Uvisensor Wiring; Typical 45º Bracket Installation - EIT MULTIBRITE MB100AC1 Operator's Manual

®
MultiBrite Operator's Manual
Figure 5. Typical 45º Bracket Installation

UVISENSOR Wiring

2.3
The cable from the UVISENSOR must be routed to the MultiBrite in such a way so as to avoid contact with
the moving equipment, workpieces, lamp bodies and lamp cabling. Use appropriate cable clamps or ties as
necessary to secure the cable.
CAUTION
Do not allow the UVISENSOR body or cabling to touch the lamp, lamp cabling, or end caps.
Allow at least one inch clearance between the sensor and these areas to prevent arcing or
insulation damage.
WARNING
The ends of the lamp and the cables feeding them may have several thousand
volts present. TURN OFF ALL POWER TO THE EQUIPMENT. UNDER NO
CIRCUMSTANCES SHOULD ANYONE ATTEMPT TO PERFORM
MAINTENANCE WHEN LAMP(S) OR EQUIPMENT ARE POWERED. The
lamps, their end caps, and cabling are very hot. Contact with these areas will
result in serious burns. ALLOW EQUIPMENT TO COOL BEFORE ATTEMPTING
TO CLEAN THE UVISENSOR.
8
