G528 Quick Start Guide

LOG INTO THE ROUTER

Note: The DHCP client must be enabled on your computer to
obtain a valid IP address from the router. Refer to your computer's oper-
ating system documentation if you need details.
To connect using Wi-Fi: In the computer's Wi-Fi network settings, select
the router's Wi-Fi access point SSID and click Connect.
Enter the default WPA/WPA2 key when prompted.
To connect using Ethernet: Attach one end of a Cat5 cable to the unit's
LAN port and the other end to the computer's LAN port.
1. To log into the Web Admin interface, open a web browser and type
the unit's LAN IP address, 192.168.1.1, in the URL field.
2. Enter the Web Admin default user name and password.
Note: Change the initial password for both the root and admin users
before configuring the router.

QUICK SETUP

To configure the network interfaces:
1. Log into the Web Admin, and click Quick Setup.
2. On the Network Setup page, you can configure the LAN, WAN,
Cellular and Wireless LAN (access point) network interfaces.
3. To complete the SIM card configuration, scroll down the page to
the Cellular section. On the General Settings tab, make sure that
the Primary SIM selection is SIM1, matching the slot where the SIM
card was inserted. Then click the SIM1 Settings tab and check that
the APN value matches the APN printed on the SIM Activation
Insert, or enter it if necessary.
4. Click Save & Apply.
Note: Use the Lantronix Connectivity Services SIM Management Portal
to manage the provided SIM card.

LANTRONIX SERVICES

Scan for product information
www.lantronix.com/mylantronix/
© 2023 Lantronix, Inc. Lantronix is a registered trademark of Lantronix, Inc. All other trademarks are the property of their respective
owners. Specifications subject to change without notice. 895-0051-00 Rev. B

Default Credentials

Access Point SSID
Parameter Default Value
SSID Lantronix-<model>-<serial-number>
WPA/WPA2 Key W1rele$$
Web Admin Console
User name Default Password
admin admin
root L@ntr0n1x
Technical Support Visit
2
IoT Cellular Gateway
www.lantronix.com/technical-support
