- Page 1 USER MANUAL ENGLISH NRG-12A Product code: D3655 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 NRG-12A Preface Thank you for purchasing this DAP product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
NRG-12A Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Text Conventions ..............................4 Symbols and Signal Words ..........................5 Symbols on the Information Label ........................5 Safety ..................................6 Warnings and Safety Instructions ........................6 Requirements for the User .......................... - Page 4 NRG-12A Instructions for Transportation ........................29 Storage ................................29 10. Disposal ................................29 11. Approval ................................29 Product code: D3655...
-
Page 5: Introduction
After unpacking, examine the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● DAP NRG-12A ● Schuko to Power Pro cable (1,5 m) ● User manual Fig. 01 Intended Use This device is designed to be used as an active full-range loudspeaker. -
Page 6: Symbols And Signal Words
NRG-12A Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 7: Safety
NRG-12A Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions... - Page 8 NRG-12A WARNING Stability hazard The device may fall if it is mounted on a distance pole, causing personal injury or death. The device is for use only with the stands that are recommended in this user manual. ● Make sure that the device is safely mounted on a distance pole.
-
Page 9: Requirements For The User
NRG-12A Attention Do not expose the device to conditions that exceed the rated IP class conditions. This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater than 12 mm, such as fingers, and no protection against harmful ingress of water. -
Page 10: Description Of The Device
Description of the Device The DAP NRG-12A is a 180 W RMS active full-range speaker. It has dedicated line and microphone inputs and is equipped with Bluetooth 5.0 with TWS (True Wireless Stereo). The device has an internal DSP with 4 modes. -
Page 11: Back View
NRG-12A Back View 04) DSP button and selector with LED indicators 05) Status LED indicators 06) Master gain control 07) Line-level gain control 08) Bluetooth signal gain control 09) BT pairing LED indicator 10) BT pairing button 11) BT stereo button... -
Page 12: Product Specifications
NRG-12A Product Specifications Model: DAP NRG-12A Physical: Dimensions: 345 x 575 x 360 mm (W x H x D) Weight: 15,5 kg Outputs: Power amplifier RMS output: 180 W Power amplifier peak output: 360 W Main outputs: Audio Specifications: THD level: <... -
Page 13: Optional Accessories
NRG-12A Optional Accessories You can additionally purchase the following accessories: ● D8600 Speaker Stand ● D8601 Speaker Stand 35mm Alu ● D8602 Speaker Stand with Baseplate ● D8436 Speaker hanging eye/ring 10mm (Black) ● D8610 Distance Tube 35 mm ●... -
Page 14: Installation
NRG-12A Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. Installation must be carried out only by instructed persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. ●... -
Page 15: Mounting Options
NRG-12A Mounting Options The device can be mounted on a pole, on a speaker tripod, suspended from an overhead structure with cables/chains, or mounted to a truss with a clamp. See 3.5. Optional Accessories on page 12. The device has 2 mounting openings on the bottom for upright (0°) or inclined installation (5°) on a pole and 3 rigging points (on the top and at the back) for suspended installation. -
Page 16: Installation On A Distance Pole
NRG-12A Installation on a Distance Pole You can stack the device on top of a subwoofer with a distance pole. See 3.5. Optional Accessories on page 12. To mount the device on a distance pole: Place the subwoofer on a level stable surface. -
Page 17: Overhead Suspension
NRG-12A Overhead Suspension CAUTION Restrict the access under the work area during installation and/or deinstallation. You can suspended the device on an overhead structure from the 3 rigging points with rigging eyes. See 3.5. Optional Accessories on page 12. To suspend the device, follow the steps below: Use a hex key to remove the 3 hex screws from the 3 mounting openings (01) and (14). - Page 18 NRG-12A Make sure that the rigging eyes are fully seated and oriented in the plane of pull. Suspend the device on the overhead structure with suitable suspension cables/chains. Note: If the rigging eyes are removed, reinstall the hex screws in the 3 mounting openings (01) and (14). If...
-
Page 19: Overhead Mounting With A Clamp
NRG-12A Overhead Mounting with a Clamp CAUTION Restrict the access under the work area during installation and/or deinstallation. You can mount the device with a clamp to a truss. See 3.5. Optional Accessories on page 12. To mount the device, follow the steps below: Use a hex key to remove the hex screw from the 2 mounting openings (01). -
Page 20: Setup
NRG-12A Setup Warnings and Precautions Attention Connect all cables before supplying power. Disconnect power supply before connecting or disconnecting cables. Connecting Multiple Devices You can connect 2 or more active full-range speakers in a daisy-chain. Use a 3-pin XLR cable to connect the 3-pin XLR mix connector OUT (17) of the 1... -
Page 21: Setup With An Audio Mixer
NRG-12A Setup with an Audio Mixer You can use the NRG-12A in a setup with an audio mixer. In this setup you can connect 2 active full- range speakers NRG-12A to 1 or 2 active subwoofers (NRG-12SA/15SA/18SA). To complete the setup, follow the steps below: Make sure that all devices are switched off. -
Page 22: Setup With 1 Active Subwoofer
NRG-12A Setup with 1 Active Subwoofer To connect 2 full-range speakers to 1 subwoofer (NRG-12SA/15SA/18SA), follow the steps below: Use a 3-pin XLR cable to connect the combined line-level connector IN (18) of the 1 active full- range speaker to the 3-pin XLR connectors THRU A of the active subwoofer. -
Page 23: Setup Without An Audio Mixer
NRG-12A Setup without an Audio Mixer You can use the NRG-12A in a setup without an audio mixer and connect it to a 2 active full-range speaker NRG-12A. In this setup the device functions as a mixer, combining all input signals. -
Page 24: Setup With A Streaming Source Device
NRG-12A Setup with a Streaming Source Device The NRG-12A has an integrated Bluetooth receiver with TWS (True Wireless Stereo). You can pair the NRG-12A with a personal computer or a smartphone with Bluetooth (a streaming source device) to stream sound. -
Page 25: Stereo Mode
NRG-12A Stereo Mode In stereo mode 1 active full-range speaker is paired with the streaming source device and a 2 active full-range speaker is linked to the 1 active full-range speaker. The 1 active full-range speaker, connected to the streaming source device, outputs the left channel of the stereo signal and the 2 active full-range speaker outputs the right channel of the stereo signal. -
Page 26: Operation
NRG-12A with a personal computer or a smartphone with Bluetooth (a streaming source device) to stream sound. You can also link 2 NRG-12A devices to use them in stereo mode. See 5.5. Setup with a Streaming Source Device on pages 23–24. -
Page 27: Linking To Another Device
Linking to Another Device You can link one NRG-12A to another NRG-12A via Bluetooth to stream sound in stereo mode. Press and hold down the BT stereo button (11) until the BT stereo LED indicator (12) starts flashing to link the devices. -
Page 28: Led Statuses
NRG-12A 6.6. LED Statuses The device has 4 status LED indicators (05) and a clip LED indicator (20). The LED indicators have the following statuses: ● Protect: Illuminates when the amp is overloaded. This can happen when the input signal is too high or when the ambient temperature is too high. -
Page 29: Maintenance
NRG-12A Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ● There are no deformations on the housing. -
Page 30: Deinstallation, Transportation And Storage
Approval Hereby, Highlite International declares that the device NRG-12A, product code D3655, is in compliance with Directive 2014/53/EU (RED – Radio Equipment Directive). The full text of the EU declaration of conformity is available at the respective product page on the website of Highlite International (www.highlite.com). - Page 31 NRG-12A Product code: D3655...
- Page 32 ©2023 DAP...
