R-410A
ZK SERIES W/SMART EQUIPMENT™
6-1/2 - 12-1/2 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Unit components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Clearances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Rigging and handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Side panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Condensate drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power and control wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Optional electric heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Optional gas heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Options and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Economizer sequences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Dry bulb changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Single enthalpy changeover . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Dual enthalpy changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1 Component location table . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 ZK-06 through -12 unit limitations . . . . . . . . . . . . . . . . . . . . . . 8
3 Weights and dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 ZK-06 through -12 unit accessory weights . . . . . . . . . . . . . . 10
5 ZK-06 through -12 unit physical dimensions . . . . . . . . . . . . . 11
6 ZK-06 through -12 unit clearances . . . . . . . . . . . . . . . . . . . . 11
7 Side duct dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Left/end duct dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
9 Roof curb components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10 Control wire sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
11 Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12 ZK-06 through -12 physical data . . . . . . . . . . . . . . . . . . . . . . 28
13 Electric heat minimum supply air . . . . . . . . . . . . . . . . . . . . . . 30
14 Gas application data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
15 Gas pipe sizing - capacity of pipe . . . . . . . . . . . . . . . . . . . . . 31
16 Gas heat minimum supply air . . . . . . . . . . . . . . . . . . . . . . . . 31
17 Supply air limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
18 Altitude/temperature correction factors . . . . . . . . . . . . . . . . . 39
1 Unit shipping bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Condenser covering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Compressor section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 ZK component location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 Unit 4 point load weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6 Unit 6 point load weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7 Center of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8 ZK-06 through -10 physical dimensions . . . . . . . . . . . . . . . . 10
9 ZK-12 physical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10 ZK-06 through -12 unit bottom duct openings . . . . . . . . . . . 11
11 ZK-06 through -12 unit electrical entry . . . . . . . . . . . . . . . . . 12
12 ZK-06 through -10 unit side duct openings . . . . . . . . . . . . . . 12
13 ZK-12 unit side duct openings . . . . . . . . . . . . . . . . . . . . . . . 13
14 ZK-06 through -12 unit/end left duct opening . . . . . . . . . . . . 13
15 ZK-06 through -12 roof curb . . . . . . . . . . . . . . . . . . . . . . . . . 14
16 ZK-06 through -12 transition roof curb . . . . . . . . . . . . . . . . . 14
17 Side panels with hole plugs . . . . . . . . . . . . . . . . . . . . . . . . . 15
18 Return downflow plenum with panel . . . . . . . . . . . . . . . . . . . 15
Table of contents
Free cooling operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Power exhaust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Smart Equipment™ economizer board . . . . . . . . . . . . . . . . . . 35
Airflow performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Air balance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Checking air quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Cooling sequence of operation . . . . . . . . . . . . . . . . . . . . . . . . 50
Cooling operation errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Reheat mode sequence of operation . . . . . . . . . . . . . . . . . . . 52
Electric heating sequence of operations . . . . . . . . . . . . . . . . . 53
Electric heat operation errors . . . . . . . . . . . . . . . . . . . . . . . . 54
Gas heating sequence of operations. . . . . . . . . . . . . . . . . . . . 54
Gas heating operation errors . . . . . . . . . . . . . . . . . . . . . . . . 55
Cooling start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Gas heat start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Checking gas heat input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Charging the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Smart Equipment™ unit control board . . . . . . . . . . . . . . . . . . . . . 60
Start-up sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
List of tables
19 Airflow performance - side duct application . . . . . . . . . . . . . 42
20 Airflow performance - bottom duct application . . . . . . . . . . . 44
21 RPM selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
22 Indoor blower specifications . . . . . . . . . . . . . . . . . . . . . . . . . 46
23 Power exhaust specifications . . . . . . . . . . . . . . . . . . . . . . . . 46
24 Motor sheave datum diameters . . . . . . . . . . . . . . . . . . . . . . 48
25 Additional static resistance . . . . . . . . . . . . . . . . . . . . . . . . . . 49
27 Electric heat limit setting 50 in. cabinet . . . . . . . . . . . . . . . . . 54
28 Electric heat limit setting 42 in. cabinet . . . . . . . . . . . . . . . . . 54
29 Electric heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . . 54
30 Gas heat limit control settings . . . . . . . . . . . . . . . . . . . . . . . . 56
31 Gas heat anticipator setpoints . . . . . . . . . . . . . . . . . . . . . . . 56
32 Gas rate cubic feet per hour . . . . . . . . . . . . . . . . . . . . . . . . . 58
33 Gas heat stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
35 Ignition control flash codes . . . . . . . . . . . . . . . . . . . . . . . . . . 66
List of figures
19 Discharge panel in place . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
20 Save side panels for economizer hood tops . . . . . . . . . . . . 16
21 Condensate drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
electric heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
24 Typical low voltage field wiring . . . . . . . . . . . . . . . . . . . . . . . 19
25 Side entry gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
26 Bottom entry gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
27 SE-ECO1001-0 economizer controller . . . . . . . . . . . . . . . . . 35
28 Belt adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
29 Altitude/temperature correction factors . . . . . . . . . . . . . . . . 40
30 Dry coil delta P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
33 Typical flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
34 Typical gas valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
35 Unit control board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls York ZK Series
Summary of Contents for Johnson Controls York ZK Series
-
Page 1: Table Of Contents
R-410A ZK SERIES W/SMART EQUIPMENT™ 6-1/2 - 12-1/2 Ton 60 Hertz Table of contents General ..........2 Free cooling operation. -
