Attach The Rear Wheels - HOMCOM BMW i4 Owner's Manual With Assembly Instructions

5
6
Remove all the parts from the rear axle.
1-2. Fit the wheel driver to the wheel. Insert and tigthen three Ø4x16 screws to secure
the wheel driver to the wheel.
3. Slide the wheel onto the rear axle (Left Side). Keep the wheel driver match up with
the gear box on the rear axle.
4. Slide a Ø10 washer onto the rear axle.
5. Tighten a lock nut to the end of the rear axle with a spanner.
Repeat the above procedure to assemble the other Rear Wheel.
HINT: An extra spanner has been provided to hold the Lock Nut on the other side of the
rear axle while tightening the Lock Nut on the other side.
6. Fit the hub caps to the wheels.
Attach the Rear Wheels │ 5
2
1 1
3
4
Rear Bottom View
Rear gear boxes Rear gear boxes
