A r n o l d
ARCADIS / SIREMOBIL
Installation and Startup
Option
Integrated laser light localizer (single-tank side)
These instructions apply to the installation and start-up of
the laser light localizer 3779001 on the products SIRE-
MOBIL Compact L and SIREMOBIL Iso-C, and the laser
light localizer 8079720 on the products ARCADIS Varic
and ARCADIS Orbic.
Print No.:
SP00-000.814.08.01.02
Replaces: n.a.
SP
2006
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 03.06
written
