MultiBrite
Operator's Manual
Electronic Instrumentation and Technology, Incorporated
108 Carpenter Drive
Sterling, VA 20164
703/ 478 - 0700
®
MULTIBRITE
UV MONITORING SYSTEM
OPERATOR'S MANUAL
Documentation Control #90-276 Rev C
MODEL #MB100AC1
90 to 132 VAC INPUT
MODEL #MB240AC1
180 to 264 VAC INPUT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EIT MULTIBRITE MB100AC1
Summary of Contents for EIT MULTIBRITE MB100AC1
- Page 1 ® MultiBrite Operator's Manual Electronic Instrumentation and Technology, Incorporated 108 Carpenter Drive Sterling, VA 20164 703/ 478 - 0700 ® MULTIBRITE UV MONITORING SYSTEM OPERATOR'S MANUAL Documentation Control #90-276 Rev C MODEL #MB100AC1 90 to 132 VAC INPUT MODEL #MB240AC1 180 to 264 VAC INPUT...
-
Page 3: Table Of Contents
® MultiBrite Operator's Manual Table of Contents INTRODUCTION..................................3 1.1 S ............................3 IGNAL ONDITIONING ODULE 1.2 S ...............................3 IGNAL ONVERSION ODULE 1.3 D ..................................3 ISPLAY ODULE 1.4 A ..................................3 LARM UTPUTS UVISENSOR INSTALLATION..............................4 2.1 C ..............................4 LAMP AND IRROR ETHOD 2.2 A ..............................6 NGLE RACKET... - Page 4 ® MultiBrite Operator's Manual 1. T ..........................5 YPICAL LAMP AND IRROR NSTALLATION 2. C .................................6 LAMP AND IRROR ETHOD 3. M ................................6 IRROR OUNTING EMPLATE 4. B ............................7 RACKET OUNTING RILL EMPLATE 5. T 45º B .............................8 YPICAL RACKET NSTALLATION 6.
-
Page 5: Introduction
® MultiBrite Operator's Manual INTRODUCTION The MultiBrite System is presented to fill the need for monitoring several UV light sources for the purpose of relaying a single alarm to an operator when any of the sources falls below the specified limit. A MultiBrite System is comprised of three major components, the Signal Conditioning Module, the Signal Conversion Module, and the Display Module, each of which will be described below. -
Page 6: Uvisensor Installation
® MultiBrite Operator's Manual The alarms will not be activated if power has recently been applied to the system. A dip switch programmable time delay from 5 seconds to 21.25 minutes will ensure the lamps will be at full intensity before indicating an alarm condition. -
Page 7: Typical Clamp And Mirror Installation
® MultiBrite Operator's Manual Once a suitable mounting location is determined, a 7/8" diameter hole is drilled or punched in the side of the lamp housing. The clamp is mounted in this hole with the threaded side facing toward the inside of the housing. -
Page 8: Angle Bracket Method
® MultiBrite Operator's Manual Figure 2. Clamp and Mirror Method CENTERLINE OF SENSOR .219 .438 LIGHT SOURCE CENTERLINE OF SENSOR .125 0 HOLE IN MIRROR 4 PLACES CENTER OF MIRROR OPPOSITE SIDE Figure 3. Mirror Mounting Template Angle Bracket Method The other mounting bracket supplied is a reflectorized 45°... -
Page 9: Bracket Mounting Drill Template
® MultiBrite Operator's Manual Figure 5B shows a similar installation with the UVISENSOR looking down at the top of the lamp through a 1/4" diameter hole. In this configuration, the UVISENSOR must look at the lamp and not beside it. This is to prevent the UVISENSOR from seeing reflections from the work surface below the lamp. -
Page 10: Uvisensor Wiring
® MultiBrite Operator's Manual Figure 5. Typical 45º Bracket Installation UVISENSOR Wiring The cable from the UVISENSOR must be routed to the MultiBrite in such a way so as to avoid contact with the moving equipment, workpieces, lamp bodies and lamp cabling. Use appropriate cable clamps or ties as necessary to secure the cable. -
Page 11: Cleaning The Uvisensor And Mirror
® MultiBrite Operator's Manual Cleaning the UVISENSOR and Mirror Whenever the UV lamp or its reflector are cleaned or replaced, the glass window of UVISENSOR should be cleaned at the same time. Before proceeding, turn OFF all power to the UV equipment and allow it to cool. Using a Q-tip dipped in denatured alcohol clean the glass window of the UVISENSOR and wipe it dry with a lint-free cloth. -
Page 12: Signal Output Connections
