R-410A
ZR SERIES
6-1/2 - 12-1/2 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 15
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Optional Gas Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Checking Air Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1 ZR078-150 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . .7
2 Weights and Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZR078-150 Unit Accessory Weights . . . . . . . . . . . . . . . . . 9
4 ZR078-150 Unit Physical Dimensions . . . . . . . . . . . . . . .10
5 ZR078-150 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . .10
6 Side Duct Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
8 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
9 ZR078-150 Physical Data . . . . . . . . . . . . . . . . . . . . . . . .26
10 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . .28
11 Gas Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
12 Gas Pipe Sizing - CapacIty of Pipe . . . . . . . . . . . . . . . . .29
13 Gas Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . .30
14 Supply Air Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
15 Altitude/Temperature Correction Factors . . . . . . . . . . . . .35
16 Air Flow Performance - Side Duct Application . . . . . . . .37
17 Air Flow Performance - Bottom Duct Application . . . . . . .39
1 Unit Shipping Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Condenser Covering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Compressor Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
®
Component Location (ZR120 Shown) . . . . . . 6
5 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8 ZR078-120 Physical Dimensions . . . . . . . . . . . . . . . . . . 9
9 ZR150 Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . 9
10 ZR078-150 Unit Bottom Duct Openings . . . . . . . . . . . . 10
11 ZR078-150 Unit Electrical Entry . . . . . . . . . . . . . . . . . . 11
12 ZR078-120 Unit Side Duct Openings . . . . . . . . . . . . . . 11
13 ZR150 Unit Side Duct Openings . . . . . . . . . . . . . . . . . . 12
14 ZR078-150 Unit Left Duct Opening . . . . . . . . . . . . . . . . 12
15 ZR078-150 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . 13
16 ZR078-150 Transition Roof Curb . . . . . . . . . . . . . . . . . 13
17 Side Panels With Hole Plugs . . . . . . . . . . . . . . . . . . . . . 14
18 Return Downflow Plenum With Panel . . . . . . . . . . . . . . 14
19 Discharge Panel In Place . . . . . . . . . . . . . . . . . . . . . . . 14
20 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TABLE OF CONTENTS
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . 45
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . 46
Reheat Mode Sequence Of Operation . . . . . . . . . . . . . . . 47
Electric Heating Sequence Of Operations. . . . . . . . . . . . . 49
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . 49
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . 50
Ignition Control Board. . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Gas Heating Operation Errors . . . . . . . . . . . . . . . . . . . . 51
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Charging The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Unit Control Board Option Setup . . . . . . . . . . . . . . . . . . . . . . 57
Option Byte Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Heat Delay Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
LIST OF TABLES
18 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
19 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . .41
20 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . .41
21 Motor Sheave Datum Diameters . . . . . . . . . . . . . . . . . . .43
22 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . .44
23 Electric Heat Limit Setting 50" Cabinet . . . . . . . . . . . . . . .50
24 Electric Heat Limit Setting 42" Cabinet . . . . . . . . . . . . . . .50
25 Electric Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . .50
26 Gas Heat Limit Control Settings . . . . . . . . . . . . . . . . . . . .52
27 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . .52
28 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . .54
29 Gas Heat Stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
30 Unit Control Board Flash Codes . . . . . . . . . . . . . . . . . . . .56
31 Heat Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
32 Ignition Control Flash Codes . . . . . . . . . . . . . . . . . . . . . .57
33 Reheat Control Board Flash Codes . . . . . . . . . . . . . . . . .57
LIST OF FIGURES
Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
23 Typical Low Voltage Field Wiring . . . . . . . . . . . . . . . . . 17
24 Side Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . 29
25 Bottom Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . 29
26 Enthalpy Set Point Chart . . . . . . . . . . . . . . . . . . . . . . . . 33
27 Honeywell Economizer Control W7212 . . . . . . . . . . . . . 33
28 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
29 Altitude/Temperature Correction Factors . . . . . . . . . . . 35
30 Dry Coil Delta P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
31 Reheat Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . 48
32 System Piping Schematic . . . . . . . . . . . . . . . . . . . . . . . 49
33 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
34 Typical Gas Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
35 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
36 Basic Troubleshooting Flowchart . . . . . . . . . . . . . . . . . 58
37 Power On Flow Chart . . . . . . . . . . . . . . . . . . . . . . . . . . 58
38 Trip Failure Flow Chart . . . . . . . . . . . . . . . . . . . . . . . . . 59
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls ZR Series
Summary of Contents for Johnson Controls ZR Series
-
Page 1: Table Of Contents
R-410A ZR SERIES 6-1/2 - 12-1/2 Ton 60 Hertz TABLE OF CONTENTS General ......... . 2 Operation . -
