705213-YIM-E-0213
D
5-5/32
Figure 13: ZR150 Unit Side Duct Openings
Table 6: Side Duct Dimensions
Unit Model Number
ZR078
ZR090
ZR102
ZR120
ZR150
Figure 14: ZR078-150 Unit Left Duct Opening
12
Dimension (in.)
A B
27 3/4 12 1/16
27 3/4 12 1/16
28 1/4 18 1/16
28 1/4 18 1/16
28 1/4 18 1/16
30-3/8
4-5/16
Dot Plugs
18-1/4
C
31-5/8
C D
27 1/2 16
27 1/2 16
28 1/4 18 1/4
28 1/4 18 1/4
28 1/4 18 1/4
Johnson Controls Unitary Products
A
B
2-7/8
