  • Page 1 VNA-CPS300 KOMFORT-STROMSCHALTER COMFORT POWER SWITCH...
  • Page 2 FUNCTIONAL DESCRIPTION With the comfort power switch VNA-CPS300 it is possible to operate your naviceiver or car radio even when the ignition is switched off. Additional connected devices such as Cameras, audio amplifiers or active antennas can also be integrated via the cable harness.
  • Page 3 SWITCH HOUSING Diameter: 23 mm Depth total: 27 mm Mounting diameter: 21 mm Mounting depth: 23 mm Installation in the dashboard REVERSE* ACTIVE* VNA-KT-DCA* CAMERA POWER* ACTIVE* AMP TURN* To the ISO connector To the ISO socket of of the vehicle the naviceiver/radio Green plug in fuse box on Fiat Ducato platform (Type 250/290)
  • Page 4 ESX Car Media Systems · Audio Design GmbH Am Breilingsweg 3 · D-76709 Kronau/Germany Tel. +49 7253 - 9465-0 · Fax +49 7253 - 946510 www.esxnavi.de - www.audiodesign.de © All Rights Reserved...
