and Cleaning the loading door and the drum cleaning For products with drum cleaning Service life of the product extends programme, please see Operating and frequently faced problems the product - Programmes. decrease if cleaned at regular intervals. Repeat Drum Cleaning Cleaning the detergent drawer process in every 2 months. -
Page 35: Cleaning The Body And Control Panel
Cleaning the body and Draining remaining water and control panel cleaning the pump filter Wipe the body of the machine with The filter system in your machine soapy water or non-corrosive mild prevents solid items such as buttons, gel detergents as necessary, and dry coins and fabric fibers clogging the with a soft cloth. -
Page 36: If The Product Has An Emergency Draining Hose, To Discharge The Water
• Open the filter cap. • Place a large container at the • If the filter cap is composed of end of the hose. Drain the water two pieces, press the tab on the into the container by pulling out filter cap downwards and pull the the plug at the end of the hose. -
Page 37: Troubleshooting
Troubleshooting Program does not start after closing the door. *Press the Start / Pause / • Start / Pause / Cancel button was not pressed. >>> Cancel button. • It may be difficult to close the loading door in case of excessive loading. >>> Reduce the amount of laundry and make sure that the loading door is closed properly. - Page 38 Machine directly discharges the water it takes in. Connect the water draining • Draining hose might not be at adequate height. >>> hose as described in the operation manual. No water can be n in the machine during washing. • The water level is not visible from outside of the washing machine. This is not a failure.
- Page 39 Machine does not switch to spinning step. (*) Automatic unbalanced load • There might be an imbalance of laundry in the machine. >>> detection system might be activated due to the unbalanced distribution of the laundry in the drum. Check the filter •...
- Page 40 It does not rinse well. • The amount, brand and storage conditions of the detergent used are Use a detergent appropriate for the washing machine and your inappropriate. >>> laundry. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 41 There is detergent left on the laundry. (**) Do not load the machine in excess. • Excessive laundry was loaded in. >>> Select the proper • Wrong programme and temperature were selected. >>> programme and temperature for the laundry to be washed. Select the proper detergent for the laundry to be •...
