Instructions for Use
49" LCD monitor
Important
Please read the safety information and all information delivered
with the product carefully to familiarize yourself with safe and
effective usage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CuratOR LX490W and is the answer not in the manual?

Questions and answers

Related Manuals for Eizo CuratOR LX490W

Summary of Contents for Eizo CuratOR LX490W

  • Page 1 Instructions for Use 49” LCD monitor Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.

  • Page 2: Legal Information

    Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    7 Operation.........................  29 Operator controls .................... 29 Remote control ....................... 30 Lock or unlock OSD menu.................. 31 Picture layout (PaP, PiP, PoP) ................ 31 Overview of the OSD menu .................. 33 "Picture” menu ...................... 33 "Image" menu ...................... 35 "Signal" menu ...................... 37 CuratOR LX490W Instructions for Use, 06/2017...
  • Page 4 13.2 Markings and symbols .................... 59 13.3 Warranty ......................... 60 13.4 Repairs ........................ 60 13.5 Environmental protection .................. 60 13.6 China RoHS (Restriction of Hazardous Substances) .......... 60 13.7 Additional devices.................... 61 13.8 Contact ........................ 62 13.9 Trademarks...................... 62 Index .......................... 63 CuratOR LX490W Instructions for Use, 06/2017...

  • Page 5: Introduction

    1 Introduction 1.1 Contents of this document This document explains the functionality and the approved use of the CuratOR LX490W. To ensure clarity, it does not contain all detailed information on this product. The contents of this document are neither part of a previous or existing agreement, commit- ment or legal relationship, nor does it modify such.

  • Page 6: Safety Information

    2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO devices assume professional transport, storage, installa- tion, and connection, as well as careful operation and service. The devices may only be used for applications for which they are intended.
  • Page 7 Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 8 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Other- wise, the device could be damaged. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 9 Note that monitors can fail as a result of aging, and that image properties such as brightness, con- trast,and color value can change. Do not touch the monitor screen Due to mechanical pressure or electrostatic discharges, touching the screen can result in brief distur- bances to the image. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 10: Product-Specific Safety Information

    • Do not connect devices that are not part of the medical system. • If a stand is subsequently attached to the monitor, the stand must meet the require- ments of standard EN 60601 so that the system, comprising the stand and monitor, meets the requirements. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 11 Note Image quality To maintain constant image quality, EIZO recommends cleaning the monitor on a regular basis and checking image properties in accordance with all applicable local regulations. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 12: Description

    CAUTION Keep the packaging material for subsequent transport of the device. Device The CuratOR LX490W is a Full HD 49" LCD Monitor. The monitor can be installed in a ceil- ing suspension or wall mount, or a stand. Product Order number...

  • Page 13: Monitor Performance Features

    3.2 Monitor performance features 3.2 Monitor performance features The CuratOR LX490W has the following features that permit a wide range of applications: 49" large screen diagonal With a screen diagonal of 49" and a resolution of 1920 x 1080 pixels (2 MP), the LX490W is suitable for simultaneous use of several video sources.
  • Page 14 The monitor with protective screen is protected at the front against moisture (IP65 degree of protection). The space between the protective screen and the panel is sealed to prevent dust from en- tering, thus helping ensure the internal surfaces remain clean. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 15: Setup And Installation

    4 Setup and installation CAUTION Changes to device Do not make any mechanical or electric changes to the device. EIZO GmbH is not liable for changes made to the device. 4.1 Installation site Note the following conditions at the installation site. NOTICE...
  • Page 16 Ensure that such mechanical influences are avoided. Movable installation If the monitor is installed such that it can move, make sure that persons or objects in the fa- cility are not endangered by the monitor's range of movement. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 17: Installing The Monitor

    • Mounts must be tested and approved by the manufacturer for the weight to be sup- ported. • An installed stand must be sufficiently stable to withstand tilting of up to 10° without top- pling the monitor. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 18: Connecting

