DKN technology SPEEDBIKE PRO X Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
1
SPEEDBIKE PRO X
OWNER'S MANUAL
OWNER'S MANUAL
WEBSITE
MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPEEDBIKE PRO X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DKN technology SPEEDBIKE PRO X

Summary of Contents for DKN technology SPEEDBIKE PRO X

  • Page 1 SPEEDBIKE PRO X OWNER’S MANUAL OWNER’S MANUAL WEBSITE MANUAL...
  • Page 2 IMPORTANT ! Please read all instructions carefully before using this product. Retain this manual for future reference. The specifications of this product may vary slightly from the illustrations and are subject to change without notice.

  • Page 3: Important Safety Notice

    Before You Start Thank you for purchasing our SPINNING Bike! For your safety and benefit, read this manual carefully before using the machine. Prior to assembly, remove components from the box and verify that all the listed parts were included. Assembly instructions are described in the following steps and illustrations.
  • Page 4 WARNING! Consult your physician before starting with any exercise program. He can advise on the kind of training and which impact is suitable. WARNING! This machine is not suitable for therapeutic or medical purpose. WARNING! Over exercising may result in serious injury or death. If you experience dizziness, nausea, chest pain, or any other abnormal symptoms STOP EXERCISING IMMEDIATELY AND CONSULT A PHYSICIAN WITHOUT DELAY.

  • Page 5: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 6: Parts List

    PARTS LIST Item Name Item Name Main Frame Rear Foot Rest Handlebar Post Adjusting Foot Pad Steel Ring Rear Post Bushing Front Stabilizer Roller Rear Stabilizer Lower glide cap Saddle Post Upper glide cap 1 Handlebar Joint Upper glide cap B Saddle upper glide Locking Handlebar Joint Handlebar upper glide...

