- Page 1 Network Camera Installation Manual DC-D4236X / DC-D4236RX / DC-D4236WRX / DC-D4236HRX Powered by...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
• Two-way audio communication support for remote compress and transmit video over Ethernet. audio dialog You can use the IDIS Discovery program to change • Video stream buffering to counter pre-/post-event network camera settings or the IDIS Solution Suite buffering and network delays for improved network... - Page 7 Remote monitoring and recording via multi streaming • Network-based integrated management of multiple are available using the IDIS Solution Suite Compact network cameras program. For more information on using IDIS Solution Suite Compact, refer to its operation manual.
-
Page 8: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. DC-D4236WRX, DC- DC-D4236X, DC-D4236RX D4236HRX Terminal Blocks (2 ea.) Network Camera Desiccant Allen Wrench Quick Guide Screws (3 ea.) -
Page 9: Overview
Part 1 – Introduction Overview Body DC-D4236X Dome Cover DC-D4236X, DC-D4236RX DC-D4236WRX, DC-D4236HRX... - Page 10 Part 1 – Introduction DC-D4236RX DC-D4236WRX, DC-D4236HRX IR LED Lens Factory Reset Button Wall/Ceiling Installation Hole Power Network Port Dome Cover Assembly Part Alarm I/O, Audio I/O, Video Out (CVBS) SD Memory Card Slot Cable Rubber • IR LED A sensor in the middle monitors lighting levels and activates the IR LED during low-lighting conditions.
- Page 11 For more information on network connection setup, refer to the IDIS Discovery operation manual. The table below shows the network cable specifications. <The network cable specifications>...
-
Page 12: Factory Reset
It's also possible to do a factory reset by pressing and releasing the reset button while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual. -
Page 13: Installation
For more information on other devices comprising the overall system, refer to their respective installation manuals. Product color and design may vary depending on the model. Removing the Dome Cover DC-D4236X, DC-D4236RX Remove the dome cover. Turn the dome cover counterclockwise. Remove the dome cover. -
Page 14: Inserting A Sd Memory Card
The camera may fall off if the wall or ceiling is not strong enough to support its weight. • Install the camera in a shaded area. If the camera DC-D4236X, DC-D4236RX is installed in direct sunlight, it may be affected adversely. - Page 15 Part 1 – Introduction Use the screws, anchor provided with the camera to DC-D4236WRX, DC-D4236HRX secure the install body on a wall or a ceiling. Use the provided guide pattern to check the Push the network cable through the cable rubber, distance between the screws.
-
Page 16: Angle Adjustment
Part 1 – Introduction Angle Adjustment Closing the Dome Cover The lens can be rotated along three axes. DC-D4236X, DC-D4236RX Attach the dome cover to the bottom cover. Turn the dome cover clockwise to fasten the dome cover. Lens Rotation... -
Page 17: Dimension
Part 1 – Introduction Dimension DC-D4236WRX, DC-D4236HRX DC-D4236X, DC-D4236RX Ø 155mm Ø 122mm... -
Page 18: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Alarm Out Power Sensor In Network Camera Monitor Out... -
Page 19: With Non Directip™ Nvr-Based Layout
Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 20: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below. -
Page 21: Specifications
Aperture F=1.4 Iris Control DC Iris Angular Field of View Wide : 98°(H), Tele : 33°(H) Min. DC-D4236X COLOR : 0.1 lux @ F1.4 Illumination B/W : 0.01 lux @ F1.4 DC-D4236RX, COLOR : 0.1 lux @ F1.4 DC-D4236WRX, B/W : 0 lux (IR LED ON) - Page 22 1 TTL open collector, Max. load: 30mA, Max. voltage: 5VDC Video Out ** 1 BNC ** Video output is limited when using all streams or the pivot function is in operation. General Operating DC-D4236X, -10°C ~ +50°C (14°F ~ +122°F) Temperature DC-D4236RX DC-D4236WRX -20°C ~ +55°C (-4°F ~ +131°F) DC-D4236HRX -40°C ~ +55°C (-40°F ~ +131°F)
- Page 24 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