    CAUTION Changes to device Do not make any mechanical or electric changes to the device. EIZO GmbH is not liable for changes made to the device. CAUTION Shielding measures Follow all shielding measures in accordance with local EMC directives. If these guidelines are not observed, device malfunction may result.
  • Page 19 • Externally connected cables can represent a trip hazard. Make sure that all incoming cables are safely routed. • If the device offers strain relief mechanisms for the cables, use them to prevent unin- tended loosening of connected cables. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 20: Connector Locations

    The power switch is not covered and is freely accessible. Fig.: Rear view with cover Operating Power switch Grounding screw Connection panel buttons Fig.: Rear view without cover Note An additional protective conductor may be connected to the grounding screw. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 21: Connection Panel

    [} 37]. Signal outputs The following signal outputs are available on the connection panel. • VGA output (15-pin D-sub socket): • HD-SDI (BNC) • S video with Y/C signal (4-pin mini-DIN socket) • Composite (BNC) CuratOR LX490W Instructions for Use, 06/2017...

  • Page 22: Connecting The Signal Cable

    • When using a BNC to VGA adapter cable, the signal cables, for example, red, green, and blue, must be of the same length to prevent a loss in image quality. • Use only the cables specified by EIZO or the transmission links available from EIZO. Note Video source settings •...

  • Page 23: Connecting The Power Cable

    Only service may open the connector panel cover. Patients must not be present when the cover is open. CAUTION Connector Connectors may only be plugged in or removed by Service when the device is switched off. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 24 1. Using a suitable tool, remove the connection panel cover. 2. Connect the appliance plug to the monitor power socket. 3. The power cable can be secured using a cable grip. 4. Place the cover back on the connection panel. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 25: Commissioning

    The monitor and video source can be switched on in any order. Switch on • Switch on the monitor. – The EIZO logo appears briefly. • Switch on the video source. – If there is no signal the monitor displays a black screen.

  • Page 26: Check For Pixel Defects

    • Digital signals on the DVI-I input do not require a fine adjustment of brightness and con- trast since the signal is always displayed in an optimal manner. With a fine adjustment, it is possible that gray scales are not displayed. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 27 Please note that these settings have no impact on the calibration in the look up table: EIZO GmbH monitors are calibrated at the factory and maintain these settings: •...
  • Page 28 EDID data (Extended Display Identification Data) is read out, and the video source can detect the monitor. CAUTION Installation and parameterization of the video source Please refer to the video source manufacturer’s manual for detailed information about in- stallation and configuration of the video source. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 29: Operation

    If the device is not working properly, check the system for basic connection and operating errors before contacting service personnel. 7.1 Operator controls The CuratOR LX490W has four keys for OSD operation located in the lower right corner. Key functions The keys have the following functions within the OSD menu: Function ①...

  • Page 30: Remote Control

    Operation 7.2 Remote control 7.2 Remote control The CuratOR LX490W is delivered with a remote control. ① Standby ⑤ Down ⑨ Left ② Escape ⑥ Plus ⑩ Menu L ③ Up ⑦ Zoom ⑪ Source ④ Right ⑧ Minus ⑫ Menu R...

  • Page 31: Lock Or Unlock Osd Menu

    The image from the primary video source is displayed in the larger segment in the lower section of the window. • The other images are displayed in a smaller format in the upper section of the window. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 32 “PiP/PaP Window (2)”. • The number displayed on the right side of the OSD window indicates which window is currently active for the setting (“1”: main window, “2”: secondary window) CuratOR LX490W Instructions for Use, 06/2017...

  • Page 33: Overview Of The Osd Menu

    Note: The function is displayed only if the "Picture layout PaP, PiP, PoP" function is active within the Default: Main win- "Signal" menu. dow (1) The “Active adjustment window” establishes the win- dow for which the settings in this menu apply. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 34 Note: “Hue” may only be set for S-Video or Compos- Default: 50 ite signals. Slider control Set the color saturation for RGB and video signals. Saturation Note: This menu is not displayed for the mono- Default: 50 chrome CVBS signal. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 35: Image" Menu

