A r n o l d
ARCADIS Varic
Replacements of Parts
System
Replacement of Parts
Print No.:
SPR2-310.841.01.07.02
Replaces:
SPR2-310.841.01.06.02
08080017
SP
2005
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 08.07
written

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARCADIS Varic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens ARCADIS Varic

Summary of Contents for Siemens ARCADIS Varic

  • Page 1 A r n o l d ARCADIS Varic Replacements of Parts System Replacement of Parts 08080017 2005 © Siemens AG The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages.
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.

  • Page 3: Table Of Contents

    Removing/replacing the camera ........42 Page 3 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 4 I.I. voltages ............91 Page 4 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...
  • Page 5 Supplement, measuring the tube current ....... . . 95 6 _______ Changes to the previous version __________________________________ 97 Page 5 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 6: Required Documents

    Prerequisites Required documents 1Prerequisites • ARCADIS Varic wiring diagram • For the laser targeting device as applica- Adjustment instructions/laser targeting ble: device RXR2-130.032.01.. Required tools, measurement devices, and accessories NOTE All tools, measurement devices, and accessories with the excep- tion of those marked with a "*" are listed along with their specifi- cations in the STC (Service Tools Catalog).

  • Page 7: Text Emphasis

    NOTE NOTE contains information provided with special emphasis to facilitate proper use of the equipment or proper execution of a procedure, i.e. hints, tips. Page 7 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 8: Symbols

    This symbol means "Dangerous voltage". This symbol means "Attention, refer to the documentation". This symbol indicates components sensitive to electrostatic discharge (ESD). Page 8 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 9: Service, Shutdown, Hibernation, Handover To The Customer

    <Options>-<End Ses- sion>-<Shut Down System>. Switch off via hibernation (on/off button on the monitor trolley) is not sufficient. Page 9 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 10: Safety Information And Protective Measures

    TD00-000.860.01 must be observed. CAUTION Electrical voltage! Non-compliance can result in material damage. When working on the system, ESD regulations must be observed. Page 10 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 11: Radiation Safety Information

    > 50 degrees Celsius. To avoid burns, switch off the system and let it cool down for at least 5 minutes before touching any parts or components. Page 11 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 12: Safety Information - Risk Of Infection

    NOTE Laser emissions! There is no immediate danger to the eye (blinking reflex). Never- theless, do not look directly into the laser beam. Page 12 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 13: Information On The Protective Conductor Resistance Test

    The protective conductor resistance must not exceed 0.2 Ohms. Page 13 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 14 DIN VDE 0751-1/2001-10, Fig. C2. Pos. 1 = System Pos. 2 = Application part type B (if available) Pos. 3 = Measurement setup (integrated into measuring device) Page 14 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 15: System Leakage Current Measurement Information

    Observe the instructions in the "Safety Rules for Installation and Repair" (ARTD-002.731.17 ...). Page 15 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 16 Fig. 2: Measuring circuit for measuring the system leakage current according to the differential current method in compliance with DIN VDE 0751-1/2001-10, Fig. C6 for protection Page 16 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...
  • Page 17 DIN VDE 0751-1/2001-10, Fig. C5 for protection class I. Pos. 1 = System Pos. 2 = Application part type B (if available) Pos. 3 = Measurement setup (integrated into measuring device) Page 17 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 18 2.5 mA is not exceeded. The evaluation is not necessary in the case of a new determination. File the protocol sheet in the system binder or log book. Page 18 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 19: Information On Navigation Systems Installed As Options

    Integrated laser light localizer option (geometric alteration) I.I.laser light localizer option (weight alteration) 2D Navigation Option (Attachment of altered mounting ring to I.I.) Page 19 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 20: Cover Panels

    7. Once again, use sealing compound 2049716 to seal the SIREPHOS cover completely. 8. Refasten the SIREPHOS cover with the cover screws. If necessary, apply side pres- sure to the SIREPHOS cover until the sealing compound hardens. Page 20 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 21: Monitor Trolley

    3. Remove the lower back cover to access the power supply. 4. Remove the front cover to access the imaging system (front). Installing the cover panels 1. Install the covers in reverse order. Page 21 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 22: Concluding Steps

    After completing all work steps and closing all the cover panels, perform the protective conductor test in accordance with ARTD-002.731.17... The protective conductor resistance must not exceed 0.2 Ohms. Page 22 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 23: D1 Control Board

    9. Restore the main system parameters (path: <Service>-<Backup & Restore> "Pack- ages" - "Main System"). 10. Perform a generator adjustment (path: <Service>-<Main System>-<Adjust- ment>-<Generator Adjust.>). Page 23 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 24 Page 24 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 25: D2 Power Board

