    User information This documentation is a part of the product. It applies to products in the standard design according to the corresponding STOBER catalog. Storage and transfer As this documentation contains important information for handling the product safely and efficiently, it must be stored in the immediate vicinity of the product until product disposal and be accessible to qualified personnel at all times.
  • Page 5: Terms

    Supporting documents Separate documents apply to the drive components which can be attached to STOBER gear units, depending on the design. These documents can be found by entering the serial number of the gear unit at https://id.stober.com...
  • Page 6: General Safety Instructions

    2 | General safety instructions General safety instructions There are risks associated with the product described in this documentation that can be prevented by complying with the described warning and safety instructions as well as the included technical rules and regulations. Intended use The drives described in this documentation are intended for installation in industrial machines or systems.
  • Page 7: Thermal Hazards

    2 | General safety instructions WARNING! Sinking or falling of gravity-loaded axes or vertical axes after switching off the motor due to gravity! Falling gravity-loaded axes or vertical axes can cause serious injuries or even death! ▪ Be aware that the holding brake of the motor does not offer sufficient safety for persons that are in the hazard area of gravity-loaded axes or vertical axes.
  • Page 8: Product Description

    3 | Product description Product description In this chapter, you can find product details that are relevant for assembly, commissioning and maintenance. Detailed technical data on your gear unit/geared motor can be found in the order confirmation. You will find more product information and dimensional drawings in the corresponding catalog (Additional documentation [} 11]).
  • Page 9: Nameplate

    3 | Product description Code Designation Design Housing Standard Shaft Flange shaft Bearing Standard bearing Reinforced bearing (PHQ4 − PHQ5) Backlash Standard Reduced (PHQ4 − PHQ9) 0880 Transmission ratio (i x 10) i = 88 (example) Motor adapter Motor adapter with EasyAdapt coupling Motor adapter with EasyAdapt coupling for large motors Motor adapter with FlexiAdapt coupling Motor adapter with FlexiAdapt coupling for large motors...
  • Page 10: Direction Of Rotation

    3 | Product description Direction of rotation The input and output rotate in the same direction. Reverse operation To ensure lubrication for circulating gearing parts during cyclic reverse operation from ± 20° to ± 90° at the output, pay careful attention to the position of the output shaft for the horizontal mounting of the gear unit, as shown in the diagrams below.
  • Page 11: Other Product Features

    Gear unit + ME/MEL/MF/MFL motor adapter Servo gear units 443054_en Gear unit + EZ synchronous servo motor EZ synchronous servo geared motors 442437_en If you have questions about your drive that are not answered by this documentation, please contact STOBER Service (Service [} 26]).
  • Page 12: Transport And Storage

    4 | Transport and storage Transport and storage STOBER products are packaged carefully and delivered ready for installation. The type of packaging depends on the product size and the transport method. Observe the following information during transport and storage: §...
  • Page 13 4 | Transport and storage Before commissioning the gear unit, reduce the lubricant fill volume to the fill volume that is specified on the nameplate of the gear unit.
  • Page 14: Installation

    This chapter contains information on how to mount a motor on a STOBER gear unit with a motor adapter. The motor adapter type of your gear unit can be found on the nameplate of the gear unit. STOBER recommends using a motor with a shaft without a feather key, since the keyway negatively affects smooth operation.
  • Page 15: Permitted Tilting Torques At The Gear Unit Input

    Permitted tilting torques at the gear unit input If you mount a STOBER gear unit on the machine in a horizontal mounting position, check that the permitted tilting torque is not exceeded on the gear unit input before mounting the corresponding motor. Information on the permitted tilting...
  • Page 16: Mounting The Motor On A Gear Unit With Me/Mel/Mf/Mfl Adapter