  • Page 7: Assembly Instruction

    ASSEMBLY INSTRUCTION STEP 1 1. Take off Packing Tube (46) from Main Frame (1), keep well the Packing Tube (46) in case of packing next time. 2. Lock Front Stabilizer (4) and Rear Stabilizer (5) to Main Frame (1) by using Inner pan head screw M10x25 (19), Spring Washer D10, Flat Washer D10xΦ20x2 (22) and Arch Washer D10xΦ...
  • Page 8 STEP 3 1. Use open end wrench to lock Saddle (39) to Saddle Post (6); loosing Quick Clamp Handle (15) to adjust Saddle Post (6), make sure Saddle Post (6) and Saddle (39) are locked tightly before exercise.
  • Page 9 STEP 4 1. Lock Handlebar upper glide (9) to Handlebar Joint (7) by Inner Hex Bolt M8×15 (45). 2. Insert Locking Screw (13) to Handlebar Joint (7); insert Pressure Spring (43) and T-shape Nut (14) to the bottom of Handlebar upper glide (9) to lock with Locking Screw (13); 3.
  • Page 10 STEP 6 Connect well Extension wire 1 (47) with Extension wire 2 (48), and then lock Connecting tube (50) tightly to Handlebar joint (7) with Square neck bolt (42), Flat washer (49) and Nylon nut (54). Draw out Extension wire 2 (48) from Computer bracket (51), and them lock Computer bracket (51) to Connecting tube (50).
  • Page 11 Step 7 Connect extension wire 2 (48) with Display screen (52),, and then lock Display screen (52) to Computer bracket (51) with Screw (53).
  • Page 12 DISPLAY 1. POWER ON ( Home page): 2. Function Spec Description: A. MY TRAINING：Displays total motion data B. GET STARTED： QUICK START / INTERVAL / MAP YOUR ROUTE /Constant Power/Program/Heart rate Control Total six modes of exercise for choose C. System Setting ：This page can operate login account/home page/historical data/new linked account/Settings and other functions D.
  • Page 13 Data&time setting WIFI setting BT PULSE 2023/8/7P2/20...
  • Page 14 3. Display Range ： ： ITEM Description DISTANCE ‧ Display the movement distance ‧ Display value range 0.0 ~ 99.9 in Cycle SPEED ‧ Display the movement speed ‧ Display Value range 0.0 ~ 99.9 ‧ Display RPM ‧ Value range 0 ~ 999 TIME ‧...
  • Page 15 5. SYSTEM SETTING OPERATION : A. LOGO IN: ( photo) Personal information login and create, login account (Email application, FB , We Chat , GOOGLE login) B . HOME: Back to home page C.TRAINING HISTORY: Exercise information enquiry (login required) D.
  • Page 16 GOOGLE /FACEBOOK/WECHAT CREATE ACCOUNT 2023/8/7P5/20...
  • Page 17 B. TRAINING HISTORY C C . . S S E E T T T T I I N N G G : : 2023/8/7P6/20...
  • Page 18 Click SYSTEM SETTINGS to enter into system setting (wifi brightness ,volume ,BT, Language ,KM/ML) a.Brightness b.Volume 2023/8/7P7/20...
  • Page 19 c.WIFI d. bluetooth device 2023/8/7P8/20...
  • Page 20 e. language f.Distance Unit 2023/8/7P9/20...
  • Page 21 SYSTEM UPGRADE into APP updata 2023/8/7P10/20...
  • Page 22 Multimedia mode (slide the page left and right to select the APP icon you want to use) A. Select APP :NETLIX、YOUTUBE、SPOTIFY、KINOMAP、CHROME、FACEBOOK、 TWITTER、 、 INSTAGRAM、 、 AMAZON PRIME VIDEO、 、 AMAZON SHOPPING 2023/8/7P11/20...
  • Page 23 Multimedia mode, user can press “ “ to display or hide the movement value, press “ ” back to the last system function page., press “ ” to the home page , press “ “to start training ,press” “ stop exercise.
  • Page 24 7、 、 Function Introduction Quick Start / Interval /Map Your Route/Constant Power/Program/Heart rate Control 2023/8/7P13/20...
  • Page 25 QUICK START MODE： ： 1. Setting the exercise value (DIST/TIME/CAL)，Press “START” go to training, data start to counting . 2. When start training can adjust the LEVEL UP&DOWN /FAN，press “PAUSE” enter into break mode, press “STOP” to exit this mode. When finished, the SUMMARY displays .
  • Page 26 B. INTERVAL MODE： ： A. Can set the functions value of CYCLE /TIME /LEVEL /TARGET RPM separately，press “START” go to training. Warm up first, then start INTERVAL mode C. In high intensity time can adjust the load level (display the level as set ) When in rest time adjust the load level，keep display the level as set .
  • Page 27 2023/8/7P16/20...
  • Page 28 C.MAP YOUR ROUTE MODE： ： 1. After entering this mode, it will detect the current region, click “ ” load the preset link,distinguish Chinese and non-Chinese region.; click “ ” can switch to the world map(GOOGLE MAP) or China Map. preset “...
  • Page 29 D、 、 Constant Power MODE: 1. User can set TIME/TARGET POWER/TARGET CADENCE , then press “START” go to training. 2. LEVEL will be adjusted according to the value of WATT. 3. Press “ Pause ‘”go to break mode, press “ Stop “ leave this mode. When finished, the SUMMARY displays .
  • Page 30 E.PROGRAM MODE: 1. Set the TIME and select P1~P12 PROGRAM，press “ START” go to training. 2. When start user can adjust the LEVEL UP&DOWN /FAN，level will be adjusted according to the PROGRAM. 3. Press “PAUSE” enter into break mode, press “ STOP” leave this mode. When finished, the SUMMARY displays .
  • Page 31 F. HEART RATE CONTROLMODE: 1. User can set the AGE/ TIME/ TARGET 55% 75% 90% TAG PULSE，press “ START” go to training. 2. LEVEL will be adjusted according the goal value of heart rate, if not reached the goal value , the load level will increase ,if over the goal value level will decrease automatically.

  • Page 32: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. WARM-UP The purpose of warming up is to prepare your body for exercise and to minimize injuries.
  • Page 33 BLUETOOTH FUNCTION Check the DKN-Technology website for more information about which apps the Spining bike is compatible with. Turn on Bluetooth function on your tablet or smartphone to connect it with the machine (pairing is not required). Download the app, open it on your device and follow the steps to set it up. For any technical questions on third party app functionality do consult the FAQ section on the specific app developper’s website.

  • Page 34: Warranty

    WARRANTY DKN-Technology warrants this product to be free from defects in material at the time of the product’s tender of delivery. This ‘Carry-in’ Limited Warranty applies for a period of two (2) years, beginning on the date mentioned on your product invoice or proof of purchase of product issue by DKN-Technology.
  • Page 35 WEBSITE Make an Appointment to Visit our Showroom...

This manual is also suitable for:

20702
