COMBINATION STEAM OVEN
OS30NPTX1, OS30NDTDX1, OS30NDTDB1, OS30NMTDB1,
OS30NMTDG1, OS30NDLX1 models
INSTALLATION GUIDE
US CA

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher & Paykel 9 Series

  • Page 1 COMBINATION STEAM OVEN OS30NPTX1, OS30NDTDX1, OS30NDTDB1, OS30NMTDB1, OS30NMTDG1, OS30NDLX1 models INSTALLATION GUIDE US CA...
  • Page 2 SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains electricity supply.
  • Page 3 SAFETY AND WARNINGS READ AND SAVE THIS GUIDE WARNING! To avoid hazard, follow these instructions carefully before installing or using this appliance. Please make this information available to the person installing the appliance—doing so could reduce your installation costs. This appliance must be installed and connected to the mains power supply only by a suitably qualified person according to these installation instructions and in compliance with any applicable local building and electricity regulations.
  • Page 4 COMPONENTS REQUIRED TOOLS Supplied Powered driver Cross-head screwdriver PARTS Supplied Metal side shelves fixing nut (2) #7x13 pan head screws (2) All imagery shown in this guide is representative. Your product may differ.
  • Page 5 ACCESSING YOUR PRODUCT SPECIFICATIONS For full product, cabinetry and service specifications, refer to the Planning Guide. To access the Planning Guide, scan the QR code or visit fisherpaykel.com/specify. Search by appliance type, product name or model code. INCHES min. 17 3/4 min.
  • Page 6 PRIOR TO INSTALLATION Ensure that: the oven cavity is square and level based on the required dimensions the installation will comply with all clearance requirements and applicable standards and regulations the isolating switch will be easily accessible to the customer with the oven installed the cable may enter the cavity from the side, top or bottom, but top entry must be at the rear of the cavity the oven connection socket is outside the cavity if the oven is flush to the rear wall...
  • Page 7 SERVICES This oven must be connected to the mains power supply only by a suitably This oven must be connected to the mains power supply only by a suitably qualified person. qualified person. This oven must be earthed. This oven must be earthed. Before connecting the oven to the mains power supply, check that: the domestic wiring system is suitable for the power drawn by the oven (as specified on the rating plate).
  • Page 8 CHECK CAVITY 1. Measure cavity dimensions. Ensure all minimum specifications have been met. Refer to the planning guide for details. For dark cabinetry, ensure clashing has been considered and installed. fisherpaykel.com/specify 2. Ensure service access complies with local requirements. 3. Ensure cavity ventilation has been set up correctly.
  • Page 9 UNPACK PRODUCT Do not lift or move the product using the door handle. Keep all packing materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you brought the product from to report the damage.
  • Page 10 REMOVE DOOR 1. Open the door and remove all cable ties and packaging holding the oven shelves in place. 2. Grip the shelves at the front, making sure to hold the wire shelf and frame together. Lift upwards and pull out from the oven.
  • Page 11 CONNECT POWER THREE WIRE CONNECTION 1. Disconnect the power supply and remove the junction box cover. 2. Connect the oven cable to the junction box through the U.L-listed conduit connector. 3. Connect the two black wires together with twist-on connectors and the two red wires together with twist-on connectors.
  • Page 12 CONNECT POWER 4. Connect electrical connection according to local codes and ordinances. If local codes DO NOT PERMIT connecting the cabinet-grounding conductor to the neutral (white) wire in junction box. 5. Seperate the factory- taped green and white oven cable wires. If junction box is grounded, connect the green wire to the metal junction box with a screw before connecting...
  • Page 13 CONNECT POWER If local codes permit connecting the cabinet-grounding conductor to the neutral (white) wire in junction box. 5. Connect the factory-taped green and white oven wires to the neutral (white) wire in the junction box. 6. Replace the junction box cover.
  • Page 14 CONNECT POWER FOUR WIRE CONNECTION 1. Disconnect the power supply and remove the junction box cover. 2. Connect the oven cable to the junction box through the U.L-listed conduit connector. 3. Connect the two black wires together with twist-on connectors and the two red wires togeher with twist-on connectors.
  • Page 15 CONNECT POWER 4. Connect electrical connection according to local codes and ordinances. 5. Seperate the green and white oven cable wires. Connect the white oven cable wire to the neutral (white) wire in junction box. 6. Connect the green grounding oven cable wire to the (green) grounding wire in the junction box.
  • Page 16 POSITION OVEN IN CAVITY 1. Some models only* For dark cabinetry, the supplied trim can be used to enhance clashing finish. To install, remove the trim adhesive and press to secure to cavity. 2. Ensure control panel is closed. Lift product into cavity taking care not to lift from the control panel.
  • Page 17 REFIT DOOR 1. Holding the door on both sides, carefully lift door back onto the hinges 2. Open the door fully and push each locking lever down and lock into place. 3. Ensure both hinges are fully locked before shutting the door.
  • Page 18 ALIGN AND SECURE 1. Align oven with surrounding cabinetry and appliances. 2. Using the product as a guide, pre-drill 2 x 3mm pilot holes. 3. Secure oven to cavity using the 2 x #7x13 pan head screws provided.
  • Page 19 REFIT SHELVES Sliding shelves Place shelves back into the oven at the desired level. Ensure shelves are level and correctly positioned with the guard rail at the back. Wire shelves Slide shelves into the cavity. Clip on sliding shelf supports Ensure the slides are positioned the correct way around, with the triangular tab at the front.
  • Page 20 ALIGN AND SECURE 1. Follow the guidance on screen to ensure oven turns on and heats correctly. Refer to your User Guide for more information.
  • Page 21 INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Ensure the oven is level and securely fitted to the cabinetry. Open the oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation.
  • Page 23 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2024. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