    Perform auto adjust- Execute Perform auto adjustment ment... "Position", "Phase", and "Frequency" are set automatically upon confirmation of the se- lected function. Note: “Perform auto adjustment” can only be used for analog signal inputs. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 36 Set the frequency and phase of the input signal Frequency Slider control Correct potential blur in the vertical lines by adjusting the "Frequency/Phase" setting. Note: Use a vertical line in a "Pixel On/Off” test pattern to make the adjustment. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 37: Signal" Menu

    An image is not displayed again unless a signal is applied to the set source or a dif- ferent signal source is selected manually. Note: If no signal is available, the monitor does not search for other available sources. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 38 Select whether the main or secondary window serves as the synchronization window. PiP window (2) Note: The “Synchronization Window” menu is Default: Main window (1) only available when the “Picture in Picture (PiP)” setting is active. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 39 Color / Monochrome Color Switch signal between monochrome and color Monochrome If "Color" is set, a monochrome signal is dis- YPbPr/YCbCr played green. For correct gray scale represen- Default: Color tation, select the “Monochrome” setting. CuratOR LX490W Instructions for Use, 06/2017...
  • Page 40 Note: The higher the slider setting, the longer it will take for a desired timing change to occur (delayed by a number of milliseconds). CuratOR LX490W Instructions for Use, 06/2017...

  • Page 41: Lut" Menu

    LUT" OSD menu. See also "Adjust LUT" menu [} 45]. A table with information regarding the avail- able LUTs is displayed below the LUT selec- tion. Note: Select a DICOM LUT to view radio- graphic images. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 42: Info" Menu

    BL on over 350 cd/m² [h] • Source • Mode • Source signal • 2. Source • Mode • 2. Source signal • FW type • FW version • OSD version • Config version • SDK version CuratOR LX490W Instructions for Use, 06/2017...

  • Page 43: Utilities" Menu

    Top - right / Mid - left / screen area using nine predefined positions Centered / Mid - right / Bottom - left / Bottom - center / Bottom - right Default: Bottom - right CuratOR LX490W Instructions for Use, 06/2017...
  • Page 44 The source scan is interrupted as soon as the quence first source with an active video signal is found. This signal is then displayed. Reset operations Reset to firmware de- All user settings are deleted and reset to the faults... firmware defaults. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 45: Adjust Lut" Menu

    CIE (DIN 6174) Note: When "Natural" is selected, only the • value for Lmax can be changed. All other functions are hidden. • DICOM • Gamma 2.0, 2.2, 2.5, 2.7, 3.0, 3.3 • Log.Lum.linear Default: DICOM CuratOR LX490W Instructions for Use, 06/2017...
  • Page 46 When using the color setting based on the ex- isting defaults, it is also possible to individu- ally modify the color coordinates. The Y color coordinate can be adapted using the "Y" func- tion. Current target value (display only) CuratOR LX490W Instructions for Use, 06/2017...

  • Page 47: Cleaning And Maintenance

    Surfanios Fraicheur Citron (Anios Labs) Guanidine derivatives Lysoformin Quaternary compounds Incidur spray, undiluted Standard household washing- denk mit Fairy Ultra, Pril, Palmolive up liquid Pyridine derivatives Activ spray, undiluted Water Tap water Distilled water CuratOR LX490W Instructions for Use, 06/2017...

  • Page 48: Maintenance

    SMPTE image: The gray levels must be displayed correctly and visibly at both 5% and 95%. • VeriLum image: The visible display of small squares in all gray scale levels confirms the correct calibration. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 49: Troubleshooting

    USER settings can be changed. • Has the device been running for at least 20 minutes without Power Management acti- vated? Other Loose plug Connect the loose plug and secure it. Defective cable Replace the defective cable. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 50: Technical Specifications

    Miniature fuse 2 T6.3 AH: UL 248-14, 250 V (5 x 20 mm) Maximum current consumption 1.5 - 0.7 A Power consumption 85 W (typical), 144 W (max) Power consumption in Standby Mode 19 W CuratOR LX490W Instructions for Use, 06/2017...

  • Page 51: Electronics

    • Front: IP65 EN 60529 • Back: IP20 Connection panel On rear panel, under cover Weight in kg 31 kg +/- 10% Dimensions (W x H x D) in mm 1103 x 634 x 80.9 CuratOR LX490W Instructions for Use, 06/2017...

