- Page 1 Network Camera Installation Manual DC-D4236X / DC-D4236RX / DC-D4236WRX / DC-D4236HRX / DC-D4236HRX-B DC-D4236X-A / DC-D4236RX-A / DC-D4236WRX-A / DC-D4236HRX-A / DC-D4237RX / DC-D4246WX / Powered by...
-
Page 2: Before Reading This Manual
Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product. -
Page 3: Safety Precautions
Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. -
Page 4: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements. -
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
Ethernet. • Day & Night feature (built-in IR cut filter changer) You can use the IDIS Discovery program to change network camera settings or the IDIS Solution Suite • Quick and easy firmware upgrade over the network Compact program to manage multiple network •... -
Page 7: Accessories
DC-D4236HRX(-A), DC- DC-D4236HRX-B Terminal Blocks (2 ea.) D4237RX D4246WX Network Camera Desiccant Allen Wrench Quick Guide Screws, Anchors (3 ea.) Protect Connector Guide Pattern DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4236HRX-B, An allen wrench, protect connector, and desiccant are included with DC-D4246WX models only. -
Page 8: Overview
Part 1 – Introduction Overview Body DC-D4236X(-A) Dome Cover DC-D4236X(-A), DC-D4236RX(-A), DC-D4237RX DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4246WX, DC-D4236HRX-B Lens Factory Reset Button Wall/Ceiling Installation Hole Power Network Port Dome Cover Assembly Part Alarm I/O, Audio I/O, Video Out (CVBS) SD Memory Card Slot... - Page 9 Part 1 – Introduction DC-D4236RX(-A) DC-D4237RX IR LED Lens IR LED Factory Reset Button Lens Built-in Microphone Factory Reset Button Wall/Ceiling Installation Hole Wall/Ceiling Installation Hole Power Power Network Port Network Port Dome Cover Assembly Part Dome Cover Assembly Part Alarm I/O, Audio I/O, Video Out (CVBS) Alarm I/O, Audio I/O, Video Out (CVBS) SD Memory Card Slot...
- Page 10 Part 1 – Introduction DC-D4236WRX(-A), DC-D4236HRX(-A) DC-D4236HRX-B IR LED Lens IR LED Factory Reset Button Lens Wall/Ceiling Installation Hole Factory Reset Button Power Wall/Ceiling Installation Hole Network Port Power Alarm I/O, Audio I/O Network Port SD Memory Card Slot Alarm I/O, Audio I/O, Video Out (CVBS)
-
Page 11: Built-In Microphone
For more information on network connection setup, refer to the IDIS Discovery operation manual. The table below shows the network cable specifications. <The network cable specifications>... - Page 12 Go to Remote Setup (System > General) and choose a video out signal. (NTSC or PAL) DC-D4236X(-A), DC- D4236RX(-A), DC-D4236HRX-B only • SD Memory Card Slot Used to insert a micro SD memory card into the camera. (An SLC (Single Level Cell) or MLC (Multi Level Cell) card by San Disk or Transcend is recommended) •...
-
Page 13: Factory Reset
Removing the Dome Cover on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual. - Page 14 Part 1 – Introduction Remove the dome cover. DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4246WX, DC-D4236HRX-B Loosen the screws counterclockwise using the allen wrench provided with the product. Remove the dome cover.
-
Page 15: Inserting A Sd Memory Card
Use the provided guide pattern to check the distance between the screws. DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4246WX DC-D4236HRX-B Push the SD memory card until it disengages from the slot, and then pull it out. - Page 16 Adjust the angle. For more information, refer to the Angle Adjustment. To pass through a thin cable or more than two cables, DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4246WX, it is advised to finish it using silicon to make sure DC-D4236HRX-B waterproofed perfectly. (Silicon finishing part — refer to the bottom image.)
- Page 17 Part 1 – Introduction Use the screws, anchor provided with the camera to secure the install body on a wall or a ceiling. Use the provided guide pattern to check the distance between the screws. Assemble the cable rubber to the bottom cover. Attach the enclosed desiccant in the bottom to prevent moisture.
-
Page 18: Angle Adjustment
• Vertical Rotation Used to adjust the lens' vertical angle. • Horizontal Rotation Used to adjust the lens' horizontal angle. DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4246WX, Turn the horizontal rotator in the clockwise or DC-D4236HRX-B counterclockwise direction. Fasten the screws for the dome cover clockwise using the Allen wrench provided with the camera. -
Page 19: Dimension
Part 1 – Introduction Dimension DC-D4237RX DC-D4236X(-A), DC-D4236RX(-A) 2-R4.50 41.27mm 23.76mm 26.67mm... - Page 20 Part 1 – Introduction DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4246WX, DC-D4236HRX-B Ø 155mm...
-
Page 21: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP® NVR or non DirectIP® NVR, VMS such as IDIS Solution Suite Compact. With DirectIP® NVR-based Layout Audio In Audio Out Alarm Out Power Sensor In Network Camera Monitor Out... -
Page 22: With Non Directip® Nvr-Based Layout
Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP® NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 23: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 10 or below. -
Page 24: Specifications
Max. Resolution 1920 x 1080 Scanning Mode Progressive Scan Lens type Motorized Vari-focal Focal Length DC-D4236X(-A), f=2.8 - 12mm DC-D4236RX(-A), DC-D4236WRX(-A), DC-D4236HRX(-A), DC-D4236HRX-B, DC-D4237RX, DC-D4246WX f=7-22mm Aperture F1.4 - 2.8 Iris Control DC Iris Angular Field DC-D4236X(-A), Wide : 98°(H), 51°(V), 116°(D) -
Page 25: Audio In/Out
Part 3 - Appendix Audio Compression DC-D4236X/ DC-D4236RX/DC-D4236WRX/ DC-D4236HRX/DC-D4236HRX-B/ G.726, ADPCM-16K, G.711u-Law, G.711a-Law DC-D4237RX/DC-D4246WX models only Supported Resolution 1920x1080, 1280x720, 640x360, 352x240 Multi-Video Streaming Quadruple Ethernet RJ45(10/100BASE-T) Edge Storage* (Optional) (Micro SD/SDHC/SDXC memory card (class 6 or higher, max. 256GB)) * An SLC (Single Level Cell) or MLC (Multi Level Cell) card by SanDisk or Transcend is recommended to ensure stable recording performance. -
Page 26: Operating Humidity
Part 3 - Appendix Operating Humidity 0% ~ 90% Power Source DC-D4236X(-A), , PoE(IEEE 802.3af, Class 2) DC-D4246WX DC-D4236RX(-A), DC-D4236WRX(-A), DC-D4236HRX(-A), , PoE(IEEE 802.3af, Class 3) DC-D4236HRX-B, DC-D4237RX Power DC-D4236X(-A), , 0.38A, 4.6W Consumption DC-D4246WX PoE, IEEE 802.3af (Class 2), 4.7W DC-D4236RX(-A), , 0.64A, 7.7W... - Page 27 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