    Procedure In order to prevent unfavorable shifting or tilting of the motor shaft, STOBER recommends mounting the motor on the gear unit with the motor shaft pointing down vertically. 1. Position the gear unit (5), if necessary with the aid of lifting gear, with the flange shaft pointing down so that the motor can be mounted in a vertical position.
  • Page 17 5 | Installation 9. Turn the motor in an axial position to the gear unit so that the nameplates are on the same side, if possible, and can also be read after installation in the machine. 10. If the motor shaft has a keyway, position the motor shaft so that the keyway is opposite the slot of the clamping hub (10).
  • Page 18 5 | Installation Fig. 1: Mounting a motor on a planetary gear unit with flange shaft and ME motor adapter (example) Torque wrench Hexagon insert Motor adapter Planetary gear unit Adapter bushing (if present) Motor shaft Motor Screw Slot of the clamping hub Locking screw Grooved pin Screw plug...
  • Page 19: Mounting The Motor On A Gear Unit With Mb Adapter

    5 | Installation Tightening torques for the locking screw (11) Type ME/MF MEL/MFL [mm] [Nm] [mm] [Nm] PHQ431 PHQ432 PHQ531 PHQ532 PHQ731 PHQ732 PHQ733 PHQ831 PHQ832 PHQ833 PHQ942 PHQ943 PHQ1042 – – – PHQ1043 PHQ1142 – – – PHQ1143 PHQ1242 –...
  • Page 20: Mounting The Gear Unit On The Machine

    5 | Installation Prerequisites § The drive element does not cause any impermissible shaft loads (e.g. tensioning the belt on a belt drive). Information on permissible shaft loads can be found in the corresponding catalog (see Additional documentation [} 11]). § The information in the chapter Cleaning agent and solvent [} 14] is observed...
  • Page 21: Tightening Torques

    5 | Installation 4. Mount the output flange of the gear unit to the connecting structure using screws. Details on the screws can be found in the following table. 5. Tighten the screws evenly in multiple passes with increasing torque and alternating diagonally. The tightening torques can be found in the chapter Tightening torques [} 21].
  • Page 22 5 | Installation Tightening torque M [Nm] Thread Strength class 8.8 Strength class 10.9 Strength class 12.9 1057 1136 1329 1176 1674 1959 1597 2274 2662 2778 3957 4631 Tab. 5: Tightening torques for screws with metric standard thread in accordance with DIN 13-1 (coefficient of friction µ 0.14).
  • Page 23: Commissioning

    The maximum surface temperature occurs in approx. 3 hours, depending on the utilization of the drive, and must not exceed the maximum value of 90 °C in the event of a maximum surrounding temperature. Immediately shutdown the drive if the maximum value is exceeded and contact STOBER Service.
  • Page 24: Servicing

    7 | Servicing Servicing Cleaning If the surface of the gear unit/geared motor is dirty, sufficient heat dissipation through the ambient air is no longer possible. As a result, impermissibly high operating temperatures could occur, which reduce the lubricating effect of the lubricant and accelerate its aging.
  • Page 25: Remedying Faults

    Servicing Have the necessary servicing work carried out on the drive by the STOBER Service department or by STOBER service partners. Be aware that improper servicing may cause material damage and may void the manufacturer's warranty. Only use replacement parts delivered by STOBER. Specify the type designation and serial number of the drive when...
  • Page 26: Service

    7 | Servicing Service If you contact STOBER Service, have the following information ready: § Serial number and type designation of the drive according to the nameplate § Type of fault and surrounding circumstances § Presumed cause § If possible, digital photo of the drive or a video recording of the drive in the context of the fault Contact data of parent company in Germany STÖBER Antriebstechnik GmbH + Co.
  • Page 27: Removal And Disposal

    8 | Removal and disposal Removal and disposal Removal WARNING! Moving machine parts can cause serious injuries or even death! Before performing work, switch off the machine with the main switch and secure the switch from being turned on again. WARNING! Falling gravity-loaded axes or vertical axes can cause serious injuries or even death! Move gravity-loaded axes or vertical axes to their lowest position and lock or brace them mechanically before entering the danger area.
  • Page 28 443353_en.00 02/2023 STÖBER Antriebstechnik GmbH + Co. KG Kieselbronner Str. 12 75177 Pforzheim Germany Tel. +49 7231 582-0 mail@stoeber.de www.stober.com 24 h Service Hotline +49 7231 582-3000 www.stober.com...
