Siemens ARCADIS Varic Installation And Startup Manual
Installation video splitter
Hide thumbs
Also See for ARCADIS Varic:
- Operator's manual (476 pages) ,
- Start-up instructions (64 pages) ,
- Start-up (48 pages)
Table of Contents
Advertisement
Quick Links
M ü h l h ä u s s e r
ARCADIS
Installation and Startup
System
Installation Video Splitter
Valid for
- ARCADIS Varic
- ARCADIS Orbic
Print No.:
SPR2-310.814.05.02.02
Replaces:
SPR2-310.814.05.01.02
80800017
10047680
SP
2005
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 01.05
written
Advertisement
Table of Contents
Related Manuals for Siemens ARCADIS Varic
Summary of Contents for Siemens ARCADIS Varic
- Page 1 M ü h l h ä u s s e r ARCADIS Installation and Startup System Installation Video Splitter Valid for - ARCADIS Varic - ARCADIS Orbic 10047680 80800017 2005 © Siemens AG The reproduction, transmission or use of this document or its contents is not...
- Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.
-
Page 3: Table Of Contents
Final work steps ........... . 11 3 _______ Changes to Previous Version _____________________________________ 12 Page 3 of 12 Siemens AG SPR2-310.814.05.02.02 ARCADIS Medical Solutions 01.05... -
Page 4: Prerequisites
Part no.: 80 81 882, 1x video split- ter + mechanical components incl. rear cover and if desired Video splitter "Reference" option, 14 400 895 Part no.: 80 81 890, 1x video split- Page 4 of 12 ARCADIS SPR2-310.814.05.02.02 Siemens AG 01.05 CS SD 24 Medical Solutions... -
Page 5: Tools
The product-specific safety information in these instruc- tions The general safety information in the instructions TD00-000.860.01... and The general safety information according to ARTD part 2. Page 5 of 12 Siemens AG SPR2-310.814.05.02.02 ARCADIS Medical Solutions 01.05 CS SD 24... -
Page 6: Work Sequence
"reference" monitor. If only the "live" option is available, carry out the cabling and the mechanical installation for the "live" monitor. Fig. 2: Cables Page 6 of 12 ARCADIS SPR2-310.814.05.02.02 Siemens AG 01.05 CS SD 24 Medical Solutions... - Page 7 (2/Fig. 2 / p. 7. Connect the 2nd piece of the distributor cable (straight plug) to the corresponding moni- tor as shown in (Fig. 2 / p. Page 7 of 12 Siemens AG SPR2-310.814.05.02.02 ARCADIS Medical Solutions 01.05 CS SD 24...
- Page 8 9. Use the supplied kit to pull the VGA cable(s) from location (3/Fig. 2 / p. 6) to the moni- tor(s) and connect it/them to the monitor(s). Run the cables as shown in (Fig. 3 / p. Page 8 of 12 ARCADIS SPR2-310.814.05.02.02 Siemens AG 01.05 CS SD 24 Medical Solutions...
- Page 9 If a video splitter for the reference monitor is available, mount it next to the video splitter for the live monitor. Fig. 5: Wiring diagram 11. Switch the line switch of the video splitter on. Page 9 of 12 Siemens AG SPR2-310.814.05.02.02 ARCADIS Medical Solutions 01.05 CS SD 24...
- Page 10 13. Push the video splitter mount into the monitor trolley slot and screw it on via the threaded plate (Fig. 6 / p. 10). Fig. 7: Slider 14. Connect the external monitors to the corresponding "RGB OUT" connectors on the video splitter. Page 10 of 12 ARCADIS SPR2-310.814.05.02.02 Siemens AG 01.05 CS SD 24 Medical Solutions...
-
Page 11: Final Work Steps
18. Reattach all covers and switch the system on. Final work steps 1. Perform a functional check. 2. Check the image on all connected live and reference monitors. Page 11 of 12 Siemens AG SPR2-310.814.05.02.02 ARCADIS Medical Solutions 01.05 CS SD 24... - Page 12 Changes to Previous Version 3Changes to Previous Version n.a.; initial publication. Page 12 of 12 ARCADIS SPR2-310.814.05.02.02 Siemens AG 01.05 CS SD 24 Medical Solutions...