  • Page 52: Climatic Conditions

    CAN/CSA - C 22.2 60601-1:08 (Third Edition) • GB 4943.1 (non-tropical, altitude < 2000 m) Protection class Protection class I Degree of protection according to Front: IP65 EN 60529 Back: IP20 Medical product classification Class I according to 93/42/EEC, Appendix IX CuratOR LX490W Instructions for Use, 06/2017...

  • Page 53: Dimension Drawings

    Dimension drawings 11.1 View from front and side 11 Dimension drawings All dimensions in mm 11.1 View from front and side 11.2 Rear view CuratOR LX490W Instructions for Use, 06/2017...

  • Page 54: Spare Parts / Accessories

    Spare parts / accessories 12.1 Accessories 12 Spare parts / accessories 12.1 Accessories Accessories Order number Description FST4700 Black 6GF6988-8BA03 Stand, black FST4700 White 6GF6988-8BA04 Stand, white CuratOR LX490W Instructions for Use, 06/2017...

  • Page 55: Appendix

    Information and manufacturer’s declaration – electromagnetic radiation The CuratOR LX490W is intended for use in the electromagnetic environments noted below. The customer or user of the CuratOR LX490W has to ensure that the device is used in such an envi- ronment.
  • Page 56 Information and manufacturer’s declaration – electromagnetic radiation The CuratOR LX490W is intended for use in the electromagnetic environments noted below. The customer or user of the CuratOR LX490W has to ensure that the device is used in such an envi- ronment.
  • Page 57 Information and manufacturer’s declaration – electromagnetic radiation The CuratOR LX490W is intended for use in the electromagnetic environments noted below. The customer or user of the CuratOR LX490W has to ensure that the device is used in such an envi- ronment.
  • Page 58 Recommended minimum distance between portable and mobile RF communications devices and the CuratOR LX490W The CuratOR LX490W is intended for use in an electromagnetic environment in which interference due to electromagnetic radiation is controlled. The customer or user of the monitor can help prevent electromagnetic interference by maintaining the recommended minimum distance between portable and mobile RF communications devices (transmitter) and the monitor as shown below.

  • Page 59: Markings And Symbols

    Symbol for protective ground (ground) "On" symbol (voltage) "Off" symbol (voltage) Input for service calls Symbol for USB Symbol for input. Symbol for output. Symbol for direct current. Symbol "Comply with the instructions for use". CuratOR LX490W Instructions for Use, 06/2017...

  • Page 60: Warranty

    The device is in compliance with directive 2011/65/EU for limiting the use of specific haz- ardous materials in electric and electronic devices. 13.6 China RoHS (Restriction of Hazardous Substances) 液晶显示器 LCD Monitor 型号 Model: CuratOR LX490W 根据SJ/T11364-2014《电子电气产品有害物质限制使用标识要求》特提供如下有关污染控制 方面的信息。 The following product pollution control information is provided according to SJ/T11364-2014 Marking for the restriction of the use of hazardous substances in electrical and electronic product.

  • Page 61: Additional Devices

    (economically or technically) available substitutes. 产品中有毒有害物质或元素的名称及含量 Table of hazardous substances’ name and con- centration. 13.7 Additional devices Connected devices such as PCs must meet the relevant safety standards. CuratOR LX490W Instructions for Use, 06/2017...

  • Page 62: Contact

    13.9 Trademarks The EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO Corporation in Japan and other countries. RadiForce is a registered trademark of EIZO Corporation in Japan and other countries.

  • Page 63: Index

     5 Utilities menu  44 General safety instructions  6 Grounding  18 Ventilation  15 Image Quality menu  34 Image Sticking  25 Warranty  60 Info menu  42 Input  21 Installation  17 Line power  23  13 Maintenance  48 CuratOR LX490W Instructions for Use, 06/2017...
  • Page 64 Siemensallee 84 76187 Karlsruhe Germany Instructions for Use, 06/2017 CuratOR LX490W 1075737-002 Copyright © 2017 EIZO GmbH. All rights reserved.
