Table Of Contents - INVENTOR AR2MVI32-12WiFi/AR2MVO32-12 Instruction Manual

CONTENTS
SAFETY PRECAUTIONS
Warning .....................................................................................................................................2
Caution ......................................................................................................................................2
INSTALLATION INSTRUCTIONS
Selecting installation place.........................................................................................................4
Accessories ........ .....................................................................................................................5
Indoor & outdoor unit installation drawings ...............................................................................5
INDOOR UNIT INSTALLATION
Installation plate mounting..........................................................................................................6
Drill a hole in the wall ........ ......................................................................................................7
Connective pipe and drainage installation..................................................................................8
OUTDOOR UNIT INSTALLAITON
Outdoor installation precaution ..............................................................................................9
Settlement of outdoor unit ......................................................................................................9
Drain joint installation ...........................................................................................................10
Refrigerant pipe connection ...................................................................................................10
Connect the cable to the outdoor unit ...................................................................................12
Air purging.................................................................................................................................12
TEST RUNNING
Test running ...................... .....................................................................................................16
INFORMATION SERVICING
Information servicing ...............................................................................................................17
Caution: Risk of fire
Read the follow SAFETY PRECAUTIONS carefully before installation.
Incorrect installation due to ignoring of the instruction will cause harm or damage, and the
seriousness is classified by the following indications.
This symbol indicates the possibility of death or serious injury.
WARNING
This symbol indicates the possibility of injury or damage to property.
CAUTION
The items to be followed are classified by the symbols:
Symbol will background white denotes item that is PROHIBITED from doing.
1) Engage dealer or specialist for installation. If installation done by the user is defective, it will cause
water leakage, electrical shock or fire.
2) Install according to this installation instructions strictly. If installation is defective, it will cause water
leakage, electrical shock or fire.
3) Use the attached accessories parts and specified parts for installation. otherwise, it will cause the set
to fall, water leakage, electrical shock or fire.
4) Install at a strong and firm location which is able to withstand the set s weight. If the strength is not
enough or installation is not properly done, the set will drop and cause injury.
5) For electrical work, follow the local national wiring standard, regulation and this installation
instructions. An independent circuit and single outlet must be used. If electrical circuit capacity is not
enough or defect found in electrical work, it will cause electrical shock fire.
6) Use the specified cable and connect tightly and clamp the cable so that no external force will be
acted on the terminal. If connection or fixing is not perfect, it will cause heat-up or fire at the
connection.
7) Wiring routing must be properly arranged so that control board cover is fixed properly. If control board
cover is not fixed perfectly, it will cause heat-up at connection point of terminal, fire or electrical shock.
8) When carrying out piping connection, take care not to let air substances other than the specified
refrigerant go into refrigeration cycle. Otherwise, it will cause lower capacity, abnormal high pressure
in the refrigeration cycle, explosion and injury.
9) Do not modify the length of the power supply cord or use of extension cord, and do not share the
single outlet with other electrical appliances. Otherwise, it will cause fire or electrical shock.
10) Do not use means to accelerate the defrosting process or to clean, other than those recommended
by the manufacturer.
11) The appliance shall be stored in a room without continuously operating ignition sources
(for example: open flames, an operating gas appliance or an operating electric heater.
12) Do not pierce or burn.
13) Appliance shall be installed, operated and stored in a room with a floor area larger than 4 m . The
appliance shall not be installed in an unventilated space, if that space is smaller than 4m .
14) Appliance shall be stored in a well-ventilated area where the room size corresponds to the room
area as specified for operation.
15) Appliance shall be stored in a room without continuously operating open flames (for example an
operating gas appliance) and ignition sources (for example an operating electric heater).
16)Be aware that refrigerants may not contain an odour.
SAFETY PRECAUTIONS
WARNING
,
