Linear Technology DC1562B Demo Manual page 7

DefaUlt circUit configUrations for each Version
Figure 9. DC1562B-G, Rising Edge Triggered 100ms Positive Output Pulse One-Shot
Figure 10. DC1562B-H, Rising Edge Retriggered 100ms Positive Output Pulse One-Shot
Figure 11. DC1562B-I, Falling Edge Triggered 100ms Positive Output Pulse One-Shot
DEMO MANUAL DC1562B
LTC6993-1
1 6
TRIGGER TRIG OUT
2 5
+
GND
V
3 4
SET DIV
R
SET
154k
LTC6993-2
1 6
TRIGGER TRIG OUT
2 5
+
GND
V
3 4
SET DIV
R
SET
154k
LTC6993-3
1 6
TRIGGER
TRIG OUT
2 5
+
GND
V
3 4
SET DIV
R
SET
154k
OUTPUT
+
V (5V)
0.1µF R
DIV1
1000k
R
DIV2
523k
DC1562b F09
OUTPUT
+
V (5V)
R
0.1µF
DIV1
1000k
R
DIV2
523k
DC1562b F10
OUTPUT
+
V (5V)
R
0.1µF
DIV1
1000k
R
DIV2
523k
DC1562b F11
dc1562bfa
7
