R-410A
ZX SERIES
3 - 12.5 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ZX04-14 Unit Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 18
Optional Gas Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Blower Phasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Compressor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
1 ZX04-14 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 ZX04-14 Corner Weights . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZX04-14 Unit Accessory Weights . . . . . . . . . . . . . . . . . . . 9
4 ZX04-07 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . 15
5 ZX08-14 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
9 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
11 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . 46
12 Gas Heat Supply Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
13 Supply Air Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
19 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1 Unit Shipping Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Condenser Covering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 ZX04-06 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . 10
7 ZX07 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 ZX08 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9 ZX09/12 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . 13
10 ZX14 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 14
13 Side Duct Cover Panels . . . . . . . . . . . . . . . . . . . . . . . . . 17

TABLE OF CONTENTS

IntelliSpeed Supply Fan Control . . . . . . . . . . . . . . . . . . . . 64
Economizer Sequences . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Single Enthalpy Changeover. . . . . . . . . . . . . . . . . . . . . . . 65
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . 65
Auto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Free Cooling Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Heating Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Gas Heat Board Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
LIST OF TABLES
20 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . . 61
21 Motor Sheave Datum Diameters . . . . . . . . . . . . . . . . . . 62
22 ZX04-14 Additional Static Resistance . . . . . . . . . . . . . . 63
23 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . . 70
24 Gas Heat Stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
26 ZX04 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
27 ZX05 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
28 ZX06 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
29 ZX07 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
30 ZX08 Charging Table System 1 . . . . . . . . . . . . . . . . . . . 78
31 ZX08 Charging Table System 2 . . . . . . . . . . . . . . . . . . . 78
32 ZX09 Charging Table System 1 . . . . . . . . . . . . . . . . . . . 79
33 ZX09 Charging Table System 2 . . . . . . . . . . . . . . . . . . . 79
34 ZX12 Charging Table System 1 . . . . . . . . . . . . . . . . . . . 80
35 ZX12 Charging Table System 2 . . . . . . . . . . . . . . . . . . . 81
36 ZX14 Charging Table System 1 . . . . . . . . . . . . . . . . . . . 81
37 ZX14 Charging Table System 2 . . . . . . . . . . . . . . . . . . . 82
LIST OF FIGURES
16 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
17 Side Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . 46
18 Flue Exhaust Hood Shipping Location . . . . . . . . . . . . . . 48
19 Flue Exhaust Hood Installed . . . . . . . . . . . . . . . . . . . . . 49
20 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
21 Altitude/Temperature Correction Factors . . . . . . . . . . . . 51
22 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
23 Ignition Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . 66
24 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
27