    7. Perform the kV offset adjustment and the generator adjustment (filament learning). 8. Test the FL/PFL/DR and direct exposure functions, if there is a cassette holder. Page 25 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 26: D3 Interface Board

    2. Check the +26.75 V voltage for the I.I. mini-voltage supply. Adjust it, if necessary. Refer to chapter 3 of these instructions, Checking the Operating Voltages. 3. Check the radiation release/format switchover/vertical column movement functions. Page 26 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 27: D40 Board For Downward Movement Of The Lifting Column

    1. Replace the D40 board. 2. Using the operating instructions for the basic system, check both the movements of the C-arm and the signal messages. Page 27 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 28: M14 Power Supply, +5 V/+15 V/-15 V

    1. Replace the power supply. 2. Check the power supply voltage and adjust it if necessary. Refer to chapter (Voltages / p. 89). Page 28 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 29: M13 Power Supply 230V/13V

    Switch the system power supply off and disconnect the power plug. 1. Replace the power supply. 2. Check the power supply voltage according to chapter (Voltages / p. 89). Page 29 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 30: I.i. Mini-Voltage Supply

    4. Check the functions and adjustments of the collimator. Readjust them, if necessary. 5. Check the display functions and the setting of the blades on the monitor. Adjust them, if necessary. Page 30 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 31: Spellman I.i. Mini Voltage Supply

    5. Check the display functions and the setting of the blades on the monitor. Adjust them, if necessary. 6. Check the overall resolution according to the IQ test. 7. Perform the IQ test. Page 31 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 32 Page 32 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 33: Collimator

    6. Remove the old set of collimator labels near the SIREPHOS and attach the included new labels in the same position. 7. Check that the original collimator labels are the same as the new ones. Page 33 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 34: Exchanging The Sirephos

    25. Check the display of the blades on the monitor screen and adjust it as necessary. 26. Check collimation for direct exposure if there is a cassette holder. 27. Reinstall the rubber stop. Page 34 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...
  • Page 35 Adjustment Instructions for the Laser Targeting Device, RXR2-130.815.01. 30. Reattach the SIREPHOS cover. 31. Seal the SIREPHOS cover using sealing compound. See chapter 1, (Cover panels / p. 20). Page 35 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 36: Replacing The Camera And The I.i. Optics (Camera Version ≥ 2.0)

    Main System - Replacing Components Replacing the camera and the I.I. optics (camera version ≥ 2.0) Relevant systems: ARCADIS Varic system serial no. 10218, 10219, 10222 and systems with serial no. > 10223; camera version ≥ 2.0 (see ID label).

  • Page 37: Removing/Replacing The I.i. Optics

    Page 37 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 38: Adjusting The Camera And I.i. Optics (Camera Version ≥ 2.0)

    Main System - Replacing Components Adjusting the camera and I.I. optics (camera version ≥ 2.0) 2.10 Relevant systems: ARCADIS Varic system serial no. 10218, 10219, 10222 and systems with serial no. >10223; camera version ≥ 2.0 (see ID label). Fig. 8:...

  • Page 39: Camera Focus

    5. Perform the IQ test. NOTE Adjusting the camera focus also has a slight effect on the repro- duction scale. The reproduction scale adjustment may have to be repeated. Page 39 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 40 Page 40 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 41: Replacing The Camera And The I.i. Optics (Camera Version < 2.0)

    Replacing the camera and the I.I. optics (camera version < 2.0) 2.11 Relevant systems: ARCADIS Varic serial no. < 10218 and 10220, 10221, 10223; or the camera was already replaced with the new camera version ≥ 2.0 (see ID label).

  • Page 42: Removing/Replacing The Camera

    6. Install the (new) camera in reverse order. 7. Adjust the camera and I.I. optics. 8. Perform the IQ test. 9. Complete the country-specific acceptance (§16 partial acceptance... /DHHS...). Page 42 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 43: Removing/Replacing The I.i. Optics

    Page 43 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 44: Adjusting The Camera And I. I. Optics (Camera Version < 2.0)

    Adjusting the camera and I. I. optics (camera version < 2.0) 2.12 Relevant systems: ARCADIS Varic serial no. < 10218 and 10220, 10221, 10223; or the camera was already replaced with the new camera version ≥ 2.0 (see ID label).

