Description

The Torit PowerCore CPV collector is a continuous duty
dust collector that uses obround style filter packs with
the proprietary axial flow PowerCore filter media. The
system is designed to provide optimum performance for
high efficiency, low operating pressure drop (energy
usage) within a small size collector. The filters can be
pulse-cleaned on- or off-line. Standard sizes range from
1 to 12 obround filter packs.
The Torit PowerCore CPV is not designed as a "stand
alone" collector. Rather, it is designed to be a filtration/
ventilation component of another component, such
as a silo or bin container. The open bottom of the
Torit PowerCore CPV is intended for roof mounting
applications. Some preparation work may be required
before installing the collector. An opening in the silo or
storage bin must have the correct dimensions and be
properly reinforced to support the weight of the Torit
PowerCore CPV. Reference the Rating and Specification
Information.
Torit PowerCore, CPV-1 to CPV-12

Purpose and Intended Use

personal injury.
Do not misuse or modify.
Discuss the use and application of this equipment with a
Donaldson Torit representative.
In pneumatic conveying systems, Torit PowerCore CPV
can be mounted on the top of silos or storage vessels
to separate the product conveying from displaced air to
prevent product loss and nuisance dust. In mechanical
conveying systems, the dust generated by product
loading, transfer, and discharge can be controlled using
Torit PowerCore CPV on an enclosure. The collected
dust returns directly to the product conveyed making
expensive ductwork systems unnecessary, saving space,
and eliminating dust disposal issues.
Torit PowerCore CPV collectors can be integrated with
process machinery requiring dust control such as fluid
bed reactors, mixers, blenders, mills, and crushers. They
can also be used in bulk materials handling applications
and for bin venting. The CPV model is commonly used in
the grain, chemical, mineral, plastic, wood, composites,
paper, packaging, and textile industries.
Misuse or modification of
this equipment may result in
