COMBINATION STEAM OVEN
PROFESSIONAL
OS30NPX1 models
INSTALLATION GUIDE
US CA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OS30NPX1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher & Paykel OS30NPX1

  • Page 1 COMBINATION STEAM OVEN PROFESSIONAL OS30NPX1 models INSTALLATION GUIDE US CA...
  • Page 2: Safety And Warnings

    SAFETY AND WARNINGS General  WARNING! Save these instructions for the local inspectors use. Please make this information available to the person installing the appliance – doing Electric Shock Hazard so could reduce your installation costs. Failure to follow this advice may result in This oven is to be installed and connected to the electricity supply only by an authorized person.
  • Page 3: During Installation

    INSTALLATION CONSIDERATIONS COMPONENTS REQUIRED PRIOR TO INSTALLATION PARTS SUPPLIED Prior to installing your oven, ensure the following: Keep all packing materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected The countertop and oven cavity are square and level, and are the required dimensions.
  • Page 4: Product Dimensions

    PRODUCT DIMENSIONS Power location OS30 MODELS PRODUCT DIMENSIONS A Overall height 18 1/2 B Overall width 29 13/16 C Overall depth (excluding handles and dials) 22 5/16 ISOMETRIC PLAN D Height of chassis 17 9/16 E Width of chassis 25 3/8 F Depth of chassis 20 13/16 G Depth of oven frame and control panel...
  • Page 5 CABINETRY DIMENSIONS (FLUSH INSTALL) Ventilation of 2" x 22 1/16" (50x560mm) or totalling 43.4in (280cm ) is required for companion products. The air vent must be located at the rear of cabinet, it can be positioned at the base, top, sides, or back of the cavity.
  • Page 6 CABINETRY DIMENSIONS (PROUD INSTALL) Ventilation of 2" x 22 1/16" (50x560mm) or totalling 43.4in (280cm ) is required for companion products. The air vent must be located at the rear of cabinet, it can be positioned at the base, top, sides, or back of the cavity.
  • Page 7: Electrical Connection

    ELECTRICAL CONNECTION SECURE THE OVEN TO THE CABINETRY Before connecting the oven to the mains power supply, check that: specifications of the electrical system match with what is detailed on this section. system has an effective ground connection compliant with current standards and laws. The ground connection is required by law.
  • Page 8 ATTACH THE LOWER TRIM TO THE OVEN Attach the lower trim to the oven after installing the oven in the cabinetry. Align the lower trim with the tabs on the base of the oven. Use the supplied screws to attach the lower trim to the tabs.
  • Page 9: Installer Checklist

    INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER … … Make sure the oven is level and securely fitted to the cabinetry. Turn the power to the oven on. The display should turn on.. … … Check the lower trim is correctly attached and undamaged. Have you demonstrated basic operation to the customer? …...
  • Page 10 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2023. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
  • Page 11 FOUR AVEC COMBINAISON DE VAPEUR PROFESSIONNEL Modèles OS30NPX1 GUIDE D’INSTALLATION...
  • Page 12: Consignes De Sécurité Et Mises En Garde

    CONSIGNES DE SÉCURITÉ ET MISES EN GARDE Entretien  MISE EN GARDE! Ne réparez ou remplacez aucune pièce de cet appareil, à moins que ce ne soit spécifiquement recommandé dans le guide d’utilisation. Tous les autres travaux doivent être effectués par un Risque de choc électrique technicien de service formé...
  • Page 13: Pendant L'installation

    À PRENDRE EN CONSIDÉRATION POUR L’INSTALLATION PIÈCES REQUISES AVANT L’INSTALLATION PIÈCES FOURNIES Avant d’installer votre four, veuillez vous assurer des points suivants : Conservez tous les matériaux d’emballage jusqu’à ce que vous terminiez l’inspection de l’appareil. La cavité du four et le comptoir sont de niveau et bien droits, avec les dimensions requises. Inspectez le produit pour vous assurer qu’aucun dommage n’a été...
  • Page 14: Dimensions Du Produit

    DIMENSIONS DU PRODUIT Emplacement du cordon d’alimentation MODÈLES OS30 DIMENSIONS DU PRODUIT A Hauteur hors tout 18 1/2 B Largeur hors tout 29 13/16 C Profondeur hors tout (excluant les poignées 22 5/16 et les boutons) D Hauteur du châssis 17 9/16 EN PLAN ISOMÉTRIQUE E Largeur du châssis 25 3/8...
  • Page 15 DIMENSIONS DES ARMOIRES (INSTALLATION ENCASTRÉE) Une ouverture de ventilation de 2 po x 22 1/16 po (50 x 560 mm) ou totalisant 43,4 po (280 cm ) est requise pour les produits complémentaires. La sortie d’air doit être située à l’arrière des armoires; elle peut être positionnée à la base, dans le haut, sur les côtés ou à...
  • Page 16 DIMENSIONS DES ARMOIRES (INSTALLATION SUPERPOSÉE) Une ouverture de ventilation de 2 po x 22 1/16 po (50 x 560 mm) ou totalisant 43,4 po (280 cm ) est requise pour les produits complémentaires. La sortie d’air doit être située à l’arrière des armoires; elle peut être positionnée à la base, dans le haut, sur les côtés ou à...
  • Page 17: Raccordement Électrique

    RACCORDEMENT ÉLECTRIQUE FIXEZ LE FOUR AUX ARMOIRES Avant de raccorder le four à l’alimentation électrique, vérifiez que : les caractéristiques du système électrique correspondent à celles indiquées dans cette section. le système possède un raccordement de mise à la terre approprié, conforme aux normes et réglementations en vigueur.
  • Page 18 FIXEZ LA MOULURE INFÉRIEURE AU FOUR Fixez la moulure inférieure au four après avoir installé le four dans les armoires. Alignez la moulure inférieure avec les languettes sur la base du four. Utilisez les vis fournies pour fixer la moulure inférieure aux languettes. Veillez à...
  • Page 19: Liste De Vérification De L'installateur

    LISTE DE VÉRIFICATION DE L’INSTALLATEUR À ÊTRE REMPLIE PAR L’INSTALLATEUR … … Assurez-vous que le four est de niveau et fixé solidement aux armoires. Activez l’alimentation du four. L’afficheur doit s’activer. … … Vérifiez que la moulure inférieure est correctement fixée et qu’elle n’est pas Avez-vous expliqué...
  • Page 20 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2023. Tous droits réservés. Les modèles illustrés dans ce guide peuvent ne pas être disponibles dans tous les pays et sont sujets à modifications sans préavis. Les caractéristiques de produit présentées dans ce guide s’appliquent aux modèles et produits spécifiques qui y sont décrits à...