  • Page 45: Centering The Camera

    Prerequisites: Camera centering should be OK. 1. Loosen the clamping screw (4/Fig. 11 / p. 44). 2. Loosen the lock ring (5/Fig. 11 / p. 44). Page 45 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 46: Camera Focus

    5. Perform the IQ test. NOTE Adjusting the camera focus also has a slight effect on the repro- duction scale. The reproduction scale adjustment may have to be repeated. Page 46 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 47 Page 47 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 48: Replacing The I. I

    1. Rotate the C-arm so that the I.I. is on top. 2. Remove the I. I. cover (see (1/Fig. 13 / p. 48)) and unsolder the cassette switch. Page 48 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 49: Installing The New I.i

    7. Perform the IQ test. Check the resolution first and readjust the optical resolution of the I.I. optics if necessary. Refer to the previous description "Adjusting the Camera and I.I. Optics". 8. Complete the country-specific acceptance (§16 partial acceptance... /DHHS...). Page 49 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 50 Page 50 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 51: Dose Area Product Measuring Device

    Perform a DAP accuracy check if DAP display is configured on the monitor. Perform an Air Kerma accuracy check if Air Kerma display is configured on the monitor. Page 51 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 52: Laser Targeting Device (Sirephos-Side)

    3. Adjust the laser diodes using the adjustment device supplied with the laser targeting device. 4. Reattach the SIREPHOS cover. 5. Seal the SIREPHOS cover using sealing compound. See chapter 1. Page 52 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 53: Integrated Laser Light Localizer (I.i. -Side)

    Page 53 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 54: Replacing The C-Arm Rollers

    1. Push a wooden block or other stable object of sufficient height under the middle of the basic unit (1/Fig. 14 / p. 54). Fig. 14: Securing the basic unit Page 54 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 55: Set The C-Arm And Lifting Column To The Working Position

    1. The C-arm can now be turned completely out of the C-arm support. 2. Make sure that the image intensifier and C-arm always remain on the table. 3. All rollers are now accessible. Page 55 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 56: Replacing The Rollers And Reinstalling The C-Arm

    5. If a cassette holder is present, check the cassette exposure collimation. 6. If a laser targeting device is present, check the function of the laser targeting device. 7. If the optional Diamentor is present, check its functioning. Page 56 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...
  • Page 57 Page 57 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 58: Replacing The Power Supply Assembly

    5. Unscrew the 6 screws from the lower rear cover and remove the cover (cover already removed in (Fig. 15 / p. 58)). 6. Unscrew the 4 Allen screws (2/Fig. 15 / p. 58) for the power supply component. Page 58 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 59 14. Unplug the PC connectors D 66 X4 (BNC) and D66 X5 (Fig. 22 / p. 68) and pull these cables down. 15. Remove the cable clamps from the SG-cable and the power cable. Page 59 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 60 20. Install the new power supply component in reverse order. 21. Reconnect all power plugs to the UPS. 22. Switch on the system and carry out a functional test. Page 60 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 61: Replacing The Ups

    5. Switch on the new UPS at its power switch. 6. Install the new UPS component in reverse order. 7. Switch on the system and carry out a functional test. Page 61 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 62 As long as the power plug of the monitor trolley is plugged in the mains voltage wall socket, the UPS battery will be charged. Page 62 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 63: Replacing The Ups Battery

    Use tools with insulated handles. UPS MGE Type 800 Fig. 18: Replacing the UPS_battery_1 Page 63 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 64 10. Install the UPS plastic cover “MGE UPS Systems”. 11. Switch on the UPS by pressing the power switch on the UPS. 12. Insert the UPS component in reverse order into the monitor trolley. Page 64 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 65: Mge Ups Type 850

    7. Disconnect the battery connector in front of the battery and pull the battery out of the slot. 8. Insert the new battery into the UPS. 9. Connect the battery connector in front of the battery. Page 65 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 66 As long as the power plug of the monitor trolley is plugged in the mains voltage wall socket, the UPS battery will be charged. Page 66 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...

  • Page 67: Replacing The Keyboard

    2. Lift the keyboard upward out of the monitor trolley. 3. Unplug the keyboard connectors. 4. Install the new keyboard in reverse order. 5. Carry out a functional test. Page 67 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 68: Replacing The Pc

    8. Switch on the system and install the software according to the "System Software Instal- lation" instructions. 9. Carry out a functional test and an IQ Quick test. Page 68 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...
  • Page 69 Page 69 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 70: Replacing Pc Covers

    5. Hold the green unlocking button depressed and slide the casing side cover upwards in the direction of the arrow (2/Fig. 23 / p. 70). 6. Pull the side cover out of the casing. PC M450 Page 70 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 71 5. Slide the side cover approximately 2cm (a/Fig. 25 / p. 71) in the direction of the arrow (1/Fig. 25 / p. 71), until it reaches the stop. Page 71 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 72: Removing The Front Panel

    5. The TCD cable is long enough so that you can carefully place it to one side with the front panel. You do not need to unplug the cable before removing the front panel. PC M450 Page 72 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07...
  • Page 73 5. If necessary, detach the pivot axle on the right-hand side of the front panel from the cas- ing and carefully remove the front panel. Page 73 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 74: Replacing The Drive

