QUICK BGA EA-H00 OPERATION MANUAL
QUICK BGA EA-H00
BGA/SMD Rework Station
Operation Manual
Thank you for purchasing our BGA/SMD Rework System. The system is exclusively designed for reworking
and soldering SMD component. Please carefully read this manual before operating the system. Store this
manual in a safe, easily accessible place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGA EA-H00 and is the answer not in the manual?

Questions and answers

Related Manuals for Quick BGA EA-H00

Summary of Contents for Quick BGA EA-H00

  • Page 1 QUICK BGA EA-H00 OPERATION MANUAL QUICK BGA EA-H00 BGA/SMD Rework Station Operation Manual Thank you for purchasing our BGA/SMD Rework System. The system is exclusively designed for reworking and soldering SMD component. Please carefully read this manual before operating the system. Store this...

  • Page 2: Table Of Contents

    QUICK BGA EA-H00 OPERATION MANUAL Contents 1. Summary .......................... 1 2. Product Picture ......................... 2 3、Enchase component ......................2 4. Safety Instructions ......................2 5. Specifications and Technical Parameters ................3 5.1 Specifications ......................... 3 5.2 Technical Parameters ...................... 4 6.

  • Page 3: Summary

    IR Software, thus meeting the higher technical demands of modern electronic industry. It becomes one of the most valued electronic equipments in this field. QUICK BGA EA-H00 consists of two parts: QUICK IR EA-H00 Infrared Rework System and QUICK PL EA-H00 Precision Placement System.

  • Page 4: Product Picture

    BGA2015 OPERATION MANUAL 2. Product Picture 3、Enchase component Please check whether the following parts are included and intact. * Main Unit BGA EA-H00 * Control box * BGA EA-H00 Operation Manual * video line * USB connect line * video capture card * BGA tool box * IR Camera—RPC（optional）...

  • Page 5: Specifications And Technical Parameters

    BGA2015 OPERATION MANUAL components. Note: Top and bottom IR radiator will be very hot during working, so explosive and combustible object or gas and solvent is strictly prohibited in working areas, also please don’ touch the hot housing parts Note: The laser alignment device includes two secondary laser device, so don’t see the laser bean directly.

  • Page 6: Technical Parameters

    BGA2015 OPERATION MANUAL Net weight： 52kg Packaging dimension： 970*830*520（mm） Note: When purchasing the equipment, please indicate the working voltage. 5.2 Technical Parameters TL：Melting temperature of solder T1：Heat preservation starting temperature of reflow soldering T2：Heat preservation ending temperature of reflow soldering T3：Peak value temperature of soldering and de-soldering T0：Valve temperature: The lowest temperature of Bottom Heater when Top Heater heats up.

  • Page 7: Install And Connect System

    BGA2015 OPERATION MANUAL 6. Install and Connect System 6.1 Place System * Unwrap the packing of the unit, then take out BGA EA-H10 Main Unit and put it on the horizontal worktable. * Make sure whether the unit and parts are in good conditions. 6.2 Install RPC 1.

  • Page 8: Control Box Instructions

    BGA2015 OPERATION MANUAL Connect USB line Connect video line Connect control box Connect ground line 7. control box Instructions A. During selecting working flow period, UP and DOWN knobs are used for controlling the moving upward or downward of cursor but when in standby interface, it can increase or decrease the digital.

  • Page 9: Parameters Setting

    BGA2015 OPERATION MANUAL Adjustment Scale Note: Adjusting the aperture system can protect the adjacent components on the PCB from being heated. But, when the aperture system is adjusted to small size, the Top Radiator will be very hot and decrease its lifetime, so it’s necessary to increase the window size appropriately to avoid the damage of the Top Radiator.
  • Page 10 BGA2015 OPERATION MANUAL password: *** Rotate MENU password: 0** press MENU 旋转 select: 0 select: 0 rotate MENU press MENU password: 0** password: 00* select: 0 select: 0 rotate MENU press OK password: 00* password: 000 select: 0 select: 0 Saving Password! Any key return After input password:...
  • Page 11 BGA2015 OPERATION MANUAL rotate MENU press MENU password: *** password: *** Step① Step② select: 0 select: 0 rotate MENU press OK password: *** password: *** Step③ Step④ select: 0 select: 1 password: *** select: 1 1. When carry on the forth step (Step④), if press “SET” key, you can browse and modify parameter of this flow, shown as C-1 item.
  • Page 12 BGA2015 OPERATION MANUAL After finishing modifying working mode, if you want to modify laser alignment mode, operate as D item shows; if no need to modify it, please press DOWN key to browse the next parameter settings. C-1. Modify Parameter of working flow If it is necessary to modify parameter of a working flow, first you must select the working flow and then modify its parameter.
  • Page 13 BGA2015 OPERATION MANUAL the value of TL. Heating time rising from T1 to T2. User can set the value in the range of 0~300s. Heating time rising from T2 to T3. User can set the value in the range of 0~300s. Prolonged heating time (Heat preservation time) after the temperature reach T3, and user can also set the value in the range of 0~999s.
  • Page 14 BGA2015 OPERATION MANUAL press OK rotate MENU T1: 130℃ _T1: 130℃ S1: 060s S1: 060s press MENU press MENU T1: 130℃ T1: 130℃ _S1: 060s S1: 060s rotate MENU press OK T1: 130℃ T1: 130℃ S1: 060s S1: 070s T1: 130℃ S1: 070s rotate MENU press MENU...
  • Page 15 BGA2015 OPERATION MANUAL press MENU press OK T2: 160℃ T2: 160℃ S2: 030s S2: 050s rotate MENU rotate MENU T2: 160℃ S2: 050s S2: 050s T3: 200℃ rotate MENU rotate MENU T3: 200℃ S3: 010s S3: 010s TL: 183℃ press MENU press MENU TL: 183℃...
  • Page 16 BGA2015 OPERATION MANUAL TC:022˙C Tb:019˙C ready for flow D. Modify laser alignment mode For instance: Modify the laser alignment mode and set it to “on”. select: 1 rotate MENU type: desolder press MENU type: desolder laser: off rotate MENU press OK type: desolder type: desolder laser: off...

