Officially
Licensed Product
BENTLEY MULSANNE
BATTERY POWERED RIDE-ON
Styles and colo(u)rs may vary.
Made in China.
The owner's manual contains important safety information as well as assembly, use and
maintenance instructions.
The Ride-on Car must be assembled by an adult who has read and understands the
instructions in this manual.
Keep the package away from children and dispose of properly before use.
Keep this manual for future reference.
ASSEMBLY INSTRUCTION
1/16
EN
INfmd001_UK
370-210V70
Advertisement
Table of Contents
Related Manuals for HOMCOM BENTLEY MULSANNE
Summary of Contents for HOMCOM BENTLEY MULSANNE
- Page 1 INfmd001_UK 370-210V70 Officially Licensed Product BENTLEY MULSANNE BATTERY POWERED RIDE-ON Styles and colo(u)rs may vary. Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual.
-
Page 2: Specifications
About Your New Ride-On │ 1 On the purchase of your new Ride-On. This ride-on will provide your child with many miles of riding enjoyment. To help ensure a safe ride we ask you to please read this manual carefully, and keep it for future reference. -
Page 3: User Notice
User Notice │ 2 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED. • Always remove protective material and poly bags and dispose before assembly. -
Page 4: Parts Diagram
Parts Diagram │ 3 HINT: Some parts shown are assembled on both sides of vehicle 4/16... -
Page 5: Parts List
Parts List │ 4 PART REMARKS PART NAME Q’ty (pcs) Vehicle body Ø12 washer Wheel Placed on the front and rear axle. Lock nut Hubcap Side mirror Bently hood emblem Windshield Steering wheel Placed on the steering wheel M5x35 machine screw Placed on the steering wheel Ø5 nut Seat... -
Page 6: Attach The Rear Wheels
Attach the Rear Wheels │ 5 Rear Bottom View Remove all the parts from the rear axle. 1-2. Fit the wheel driver to the wheel. Insert and tigthen four Ø4x16 screws to secure the wheel driver to the wheel. 3. Slide the rear wheel onto the rear axle (Left Side). Keep it match up with the gear box on the rear axle. -
Page 7: Attach The Front Wheels
Attach the Front Wheels │ 6 Front Bottom View Remove all the parts from the front axle. 1. Slide a Ø12 washer onto the front axle. 2. Slide a wheel onto the front alxe. 3. Slide a Ø12 washer onto the front axle. 4. -
Page 8: Attach The Steering Wheel
Attach the Steering Wheel │ 7 HINT: If the steering wheel of your vehicle equipped with the sound function, please follow the steps 1-4 to add the batteries (Not Included), and refer to the battery information on page 2. 1. With a screwdriver loosen the screw on the battery cover located in the center of the steering wheel. -
Page 9: Connect The Power Supply
Connect the Power Supply │ 8 Rear Top View Red battery connector Red vehicle connector 1. Plug the vehicle connector into the connector on the battery. 9/16... - Page 10 Attach the Motor hood & the Seat │ 9 1. Fit the motor hood over the motor. 2. Insert four Ø4x16 screws and tighten. Repeat for the other Motor Hood. 3. Fit the tabs on the seat back into the grooves on the rear of the vehicle.
- Page 11 Attach the Windshield, Side Mirrors, Bently Hood Emblem │ 10 1. Fit the tabs windshield into the grooves on the vehicle. Press until you hear it “click” into place. 2. Fit the side mirrors to the holes on the both doors, push until you hear them “click” into place.
- Page 12 Use Your Ride-on │ 11 1. Power button: Turns the product on and off. 2. Foot pedal: Applies power (speed) to the product. ● To move the product, press the pedal down. ● To brake or slow down, release pressure from the pedal. 3.
-
Page 13: Battery Disposal
Charging │ 12 WARNING! • ONLY an adult is allowed charge and recharge the battery! • This product with Charging Protection: when charging, all functions will be cut off. • The POWER SWITCH (BUTTON) must be turned in OFF position when charging. •... -
Page 14: Troubleshooting Guide
Troubleshooting Guide │ 13 Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other. If wires are loose around the motor are loose contact your distributor please. - Page 15 Maintaining │ 14 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge, cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.
- Page 16 Our products are suitable for ASTM F963; GB6675; EN71 and EN62115 standard. 16/16...
