DEMO MANUAL DC1562B

Using the Demo BoarD

Table 1. Standard Configuration for Each Version
DEMO BOARD
NUMBER LTC PART NUMBER
DC1562B-A LTC6990
DC1562B-B LTC6991
DC1562B-C LTC6992-1
DC1562B-D LTC6992-2
DC1562B-E LTC6992-3
DC1562B-F LTC6992-4
DC1562B-G LTC6993-1
DC1562B-H LTC6993-2
DC1562B-I LTC6993-3
DC1562B-J LTC6993-4
DC1562B-K LTC6994-1
DC1562B-L LTC6994-2
DC1562B-M LTC6995-1
DC1562B-N LTC6995-2
* Rising Edge Triggered
** Falling Edge Triggered
2
PART MARKING FUNCTION
LTDWW HF OSC
LTDWY LF OSC
LTDXB PWM
LTDXD PWM
LTFCQ PWM
LTFCS PWM
LTDXG One-Shot
LTDXJ One-Shot
LTFMH One-Shot
LTFMK One-Shot
LTFCV Delay
LTFCX Delay
LTGJN POR
LTGJQ POR
CONFIGURED FUNCTION
1kHz to 10kHz Voltage Controlled Oscillator
1Hz (1Sec) Fixed Frequency Oscillator
10kHz 0% to 100% Duty Cycle PWM
10kHz 5% to 95% Duty Cycle PWM
10kHz 0% to 95% Duty Cycle PWM
10kHz 5% to 100% Duty Cycle PWM
RET* 100ms Positive Output Pulse
RET* Retriggerable 100ms Positive Output Pulse
FET** Positive 100ms Output Pulse
FET** Retriggerable 100ms Positive Output Pulse
Output Falling Edge Delayed 100ms from Input Falling Edge
Output Rise/Fall Edges Delayed 100ms from Input Rise/Fall Edges
1sec Power on Reset
1sec Power on Reset
