Gazebo penguin Florence Assembly Instructions Manual

Sand 10 x 16 solarium
Hide thumbs Also See for Florence:

Advertisement

Quick Links

Download this manual
W1610 ½ -12
SAND
10 X 16 SOLARIUM
ASSEMBLY INSTRUCTIONS
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
FOR FUTURE REFERENCE,
TAKE PICTURES OF ALL SIX SIDES OF EACH OF THE BOXES UPON RECEIPT.
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
Assembly by two or three adults is suggested.
Requires 96" clearance at the wall
Base Dimensions 190''x 118''
Largest Dimensions 190''x122''
APPROX.
(See Last Pg.)
ZZZ-210.W1610-12.1129-21.GP.EN
TAP-OH
1
