- Page 1 INSTRUCTION MANUAL GLASSWASHERS Mod. RB200 RB260 RB215 RB275...
- Page 2 INSTRUCTIONS FOR THE USER FOREWORD 1. Read the instructions contained in the enclosed booklet carefully, because it contains important information on installation, operation and maintenance safety. Store this booklet carefully for any further consultation by other operators. 2. Having removed the packing material, check that all the equipment is present.
- Page 3 INSTRUCTIONS FOR THE USER INSTRUCTIONS FOR USE...
-
Page 4: Control Panel
INSTRUCTIONS FOR THE USER CONTROL PANEL CONTROL PANEL CONTROL PANEL CONTROL PANEL H2 H3 Pilot lamp "machine READY" Pilot lamp "machine WORKING" Main switch GREEN Machine off Machine on / Start cycle Machine on / Drain position (only mod. with drain pump) Push button "CYCLE START"... -
Page 5: Operation And Use
INSTRUCTIONS FOR THE USER OPERATION AND USE 1. Before washing make sure that: • the wall-mounted on/off switch is switched on; • the water tap is open; • water is present in the distribution network; • the pump protection filters are installed in their respective positions; •... - Page 6 INSTRUCTIONS FOR THE USER 6. Remove the rack and slightly incline it to permit a perfect drain; allow dishware to dry and after having washed one’s hands, handle the rack in order not to touch the dishware inside then place the rack on hygienically clean shelves.
- Page 7 INSTRUCTIONS FOR THE USER INSTRUCTIONS DURING THE WASHING 1)Do not plunge bare hands into the water containing the detergent. If this happens, wash them immediately and abundantly with fresh water. 2)When the machine is operating, do not open the door too rapidly. 3)Use only specific anti-foaming detergents.
-
Page 8: Useful Suggestions
INSTRUCTIONS FOR THE USER USEFUL SUGGESTIONS 1) MAINTENANCE IMPORTANT: Before carrying out the cleaning and maintenance operations, disconnect the equipment from the electric supply. Frequently check and clean the nozzles. The frequency of this operation will depend on the quantity of residues, which may result in an unsatisfactory washing result. -
Page 9: Hard Water Conditions
INSTRUCTIONS FOR THE USER 4)SANITIZING THE MACHINE Sanitizing the machine at least once a week is of the utmost importance in order to guarantee hygiene even when the machine is not in use. It is advisable to use a disinfecting product suggested by an authorised detergent dealer. -
Page 10: Installation And Maintenance Instructions
INSTALLATION AND MAINTENANCE INSTRUCTIONS The following instructions are addressed to a qualified personnel the only one authorised to carry out checks and repairs, if any. The manufacturer declines any responsibility in the case of interventions made by a non qualified personnel or the use of spare parts other than those supplied by the Manufacture. -
Page 11: Installation
INSTRUCTIONS FOR TECHNICAL PERSONNEL INSTALLATION During installation, carry out proper machine levelling, which is a prerequisite for a correct operation thereof (max. tolerance 2°). In order to prevent any damage caused by steam going out of the machine, make sure that the surrounding materials do not deteriorate in its presence. After machine installation check thermostat settings, booster 85°C, tank 60°C. -
Page 12: Water Drain
INSTRUCTIONS FOR TECHNICAL PERSONNEL 3)WATER DRAIN Arrange a water drain towards the floor with siphon and connect the machine with the flexible tube given with the machine, so that it leans towards the drain. Moreover, make sure that the hose does not have constrictions. Make sure that the building drain tubing withstands temperatures up to 70°C. -
Page 13: Loading And Unloading Of The Machine
INSTRUCTIONS FOR TECHNICAL PERSONNEL 6) LOADING AND UNLOADING OF THE MACHINE For the transportation of the machine from the delivery point to the final installation position, use a fork lift or adequate lifting equipment used by authorised staff. Lift the machine by its frame, taking care that any protruding parts are not damaged (discharges, wiring etc.). -
Page 14: Wiring Diagram
INSTRUCTIONS FOR TECHNICAL PERSONNEL WIRING DIAGRAM Anti noise filter Condensator Booster heater Tank heater Pilot lamp machine on Pilot lamp machine ready Pilot lamp machine working Rinse pump (if required) Wash pump Drain pump MD Detergent dispenser Main switch Door switch Pressure switch Start switch Regeneration switch (if required... - Page 15 900771 900771 900771 900771 03-2011...
