Installation,
Operation and
Service Information
Throughout this manual
statements indicating
precautions necessary
to avoid equipment failure are
referenced in a Note. Statements
indicating potential hazards that
could result in personal injury or
property damage are referenced
in a CAUTION! box.
Illustrations in this manual are for
reference only, as actual product
may vary.
Installation
and Operation Manual
Modular MediaFilter
Source Collectors
Models HS-1A, HS-1B, HS-2A, and HS-2B
This manual is property of the owner. Leave with the unit when set-up and
start-up are complete. Donaldson Company reserves the right to change design
and specifications without prior notice.
™
– Horizontal Series –
IOM AD3027201
Revision 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Donaldson Torit Horizontal Series
Summary of Contents for Donaldson Torit Horizontal Series
- Page 1 Installation and Operation Manual ™ Installation, Modular MediaFilter – Horizontal Series – Source Collectors Operation and Models HS-1A, HS-1B, HS-2A, and HS-2B Service Information Throughout this manual statements indicating precautions necessary to avoid equipment failure are referenced in a Note. Statements...
- Page 2 Donaldson Company, Inc. CAUTION! Application of Mist Control Equipment • Combustible materials such as buffing lint, rouge, aluminum and steel dust, weld fume, or flammable solvents represent fire or explosion hazards. Use special care when selecting and operating all mist collection equipment when combustible materials are present to protect workers and property from damage due to fire and/or explosion.
-
Page 3: Table Of Contents
This manual contains specific precautionary statements relative to worker safety. Read thoroughly and comply as directed. Discuss the use and application of this equipment with a Donaldson Torit representative. Instruct all personnel on safe use and maintenance procedures. Data Sheet... -
Page 4: Description
Modular MediaFilter— mist such as oil- or water-soluble, and synthetic Horizontal Series collectors are widely used in coolant from machining operations. Two stages of machine tool operations where metalworking fluids filtration plus an optional HEPA filter provide a are used. -
Page 5: Rating And Specification Information
Modular MediaFilter – Horizontal Series – Source Collectors Rating and Specification Information dirty-air inlet lift and turn latches with cover plate both sides lift-off hinge dirty-air inlet with clean-air cover plate outlet motor and blower access Modular MediaFilter – Horizontal Series – Source Collector... -
Page 6: Operation
Donaldson Company, Inc. Operation Smaller mist droplets pass to a second-stage During normal operation, contaminated air enters fiberglass vee-bag filter. The vee-bag’s open pleat the unit through one of the two side inlet collars. design and precise bag spacing allows contaminant The dirty-air plenum is designed to reduce the loading throughout the life of the filter. -
Page 7: Inspection On Arrival
Modular MediaFilter – Horizontal Series – Source Collectors Inspection on Arrival Installation 1. Inspect unit on delivery. Site Selection, Ceiling-Mounted Units 2. Report any damage to the delivery carrier. 1. The unit can be suspended or hung from 3. Request a written inspection report from the overhead supports. -
Page 8: Electrical Wiring
Donaldson Company, Inc. Electrical Wiring Rigging Instructions Suggested Tools & Equipment CAUTION! Crane or Forklift Socket Wrenches, metric • Electrical installation must be Slings, Spreader Bars, End Wrenches, metric performed by a qualified electrician and Clevis Pins Level and comply with all applicable Drift Pins Drill and Drill Bits national and local codes. -
Page 9: Standard Equipment
Modular MediaFilter – Horizontal Series – Source Collectors Standard Equipment Ceiling Mount 1. Position the unit as close to the mist source as 6. Insert rod with washer and hex nut through the possible allowing optimum extraction air ceiling mount bracket from the bottom up. -
Page 10: Magnehelic Gauge
Donaldson Company, Inc. Magnehelic Gauge The Magnehelic is a differential pressure gauge 3. Place a piece of wood behind the drill location used to measure the pressure difference between in the dirty-air chamber to protect the filters the clean- and dirty-air chambers and provides a from damage by the drill bit. -
Page 11: Inlet Collar
Modular MediaFilter – Horizontal Series – Source Collectors Inlet Collar 6. Mount the gauge and bracket assembly to the 1. Remove the inlet cover plate. supporting structure using two, self-drilling 2. Apply the 1/2 x 1/16-in gasket toward the inside screws. -
Page 12: Electrical Connection
Donaldson Company, Inc. Electrical Connection 1. Mount the control box in a convenient, All the Modular MediaFilter –Horizontal Series accessible location. source collectors must be equipped with a customer-supplied safety disconnect with short 2. Make the wiring connections to the fan motor... -
Page 13: Preliminary Start-Up Check
Modular MediaFilter – Horizontal Series – Source Collectors Preliminary Start-Up Check Optional Equipment 1. Check all electrical connections for tightness Drain Collection Container and contact. 2. Check for and remove all loose items in or near 1. Install the drain collection container during the inlet and outlet of the unit. -
Page 14: P-Trap Or Y-Strainer Installation
Donaldson Company, Inc. P-Trap or Y-Strainer Installation First-Stage Filters 1. Install the 1 1/2-in NPT pipe as shown below. An optional 4-in metal mesh filter is available for heavy liquid-load applications. This is a permanent, 2. Plumb the P-Trap to a receptacle or install a reusable filter and may need periodic cleaning. -
Page 15: Service Information
Modular MediaFilter – Horizontal Series – Source Collectors Service Information Operational Checklist Second-Stage Vee-Bag Filter Replacement 1. Open the two filter access doors. 1. Monitor overall performance of the collector. 2. Remove the vee-bag filter’s support rod by 2. Monitor exhaust. Exhaust should remain lifting the rod from its retaining brackets. - Page 16 Donaldson Company, Inc. Dirty-Air Inlet Hopper P-Trap with Y Strainer, Screen Cleaning 1. Clean hopper by scraping the particulate out. 1. Place a suitable container under the screen clean-out valve, turn the collector OFF, close 2. Do not allow particulate to fall into drain. the P-trap valve, then open the screen clean-out valve.
- Page 17 Modular MediaFilter – Horizontal Series – Source Collectors P-Trap with Y-Strainer, Screen Removal Drain Collection Container 1. Close the P-trap valve. 1. Turn unit OFF. 2. Unscrew the screen cap and pull the screen out. 2. Remove the container by unscrewing the container from the cap.
- Page 18 Donaldson Company, Inc. Split Taper™ Bushing Mounting Instructions Many fans are furnished with split taper bushings Split Taper Bushing for mounting the impeller to the shaft. When properly assembled, the bushings grip the hub with ® BROWNING Split Taper Bushed a positive clamping action.
-
Page 19: Troubleshooting
Modular MediaFilter – Horizontal Series – Source Collectors Troubleshooting i f i s ' r a l i l l a . t l l l a , r e t s i f r i i t c i t c... - Page 20 Donaldson Company, Inc. Troubleshooting, continued c i f f r i i l e l l a t c i l a i . s i s r i s - t t l i t l i e t l .
-
Page 21: Service Notes
Modular MediaFilter – Horizontal Series – Source Collectors Service Notes i v r... - Page 22 Donaldson Company, Inc. Service Notes, continued i v r...
-
Page 24: Warranty
FITNESS FOR A PARTICULAR PURPOSE, WHETHER EXPRESS OR IMPLIED ARE HEREBY EXPRESSLY EXCLUDED AND DISCLAIMED. Parts and Service For genuine Donaldson Torit replacement filters and parts, call the Parts Express Line Donaldson Company, Inc. is the leading designer and manufacturer of dust, mist, and fume collection equipment used to control industrial-air pollutants.