    10. Reinstall the PC in reverse order and reconnect the PC plugs (see (Fig. 22 / p. 68)). 11. Carry out a functional test. PC M450 Page 74 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 75 11. Close the casing in reverse order. 12. Reinstall the PC in reverse order and reconnect the PC plugs (see (Fig. 22 / p. 68)). 13. Carry out a functional test. Page 75 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 76: Replacing The Lithium Battery

    Prerequisite: The software installation CD/DVD for the system (includes BIOS installa- tion) must be available. PC M420 and M430 Fig. 30: Replacing the lithium battery_1 PC M450 Page 76 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 77 Monitor Trolley - Replacing Components Fig. 31: Components M450_ Fig. 32: Replacing the lithium battery Page 77 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 78: Restoring Bios Settings (Necessary After Battery Replacement)

    - If the system is unintentionally switched off during BIOS installa- tion, it may be necessary to press the reset key (2/Fig. 21 / p. 67) with a pin shaped object. Page 78 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...
  • Page 79 At this time a restore of the BIOS settings is only possible together with the complete software installation procedure. --> Perform software installation according to instruction SPR2-310.816.02... Page 79 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 80: Replacing A Pci Board Pc M420 And M430 (E. G. Cipp Board)

    Monitor Trolley - Replacing Components Replacing a PCI board PC M420 and M430 (e. g. CIPP board) Fig. 33: Replacing a PCI board_1 Page 80 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 81 Monitor Trolley - Replacing Components Fig. 34: Replacing a PCI board_2 Fig. 35: Replacing a PCI board_3 Page 81 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 82 Page 82 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...

  • Page 83: Replacing A Pci Board Pc M450 (E. G. Cipp Board)

    Monitor Trolley - Replacing Components Replacing a PCI board PC M450 (e. g. CIPP board) Fig. 36: Removing the side fan M450_ Fig. 37: Components M450_ Page 83 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 84 13. Reinstall the PC in reverse order and reconnect the PC plugs (see (Fig. 22 / p. 68)). 14. Carry out a functional test and an IQ Quick test. Page 84 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...
  • Page 85 Page 85 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 86: Replacing Or Installing A Double Usb Slot Pc M420 And M430

    Replacing or installing a double USB slot PC M420 and M430 (optional for CAN converter) 3.10 Fig. 39: Replacing or installing a double USB slot_1 Page 86 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
  • Page 87 5. Reinstall the double USB connector in the slot assembly. 6. Position and connect the USB cable as shown in (Fig. 41 / p. 87). Page 87 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 88 70). 9. Reinstall the PC in reverse order and reconnect the PC plugs (see (Fig. 22 / p. 68)). 10. Carry out a functional test. Page 88 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 89: Monitor Trolley Voltages

    230 V ~ to 246 V ~ Paper printer = option Paper printer UPS input X4.2 -- X4.3 230 V ~ to 246 V ~ Supply voltage Page 89 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 90: Main System Voltages

    D3X1.9 -- D3 X1.7 n.a. n.a. 200V~ +15V Generator line filter n.a. n.a. Z1.3 -- Z1.4 230V~ +16V M14 N.2 -- M14 N.1 n.a. n.a. Page 90 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 91: Voltages

    3. Tab. 1 Test points and voltage divider ratio Voltage Test point Test point Voltage divider Ground (0V) ratio TP G 1:100 TP G 1:200 Page 91 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 92 • If needed, select the next I.I. zoom format and repeat the voltage adjustments for the electrodes E, E2 and E3 for the I.I. zoom format. Page 92 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP...
  • Page 93 Page 93 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...

  • Page 94: Brake Force Calibration

    Fig. 43: Angulation brake_2 • Remove the plug (1/Fig. 42 / p. 94) and adjust the angulation brake with a 6 mm Allen (1/Fig. 43 / p. 94). Page 94 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 95: Lubricating The Vertical Column

    2. Remove jumper X97 from board D1. 3. Connect the mA measuring device at D1.X39 and D1.X40. 4. Switch the system ON. 5. Release radiation and read the overall current. Page 95 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 96 At 110 kV, an overall current of 5.275 mA is measured. 110 [kV] tube current [mA] = 5.275 [mA] - ___________ = 5.275 [mA] - 0.275 [mA] = 5.0 [mA] 400 [MOhm] Page 96 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...

  • Page 97: Changes To The Previous Version

    Changes to the previous version 6Changes to the previous version Section “Adjustment of the angulation brake” added. Page 97 of 98 Siemens AG SPR2-310.841.01.07.02 ARCADIS Varic Medical Solutions 08.07 CS PS SP...
  • Page 98 Changes to the previous version Page 98 of 98 ARCADIS Varic SPR2-310.841.01.07.02 Siemens AG 08.07 CS PS SP Medical Solutions...
