iC7 Series Functional Safety
Operating Guide
Table 14: Auxiliary Voltages
Function
24 V output, functional safety (X31, X32)
7.3 Operating Conditions
Table 15: Operating Conditions for Functional Safety
Function
Operating temperature
Storage temperature
Air humidity
Operating altitude
Environmental conditions
Check the operating conditions for each drive from the product-specific design guide or operating guide. Latest versions of Danfoss
product guides are available for download at http://drives.danfoss.com/downloads/portal/.
7.4 Cable Specifications
Table 16: Cable Sizing for Connectors X31, X32
Wire type
Solid
Flexible
Flexible with ferrule w/o plastic sleeve
Flexible with ferrule w plastic sleeve
22 | Danfoss A/S © 2023.03
Data
According to the AC drive specifications.
-40 °C...+80 °C (-40 °F...+176 °F)
According to the AC drive specifications (non-condensing).
According to the AC drive specifications.
The product must be installed in an environment corresponding to EN IEC 61800-5-1:2017 PD2 –
non-condensing.
For PD2 condensing environments, the product must be installed in IP54/NEMA 12 cabinet as per
EN IEC 60529 AMD 2:2013 , or similar.
Cross section [mm
0.5-1.5 (24-16)
0.5-1.5 (24-16)
0.5-1.5 (24-16)
0.5 (24)
Output voltage
Max load
2
(AWG)] Stripping length [mm (in)]
10 (0.4)
10 (0.4)
10 (0.4)
10 (0.4)
AQ319741840653en-000201 / 136R0268
Specifications
Data
24 V ±15%
100 mA
