YOKOGAWA 751534-J2 User Manual

User's
Manual
1.

Contents of the Package

2.

Conventions Used in This Manual

3.

Safety Precautions

Model 751534-J2
RACK MOUNTING KIT
For a JIS-compliant Dual-housing Rack
Check that the following components are included in the package. If items are missing or
if there is a problem with the appearance of the items, contact your nearest YOKOGAWA
dealer.
Part Name Quantity
Left rack frame 1 pc.
Right rack frame 1 pc.
Center bracket 2 pcs.
Upper bracket 1 pc.
Rear bracket 1 pc.
WARNING
Calls attention to actions or conditions that could cause serious or
fatal injury to the user, and precautions that can be taken to prevent
such occurrences.
CAUTION
Calls attention to actions or conditions that could cause light injury to
the user or damage to the instrument or user's data, and precautions
that can be taken to prevent such occurrences.
French
AVERTISSEMENT
ATTENTION
Note
Calls attention to information that is important for the proper operation
of the instrument.
This product is designed to be used by a person with specialized knowledge.
The general safety precautions for this product and the measuring instruments used
in combination with this product must be observed during all phases of operation.
If the product and the measuring instruments are used in a manner not specified in
the respective manuals, the protection provided by the product and the measuring
instruments may be impaired.
This manual is part of the product and contains important information. Store this manual
in a safe place close to the product so that you can refer to it immediately. Keep this
manual until you dispose of the product. YOKOGAWA assumes no liability for the
customer's failure to comply with these requirements.
This product is used to connect measuring instruments and mount them on a rack. Do
not use it for anything other than its intended purpose.
4th Edition : November 2021 (YMI)
All Rights Reserved. Copyright © 1996 Yokogawa Electric Corporation
All Rights Reserved. Copyright © 2021 Yokogawa Test & Measurement Corporation
Printed in Japan
Part Name
Countersunk head screw (M4 × 14 mm)
Countersunk head screw (M3 × 8 mm)
Binding screw (M4 x 6 mm)
Binding screw (M3 x 14 mm)
Cover sticker
Attire l'attention sur des gestes ou des conditions
susceptibles de provoquer des blessures graves (voire
mortelles), et sur les précautions de sécurité pouvant
prévenir de tels accidents.
Attire l'attention sur des gestes ou des conditions
susceptibles de provoquer des blessures légères ou
d'endommager l'instrument ou les données de l'utilisateur,
et sur les précautions de sécurité susceptibles de
prévenir de tels accidents.
*IM 751534-J2-01E/4*
Quantity
8 pcs.
2 pcs.
1 pc.
1 pc.
8 sheets
IM 751534-J2-01E (1/5)
4th Edition
