Software Overview
As shown in Figure 3-4, the GUI opens to the Audio Config tab.
Before changing any parameters, check the lower left corner of the PPC3 window, as shown in
verify that the EVM is connected. If no EVM is detected, the text will read ADCx120 offline. If the EVM is
detected, a Connect button appears. Clicking this button connects the hardware.
When the hardware is connected, the Connect button changes to read Disconnect, and the device is ready to be
configured.
