Zoeller X71 Series Owner's Manual

NOTICE TO INSTALLER: Instructions must remain with installation.
Your Peace of Mind is Our Top Priority
Product information presented
here reflects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies.
Register your
Zoeller Engineered Product
on our website:
http://reg.zoellerengprod.com/
X71 HAZARDOUS ENVIRONMENT SERIES CLASS
DIVISION 1, GROUP C & D SUBMERSIBLE GRINDER UNITS
Congratulations on the purchase of the Zoeller X71 Series submersible
grinder pump. This pump has been constructed in compliance with FM
and CSA testing. These requirements enable the unit to be listed as an
explosion proof pump rated for use in Class I, Division 1, Group C & D
environments. Zoeller Grinder Pumps are designed for grinding and pumping
sanitary sewage from submersible lift stations. The pump is intended to grind
and pump reasonable quantities of disposable diapers, sanitary napkins, paper
towels, rubber materials, plastics, cigarette butts and other items normally
found in sanitary sewage applications. For over sixty years the name Zoeller
has represented the standard for submersible dewatering and sewage pumps.
The same high quality workmanship and easy maintenance design has been
incorporated into this line of heavy-duty submersible grinder pumps. This Zoeller

Table of Contents

Safety Instructions ....................................................................... 1
Limited Warranty .......................................................................... 2
Preinstallation Information .......................................................... 3
Electrical Data ............................................................................... 3
Typical Sewage Installation ........................................................ 4
Pump Wiring Instructions .........................................................5-6
Operation ....................................................................................... 7
Maintenance .................................................................................. 7
Service Checklist .......................................................................... 8
Owner's Information
Model Number: _______________ Date Code: _______________
Serial Number: Pump 1_____________ Pump 2_____________
 Simplex  Panel P/N ______________________________
 Duplex  Rail System P/N ________________________
Job Name: ____________________________________________
Distributor: ____________________________________________
Sales Order Number: ____________________________________
Contractor: ____________________________________________
Date of Installation: _____________________________________
System Readings During Operation: Voltage _____ Amps _____
CLICK ANYWHERE on THIS PAGE to RETURN TO SEPTIC PUMP INSPECTION & MAINTENANCE at InspectApedia.com
®
®
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
(502) 778-2731 • 1 (800) 928-PUMP • FAX (502) 774-3624
OWNER'S MANUAL
© Copyright 2015 Zoeller
1
pump will provide years of trouble-free service when installed according to the
manufacturers' recommendations.
This manual incorporates the installation, operation, maintenance, and
service instructions into one document to aid in the ownership of a Zoeller
submersible wastewater product. Please read and review this manual before
installing the product. Follow the steps and procedures listed on ZM1074 for
a proper start-up and warranty protection. Many items contained within, when
followed correctly, will not only ensure a long and problem-free life for the pump,
but also save time and money during installation. Should further assistance be
necessary please call our Technical Service Department at 1-800-928-PUMP
(7867).

Safety Instructions

TO AVOID SERIOUS OR FATAL PERSONAL INJURY OR MA-
JOR PROPERTY DAMAGE, READ AND FOLLOW ALL SAFETY
INSTRUCTIONS IN THIS MANUAL AND ON THE PUMP.
THIS MANUAL IS INTENDED TO ASSIST IN THE INSTALLATION
AND OPERATION OF THIS UNIT AND MUST BE KEPT WITH
THE PUMP.
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the pump or in the
manual, look for one of the following signal words
and be alert to the potential for personal injury or
property damage.
Warns of hazards that WILL cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause personal injury
CAUTION
or property damage.
INDICATES SPECIAL INSTRUCTIONS WHICH ARE
VERY IMPORTANT AND MUST BE FOLLOWED.
THOROUGHLY REVIEW ALL INSTRUCTIONS AND WARNINGS
PRIOR TO PERFORMING ANY WORK ON THIS PUMP.
MAINTAIN ALL SAFETY DECALS.
REFER TO WARRANTY ON PAGE 2.
Co. All rights reserved.
®
SECTION: Z4.30.150
ZM2209
Rev. A
0515
Supersedes
0714
visit our web site:
www.zoeller.com
R
Standard 3600 & 3615
Standard 3600 Certified to CSA Standard
C22.2 No. 145
& 3615
I ,
Rev. 02/04
