Summary of Contents for Clarke OFR 5/50
- Page 1 Only suitable for well insulated areas and not designed to be the primary heat source 500W OIL FILLED RADIATOR MODEL NO: OFR 5/50 PART NO: 6934015 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC03/23...
-
Page 2: Specification
INTRODUCTION Thank you for purchasing this CLARKE oil filled radiator. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. - Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 Item Symbol Value Unit Heat output Measured seasonal space heating energy efficiency Nominal heat output Minimum heat output (indicative) Maximum continuous heat output Auxiliary electricity consumption At nominal heat output At minimum heat output In standby mode Type of heat input for electric storage local heaters only Manual heat charge control with integrated thermostat...
-
Page 4: Safety Advice
SAFETY ADVICE Make sure that you read, understand and comply with the following. The following symbols appear on the unit. Hot surface, Do not Read the - do not cover manual touch GENERAL SAFETY 1. Read these instructions carefully before using the radiator. 2. -
Page 5: Environmental Recycling Policy
16. DO NOT use the radiator in rooms with explosive gas (e.g. petrol) or while using inflammable glue or solvent (e.g. when gluing or varnishing parquet floors, PVC etc) 17. Extra caution is necessary when the radiator is used near children or when it is left unattended. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 7: Operation
ASSEMBLY The feet for the radiator are supplied loose in the packaging and require fitting. 1. Slide the front foot onto the base plate until it clips into place. 2. Slide the rear foot onto the rear fin of the heater. The fin will slide into the slot in the foot. -
Page 8: Safety Shut-Off
POSITIONING 1. DO NOT operate the radiator unless it is placed in an upright position. 2. Select an indoor location for the radiator away from electrical cables, drapes and other furnishings. 3. DO NOT place radiator directly beneath an electrical outlet, against paper board or low density fibreboard. - Page 9 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 10: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 11 ALTERNATIVE PRODUCTS FROM THE CLARKE RANGE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