® MultiBrite Operator's Manual 17 Alarm NC Alarm Common 16 15 Alarm NO Figure 7. Low intensity alarm contact configuration The second set of alarm contacts may be used to verify power has been applied to the MultiBrite System and a control signal has been applied to the Lamp Power Detection Input. -
Page 13: To 10 Volt Output Connections
® MultiBrite Operator's Manual Table 1. Output Selection Table. Caution must be exercised in connecting the signal loads to the system because the four connectors on the back panel are identically the same. For convenience, the signal wiring may be attached to the connector terminal strip before the connector is inserted into the mating back panel connector. -
Page 14: To 20 Ma Output Connections
® MultiBrite Operator's Manual CHANNEL 1 CHANNEL 2 CHANNEL 3 CHANNEL 4 GUARD GUARD 0 TO 10 VOLT 0 TO 10 VOLT 0 TO 10 VOLT 0 TO 10 VOLT Figure 11. 0 to 10 volt connections 2.7.2 4 to 20 mA Output Connections A continuous analog current loop output is available for each of the 4 lamp monitor channels in the MultiBrite System. -
Page 15: Power Connections
® MultiBrite Operator's Manual 0 to 100% Switch Position 3 Switch Position 3 Switch Position 3 Switch Position 3 0 to 5 Volts Table 2. Analog Voltage Output Selection Options. Switches for each of the 4 channels inside the MultiBrite enclosure allow the user to select 3 different continuous analog output options. -
Page 16: Control Connections
® MultiBrite Operator's Manual 24V LAMP Lower Bottom POWER CHANNEL CHANNEL CHANNEL CHANNEL Connector DETECTION (TIMER INITIATION) REMOTE CHANNEL DISABLE INPUTS ALL REQUIRE 24 VOLTS AC OR DC Figure 13. Back Panel Power Connector Definitions Control Connections 2.9.1 Lamp Power Detection Input In addition to the AC power source required to power the MultiBrite System, a Lamp Power Detection Input is required to make the system operational. -
Page 17: Specifications
Operating temperature is 0 to 50 degrees Celsius. Sensor Input Current Range MultiBrite was designed for use with EIT UVISENSORS. Current range through the sensor input terminals is 0.2 to 2.0 microamperes for a "100%" full scale reading. Display reading is adjustable by turning a respective channel's screw slotted "CALIBRATE" control located on the front panel. -
Page 18: Current Loop Output
® MultiBrite Operator's Manual Position 2: 0 to 200% output represented by 0 to 10 volts DC and 4 to 20 mA DC. Position 3: 0 to 100% output represented by 0 to 5 volts DC and 4 to 20 mA DC Refer to section 2.4 for a description of these configurations. -
Page 19: Dimensions
® MultiBrite Operator's Manual Weight approximately forty-eight ounces. Dimensions The enclosure portion is 7.82 inches wide by 3.5 inches high by 6.37 inches deep (7.82”W x 3.5”H x 6.37” The front panel is 9.44 inches wide by 3.5 inches high by 0.125 inches thick (9.44”W x 3.5”H x 0.125”T). Construction Painted aluminum with integral mounting flanges on the front panel. -
Page 20: Calibration And Operation
® MultiBrite Operator's Manual 9 . 4 4 " Figure 16. MultiBrite front view dimensional diagram CALIBRATION AND OPERATION Calibration To calibrate the MultiBrite system, perform the following steps: 1. Make sure that the UVISENSOR(s) and the MultiBrite components have been properly installed (see section 2.1). -
Page 21: Applications
® MultiBrite Operator's Manual APPLICATIONS The MultiBrite is capable of monitoring a curing system with up to four lamps. For curing systems with more than four UV sources, multiple MultiBrites can be cascaded. IMPORTANT The applications are shown using a model MB100AC1 (90 to 130 VAC input) for simplicity. Applications using a model MB240AC1 (180 to 264 VAC input) would use an appropriate transformer (with 24-volt output). -
Page 22: Guidelines For Multibrite Use
® MultiBrite Operator's Manual Guidelines for MultiBrite Use The EIT MultiBrite is a relative intensity radiometer designed to measure the performance of any manufacturer’s Ultra-Violet curing lamp. 5.3.1 Methodology Calibrate each monitored channel to “100%” when a new bulb is installed and (optimally) when new reflectors are installed. -
Page 23: Single Multi Brite Configuration
® MultiBrite Operator's Manual Figure 17. Single MultiBrite configuration. -
Page 24: Multiple Multi Brite Configuration
® MultiBrite Operator's Manual Figure 18. Multiple MultiBrite configuration...
