Hioki P9000-01 Instruction Manual

P9000-01
P9000-02
DIFFERENTIAL PROBE
Instruction Manual
Dec. 2019 Revised edition 1
P9000A981-01 19-12H

Warranty

Warranty malfunctions occurring under conditions of normal use in
conformity with the Instruction Manual and Product Precautionary
Markings will be repaired free of charge. This warranty is valid for a
period of three (3) years from the date of purchase. Please contact
the distributor from which you purchased the product for further infor-
mation on warranty provisions.

Introduction

Thank you for choosing the Hioki P9000-01, P9000-02 Differential
Probe. Preserve this manual carefully and keep it handy to make full
use of this product for along time.

Overview

The product is a differential probe that is connected to a Memory
HiCorder input unit. The probe divides two high voltages input to its
high and low terminals by 100 or 1000 and then outputs the differ-
ence as a signal relative to ground. The P9000-02 includes AC RMS
value output functionality.
Power can be supplied via the optional AC adapter or a commer-
cially available USB cable.

Verifying Package Contents

When you open the package, carefully inspect the product to ensure
that everything is in good condition, and that no damage occurred
during shipping. Carefully check the accessories and connectors.
If the product seems to have been damaged or does not work as
specified, contact your authorized Hioki distributor or reseller.

Cleaning

If the product becomes dirty, slightly moisten a soft cloth moistened
with water or a neutral detergent and wipe the product clean.
IMPORTANT
Never use solvents such as benzene, alcohol, acetone, ether,
ketones, thinners or gasoline, as they can deform and discolor the
case.

Repair

If the product seems to be malfunctioning, confirm that the AC adapt-
er and the USB cable are connected properly before contacting your
authorized Hioki distributor or reseller.
Touching any of the high-voltage points inside the
product is very dangerous. Do not attempt to mod-
ify, disassemble, or try to repair the product. Doing
so may cause a fire, electric shock, or injury.
EN

Calibration

IMPORTANT
Periodic calibration is necessary in order to ensure that the in-
strument provides correct measurement results of the specified
accuracy.
The calibration period varies with the conditions and environment of
use. It is recommended to determine a calibration period based on
those factors and to have the product regularly calibrated by Hioki.
Please contact your Hioki distributor to have your product periodi-
cally calibrated.

Precautions during shipment

Be sure to follow these precautions when transporting the product:
• Remove accessories and optional equipment from the product
in order to avoid damage. Additionally, be sure to double box the
product. Accidental damage suffered in transit is not covered by the
warranty.
• Attach a description of the issue when sending out your product for
repair.

Disposal

Dispose of the product in accordance with local regulations.

Safety Notes

This product is designed to conform to IEC 61010 Safety Standards,
and has been thoroughly tested for safety prior to shipment. How-
ever, using the product in a way not described in this manual may
negate the provided safety features.
Carefully read the following safety notes before using the product.
Mishandling product could result in bodily injury or
even death, as well as damage to the product. Fa-
miliarize yourself with the instructions and precau-
tions in this manual before using the product.
• Protective Gear
Performing measurement using this product in-
volves live-line work. To prevent an electric shock,
use appropriate protective insulation and adhere
to applicable laws and regulations.
• Electricity can potentially cause serious events
such as an electric shock, heat generation, fire,
and an arc flash due to a short-circuit. If you have
not used electrical measuring instrument before,
you should be supervised by a technician who
has experience in electrical measurement.
WARNING
WARNING
WARNING
