- Page 1 AB 140 OWNER’S MANUAL WEBSITE MANUAL...
- Page 2 MAGNETIC AIR BIKE IMPORTANT! Please read all instructions carefully before using this product. Retain this manual for future reference. The specifications of this product may vary slightly from the illustrations and are subject to change without notice.
-
Page 3: Important Safety Notice
Before You Start For your safety and benefit, read this manual carefully before using the machine. Prior to assembly, remove components from the box and verify that all the listed parts were supplied. Assembly instructions are described in the following steps and illustrations. IMPORTANT SAFETY NOTICE PRECAUTIONS BE SURE TO READ THE ENTIRE MANUAL BEFORE YOU ASSEMBLE OR OPERATE... - Page 4 WARNING! Consult your physician before starting with any exercise program. He can advise on the kind of training and which impact is suitable. WARNING! This machine is not suitable for therapeutic or medical purpose. WARNING! Over exercising may result in serious injury or death. If you experience dizziness, nausea, chest pain, or any other abnormal symptoms STOP EXERCISING IMMEDIATELY AND CONSULT A PHYSICIAN WITHOUT DELAY.
-
Page 5: Exploded Diagram
EXPLODED DIAGRAM - 3 -... -
Page 6: Parts List
PARTS LIST DESCRIPTION QTY NO. DESCRIPTION Main frame Bearing Upright frame Pivot shoulder bolt Φ10*44.5 Saddle post Hex thin nut M8*H5 Saddle slider Pivot bearing 5L/R Motion handle Nylon nut M8 Foot peg Flange nut M14*1.5 Pedal arm Flat washer Φ17*Φ22*1 8L/R Step crank 1 pr. - Page 7 ASSEMBLY INSTRUCTIONS ♦ Take time to review the manual and familiarize yourself with the entire assembly process before proceeding. ♦ Given the weight of the equipment, we recommend that two or more people be involved in assembly, and having assistance accordingly. This is especially convenient when assembling multiple parts or moving the equipment.
- Page 8 STEP 2 A. Dismount the Nylon Nuts (27) from the Motion Handle (5L/R). B. Install the Motion Handle (5L/R) to the Main Frame (1) accordingly with the Motion Handle Pivot Shaft (31) and Spring Washer (40) as shown. (DO NOT Tighten Yet.) C.
- Page 9 STEP 3 Install the Pedal (11L/R) to the Crank (13L/R) respectively with Wrench as shown. Make Ensure the Pedals are securely locked during exercise to avoid any damage to the threads of Pedals or Cranks. NOTE: Both pedals are labeled L FOR LEFT and R FOR RIGHT (View from Rider’s position). To tighten turn the Left pedal COUNTERCLOCKWISE and the Right pedal CLOCKWISE.
- Page 10 STEP 4 A. Feed the Sensor Wire (38) through the Upright Frame (2) and out from top, feed the Tension Control Cable (41) through the Upright Frame (2) and out from designed hole for Controller as shown. B. Turn the Tension Controller (42) to Level-1, and then install the Tension Control Cable (41) to the Tension Controller (42) properly as shown in Fig-A.
-
Page 11: Operation
OPERATION Seat Adjustment Proper seat height ensures maximum exercise efficiency and comfort, while reducing the risk of injury. 1. Place one pedal in the down position, and center the ball of your foot over the center of the pedal. Your leg should be slightly bent at the knee. If you leg is too straight or your foot cannot touch the pedal, you will need to lower the seat. -
Page 12: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. -
Page 13: Warranty
WARRANTY DKN-Technology warrants this product to be free from defects in material at the time of the product’s tender of delivery. This ‘Carry-in’ Limited Warranty applies for a period of two (2) years, beginning on the date mentioned on your product invoice or proof of purchase of product issue by DKN-Technology. - Page 14 DO NOT BOUNCE. REMEMBER always to check with your physician before starting any exercise program. EXERCISE PHASE This is the stage where you put the effort in. After regular use, the muscles in your legs will become more flexible. Work at your own pace and be sure to maintain steady...
