Summary of Contents for Carrier 42GCVPH010-303P
- Page 1 INSTALLATION MANUAL AIR CONDITIONER (SPLIT TYPE) Indoor unit 42GCVPH010-303P 42GCVPH013-303P 42GCVPH018-303P Outdoor unit 38GCVPH010-303P 38GCVPH013-303P 38GCVPH018-303P 1 1 2 9 8 5 0 1 1 3...
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS FOR SAFETY ............................... 1 ACCESSORY AND INSTALLATION PARTS ..........................5 INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS ....................6 Optional Installation Parts ................................6 INDOOR UNIT ....................................7 Installation Place..................................7 Cutting a Hole and Mounting Installation Plate ..........................7 Piping and Drain Hose Installation .............................. -
Page 3: Precautions For Safety
PRECAUTIONS FOR SAFETY PRECAUTIONS FOR SAFETY Read the precautions in this manual carefully before This appliance is filled with R32. operating the unit. Warning indications on the air conditioner unit Warning indication Description CAUTION CAUTION BURST HAZARD BURST HAZARD Open the service valves Open the service valves before the operation, before the operation, otherwise there might be the burst. - Page 4 DANGER • FOR USE BY QUALIFIED PERSONS ONLY. • TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK. MAKE SURE ALL POWER SWITCHES ARE OFF. FAILURE TO DO SO MAY CAUSE ELECTRIC SHOCK. • CONNECT THE CONNECTING CABLE CORRECTLY. IF THE CONNECTING CABLE IS CONNECTED WRONGLY, ELECTRIC PARTS MAY BE DAMAGED.
- Page 5 • The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). • Be aware that refrigerants may not contain an odour. • Do not pierce or burn as the appliance is pressurized. Do not expose the appliance to heat, flame, sparks, or other sources or ignition.
- Page 6 CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock. Do not store it in a wet basement or expose to rain or water. • After unpacking the unit, examine it carefully for possible damage. •...
-
Page 7: Accessory And Installation Parts
ACCESSORY AND INSTALLATION PARTS ACCESSORY AND INSTALLATION PARTS Indoor Unit Part name Part name Installation plate × 1 Wireless remote control × 1 Battery × 2 Remote control holder × 1 Ultra pure filter × 2 Mounting screw × 10 Flat head wood screw ×... -
Page 8: Installation Diagram Of Indoor And Outdoor Units
INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS For the rear left and bottom left piping Wall Hook Mounting screw Hook Installation plate Cut out a piece of SPACER from indoor unit packaging box, roll it and insert between the indoor unit and wall to tilt the indoor unit for better operation. -
Page 9: Indoor Unit
INDOOR UNIT INDOOR UNIT Installation Place • Space allows for moving range of the air inlet grille and horizontal louver in operation above curtain rails, window cornice or other objects. (Unit : mm) • A place which provides the spaces around the indoor unit as shown in the diagram •... -
Page 10: Piping And Drain Hose Installation
• Cut off the pipe exist from inside of Front panel using a coping saw or an Piping and Drain Hose Installation equivalent tool. • The plastic burrs from the cutting process should be removed with a half round file or an equivalent tool. Piping and drain hose forming •... -
Page 11: Indoor Unit Fixing
How to remove the drain cap CAUTION • Clip the drain cap by needle-nose pliers and pull out. • Bind the auxiliary pipes (two), power supply and connecting cable with facing tape tightly. Connecting cable Installation plate Indoor unit Auxiliary pipes Cap drain •... -
Page 12: Drainage
Drainage CAUTION MOUNTING INDOOR UNIT TO THE INSTALLATION PLATE 1. Run the drain hose sloped downwards. • The lower part of indoor unit may float, due to the condition of piping and installer cannot fix it to the installation plate. In that case, use the NOTE screws provided to fix the indoor unit with the installation plate. -
Page 13: Outdoor Unit
OUTDOOR UNIT OUTDOOR UNIT Installation Place Refrigerant Piping Connection • A place which provides the spaces around the outdoor unit as shown in Flaring the diagram • A place which can bear the weight of the outdoor unit and does not allow 1. -
Page 14: Evacuating
Packed valve handling precautions Evacuating • Open the valve stem all the way out, but do not try to open it beyond the stopper. After the piping has been connected to the indoor unit, you can perform the air purge together at once. Pipe size of Packed Valve Size of Hexagon wrench AIR PURGE... -
Page 15: Electrical Works
ELECTRICAL WORKS ELECTRICAL WORKS Model 42GCVPH010-303P 42GCVPH013-303P 42GCVPH018-303P Power source 60Hz, 220 - 230V Single phase Maximum running current 5.30A 6.30A 9.80A Circuit breaker rating H07RN-F or 60245 IEC66 Power supply cable H07RN-F or 60245 IEC66 (1.25 mm or more) (1.5 mm... -
Page 16: Power Supply And Connecting Cable Connection
Power Supply and Connecting Cable Connection Power Supply Input at Outdoor Unit Terminal Block Indoor Unit Outdoor Unit Connecting cable 1 2 3 Connecting cable connect to 1 2 3 Terminal block (1 2 3) Earth line Earth line Earth line Connecting cable Power supply cable Connecting cable... -
Page 17: Others
OTHERS OTHERS Gas Leak Test Test Operation To switch the TEST RUN (COOL) mode, press [RESET] button for 10 seconds. (The beeper will make a short beep.) Check places for the indoor unit. OPERATION / Check places for RESET Button the outdoor unit. -
Page 18: Decorative Fabric Installation
Decorative Fabric Installation The decorative fabric for cover on the air inlet grille of indoor unit was put in the accessories. User can use it as required. The method of installation is as follows. 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you. - Page 20 1 1 2 9 8 5 0 1 1 3...