  • Page 17: Operating Technics Instruction

    BGA2015 OPERATION MANUAL TC: ***℃ Tb: ***℃ T sense error ! If the bottom sensor is broken, it displays: TC: ***℃ Tb: ***℃ B sense error ! If above status happens, user should stop operating. 1. During the upward or downward movement of Top Heater or holding out and drawing back of fan arm, if it doesn’t reach over 10 seconds, the unit will come back to initial state all and singular in spite of what state it is here.
  • Page 18 BGA2015 OPERATION MANUAL 8.3.1Soldering Technics 1. Turn on power switch of each part. 2. Move PCB Fixture with fixed PCB and make it above the Bottom Radiator and make the soldered component on the PCB between Top Radiator and Bottom Radiator. The position is easy to be measured with laser alignment device.
  • Page 19 BGA2015 OPERATION MANUAL Heater and Bottom Heater. The position is easy to be measured with laser alignment device. The right position should make the red laser point in the center of component and the suction pad in center of component also. 3.

  • Page 20: System Operation

    BGA2015 OPERATION MANUAL 9. PL System Operation 9.1 Component function Crosswise Cooling Fan Besides the existing top cooling system, the system adds outside Cooling Fan again to speed up the cooling process of PCB. 2、PCB fixture The movable PCB fixture is able to fix PCBs of different sizes. It has four Fixing Knobs. Two PCB Fixing Knobs are used for locking PCB Clamp Bar to fix PCB.

  • Page 21: 10．Equipment Maintenance

    BGA2015 OPERATION MANUAL Fixed Knob 10．Equipment Maintenance Remark: For ensuring reliable function and maintenance of equipment, please use parts provided by original factory. Please turn off power switch of each part and pull out power plug when not in use. Note: After cutting off the power supply, the housing is still very hot, so please don’t use any dangerous or combustible solvent to clean it.

  • Page 22: 11、Quicksoft Brief Instruction

    QUICK BGA EA-H00 OPERATION MANUAL 11、QUICKSOFT brief instruction 11.1 operation interface 1. Operation interface: this interface reaction executive condition of flow , we can real-time operate by this interface. 2. parameter of operation interface, be setting from “parameter testing interface”, in operation interface do not need setting.

  • Page 23: Parameter Testing Interface

    QUICK BGA EA-H00 OPERATION MANUAL Only when communicate state is online, we can control equipment auto carry out flow by software. Working area: contain every working button “heat arm up”, “heat arm down”,“dissipation open/dissipation close”,“cooling fan enter ” , “cooling fan out”.

  • Page 24: Curve Analysis Interface

    QUICK BGA EA-H00 OPERATION MANUAL In parameter setting display, can set parameter, setting range refer to 5.1. T0: only satisfy “TIR≥T0”, top infrared heater can start working. No special purpose, please set Tir＞ Can also click “flow select” in “edit flow display”, call saved parameter and modify it.
  • Page 25 QUICK BGA EA-H00 OPERATION MANUAL Password setting: can set “enter password” and “parameter protect” two type password. The people who obtain enter password can operation this software, but no parameter modify power. The people who obtain parameter protect can operation this software, and modify parameter.
  • Page 26 Changzhou Quick Soldering Co., Ltd Add: No.11, FengXiang Road, Wujin High-Tech Industrial Development Zone, Jiangsu, China Tel: 86-519-86225678 Fax: 86-519-86558599 Zip code: 213167 Website: www.quick-global.com...
