- Page 1 Network Camera Quick Guide DC-D4238HRA DC-D4248HRA Powered by...
-
Page 2: Safety Precautions
Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result appliance is operated. -
Page 3: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this document. Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this document are subject to change without prior notice for reasons such as functionality enhancements. -
Page 4: Dome Cover
Allen Wrench Guide Pattern Safety Wire Screw Please download software (IDIS Discovery, IDIS Center, IDIS Solution Suite Compact) and product manual from this link : - IDIS Website (www.idisglobal.com) - Search IDIS Discovery, IDIS Center, IDIS Solution Suite Compact. Overview Body •... -
Page 5: Camera Installation
IR LED Network Port Lens Alarm I/O, Audio I/O Factory Reset Button SD Memory Card Slot Wall/Ceiling Cable Rubber Installation Hole Power Camera Installation Push the SD memory card until it disengages from the slot, and then pull it out. Removing the Dome Cover Installation Loosen the screws counterclockwise using the... - Page 6 Pull the cable slightly and arrange the rubber as shown below. Use the screws, anchor provided with the camera to secure the install body on a wall or a ceiling. Use the provided guide pattern to check the distance between the screws. To pass through a thin cable or more than two cables, it is advised to finish it using silicon to make sure waterproofed perfectly.
-
Page 7: Angle Adjustment
Angle Adjustment Fasten the screws for the dome cover clockwise using the Allen wrench provided with the camera. Lens Rotation Horizontal Rotation Vertical Rotation Closing the Dome Cover Attach the double-sided tape to the desiccant first, and attach it to the specified location inside the dome cover as shown below. -
Page 8: Specifications
Specifications Operating Temperature -40°C ~ +60°C (-40°F ~ +140°F) Boot Up Temperature -20°C ~ +60˚C (-4°F ~ +140˚F) Operating Humidity 0% ~ 90% Power Source , PoE(IEEE 802.3af, Class 3) Power Consumption , 1.1A, 13.2W PoE, IEEE 802.3af (Class 3), 8.3W Approval FCC, CE, IP67, IK10 External Dimensions (Ø... - Page 12 IDIS Co., Ltd. For more information, please visit www.idisglobal.com...
