Installation,
Operation, Service,
and Replacement
Parts Information
Throughout this manual,
statements indicating
precautions necessary to
avoid equipment failure are
referenced in a Note. Statements
indicating potential hazards that
could result in personal injury or
property damage are referenced
in a Caution! box.
I I nstallation
and Operation Manua l l
Remote Weld Bench
Models RWB-2000 and RWB-3000
This manual is the property of the owner. Leave with the unit when set-up and
start-up are complete. Donaldson Company reserves the right to change design
and specifications without prior notice.
IOM 9421701
Revision 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Donaldson Torit RWB-2000
Summary of Contents for Donaldson Torit RWB-2000
- Page 1 I I nstallation and Operation Manua l l Installation, Remote Weld Bench Operation, Service, Models RWB-2000 and RWB-3000 and Replacement Parts Information Throughout this manual, statements indicating precautions necessary to avoid equipment failure are referenced in a Note. Statements indicating potential hazards that This manual is the property of the owner.
- Page 2 Donaldson Company, Inc. Caution! Application of Dust Control Equipment Combustible materials such as buffing lint, paper, wood, aluminum or steel dust, weld fume, or flammable solvents represent fire or explosion hazards. Use special care when selecting and oper- ating all dust or fume collection equipment when combustible materials are present to protect workers and property from damage due to fire and/or explosion.
-
Page 3: Table Of Contents
Remote Weld Bench, Models RWB-2000 and RWB-3000 Table of Contents Introduction ......5 Figure 1, Typical Installation ....4 Operational Explanation . - Page 4 Donaldson Company, Inc. swing door weld work surface 3/4" NPT sprinkler coupling panel collar pack for duct connection maintenance access panel Figure 1, Typical Remote Weld Bench Installation...
-
Page 5: Introduction
The Remote Weld Bench is an optional accessory hazard. for dust collection systems. Standard models are the RWB-2000, which is a 2000 cfm unit for use with 2000 cfm dust collectors, and the RWB-3000, a 3000 cfm unit for use with 3000 cfm dust collec- tors. -
Page 6: Installation
The RWB-2000 and RWB-3000 are normally Each Remote Weld Bench is shipped fully assem- shipped by common carrier and should be careful- bled from the factory. The RWB-2000 weighs ly inspected for damages that may occur en route. approximately 600-lbs. The forklift must be able Any damage should be noted and the carrier noti- to safely lift the unit. -
Page 7: Collar Pack
Collar Pack Swing Door Each Remote Weld Bench has a right and left, lift- The RWB-2000 has three collar pack sizes; 8, 10, and 12-inch ID. The RWB-3000 has two collar off swing door. This feature accommodates long pack sizes; 10 and 12-inch ID. Make sure to use and awkward workpieces. -
Page 8: Service
Donaldson Company, Inc. Service Scheduled Maintenance (See Figure 4) 1. Remove the welding work surface by lifting at 5. Reinstall welding work surface, maintenance the eyebolts. See Figure 4, Scheduled access panel, and backdraft panel. Maintenance. 6. Regular dust removal in the maintenance sched- 2. -
Page 9: Troubleshooting Guide
Remote Weld Bench, Models RWB-2000 and RWB-3000 Troubleshooting Trouble Possible Cause Remedy Insufficient airflow 1. Fan not working a. Incorrect fan When adding the Remote Weld Bench to an existing dust collection system, make sure the duct system is capable of handling the losses and the remote bench pressure losses. -
Page 10: Replacement Parts List
Donaldson Company, Inc. Replacement Parts List Parts Drawing 1, Remote Weld Bench... - Page 11 Remote Weld Bench, Models RWB-2000 and RWB-3000 Item Part Number Description Model 8PP 7555803 Light Fixture, Wrap Around, 60 Hz RWB-2000 8PP 7555805 Light Fixture, Wrap Around, 60 Hz RWB-3000 8PP 4020101 Lift-off Hinge, Right-hand 6MM 9322702 Swing Door, Right 2SG 2723104 Collar Pack, 8”...
-
Page 12: Warranty
Limited Warranty Donaldson warrants to the original purchaser that the major structural components of the goods ® will be free from defects in materials and workmanship for ten (10) years from the date of ship- ment, if properly installed, maintained and operated under normal conditions. Donaldson warrants all other Donaldson built components and accessories including Donaldson Airlocks, TBI Fans, TRB Fans, Fume Collector products and Donaldson built Afterfilter housings for twelve (12) months from date of shipment.
