Comenda lf321; lf322; lf324; lf700 dishwasher
Hide thumbs Also See for LF321:

Advertisement

Manuale di istruzione per
Notice d'utilisation pour
Gebrauchsanweisung für
Instruction manual for
Manual de instrucciones para
LF321 / LF321A
LF322 / LF322A
LF324 / LF324A
LF700 / LF700A
lavastoviglie
lave-vaisselle
Geschirrspüler
dishwashers
lavavajillas
Mod.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LF321 and is the answer not in the manual?

Questions and answers

Summary of Contents for COMENDA LF321

  • Page 1 Manuale di istruzione per lavastoviglie Notice d’utilisation pour lave-vaisselle Gebrauchsanweisung für Geschirrspüler Instruction manual for dishwashers Manual de instrucciones para lavavajillas Mod. LF321 / LF321A LF322 / LF322A LF324 / LF324A LF700 / LF700A...
  • Page 2 INSTRUCTIONS FOR THE USER FOREWORD 1. Read the instructions contained in the enclosed booklet carefully, because it contains important information on installation, operation and maintenance safety. Store this booklet carefully for any further consultation by other operators. 2. Having removed the packing material, check that all the equipment is present.
  • Page 3: Instructions For Use

    INSTRUCTIONS FOR THE USER INSTRUCTIONS FOR USE...
  • Page 4: Control Panel

    INSTRUCTIONS FOR THE USER CONTROL PANEL Main switch Pilot lamp "machine ON" Pilot lamp "machine READY" Pilot lamp "machine WORKING" Push button "CYCLE START" Push button "REGENERATION START" (only mod. LF…A) Cycle selector Plug Salt container (only mod. LF…A) Regulating screw for rinse aid injector...
  • Page 5: Operation And Use

    INSTRUCTIONS FOR THE USER OPERATION AND USE 1. Before washing make sure that: ??the wall-mounted on/off switch is switched on; ??the water tap is open; ??water is present in the distribution network; ??the pump protection filters are installed in their respective positions; ??the overflow in inserted;...
  • Page 6 INSTRUCTIONS FOR THE USER ATTENTION: Machine in conformity with the existing hygienic standards, guaranteeing a final rinse at 85°C. Wash cycle automatically lengthened if final rinse temperature is not reached.When this auto-cycle intervenes and the cycle is pro-longed, after 8 minutes the "H3"...
  • Page 7 INSTRUCTIONS FOR THE USER INSTRUCTIONS DURING THE WASHING 1)Do not plunge bare hands into the water containing the detergent. If this happens, wash them immediately and abundantly with fresh water. 2)When the machine is operating, do not open the door too rapidly. 3)Use only specific anti-foaming detergents.
  • Page 8: Useful Suggestions

    INSTRUCTIONS FOR THE USER USEFUL SUGGESTIONS 1) MAINTENANCE IMPORTANT: Before carrying out the cleaning and maintenance operations, disconnect the equipment from the electric supply. Frequently check and clean the nozzles. The frequency of this operation will depend on the quantity of residues, which may result in an unsatisfactory washing result.
  • Page 9: Sanitizing The Machine

    INSTRUCTIONS FOR THE USER 4)SANITIZING THE MACHINE Sanitizing the machine at least once a week is of the utmost importance in order to guarantee hygiene even when the machine is not in use. It is advisable to use a disinfecting product suggested by an authorised detergent dealer.
  • Page 10: Installation And Maintenance Instructions

    INSTALLATION AND MAINTENANCE INSTRUCTIONS The following instructions are addressed to a qualified personnel the only one authorised to carry out checks and repairs, if any. The manufacturer declines any responsibility in the case of interventions made by a non qualified personnel or the use of spare parts other than those supplied by the Manufacture.
  • Page 11: Installation

    3mm and a supply cable no less than 2.5mm². Modello 220/230V? 220/230V 3? 380/400V 3N? LF321 LF322 LF324 LF700 For other supplies the cable cross section and the circuit breaker switch must be calculated according to voltage and length of cabling. If cabling too long adjust cable size to Amp rating;...
  • Page 12 INSTRUCTIONS FOR TECHNICAL PERSONNEL 2)WATER CONNECTION Install a 55°C water tap in a well accessible place, terminating in a 3/4" fitting, which the pipe strainer and inlet hose shall be connected to. Carefully comply with any national or regional regulations in force. The operating pressure should be neither less than 2 bars or greater that 4 bars (200/400 kPa).
  • Page 13: Loading And Unloading Of The Machine

    Output in capacity consumpt. heater heater pump (W) electric racks per racks per load (W) hour with hour with 55°C inlet 12°C inlet water water LF321 2000 3000 3450 30/20 LF322 2000 3000 3450 30/20 LF324 2000 4200 4650 36/24 LF700...
  • Page 14: Wiring Diagram

    INSTRUCTIONS FOR TECHNICAL PERSONNEL WIRING DIAGRAM Anti noise filter Condensator Booster heater Tank heater Pilot lamp power on Pilot lamp machine ready Pilot lamp machine working Booster heater contactor KE2b Safety contactor of booster heater KM2 Rinse pump contactor (if required) KM3 Wash pump contactor Rinse pump (if required) Wash pump...
