Installation and Operation
D
F
J
K
L
M
Figure 3-41. SNMPv3
Letter Setting Name
D Enable SNMP.
E Select SNMP version SNMPv3.
F Add user.
G Delete entry.
User name. Requests will be rejected if mes-
H
sage does not include matching user name.
Access Level (None, Read Only, Read
J
Write).
Authentication Level setting (No authentica-
K
tion, MD5, SHA).
Encryption setting (No Encryption, 128-bit
L AES, 256-bit AES-Blumenthal, 256-bit AES-
Reeder)
M Save settings.
24
SNMP Notifications
E
G
H
014611
Letter
1. See
2. Tap the checkbox to enable SNMP traps to be set.
3. Select "Send Heartbeat" (D) checkbox to send out
4. Select "Send at Power Up" (E) checkbox to send
5. Select "Send Alarms and Warnings" (F) checkbox
6. Select "Send Events" (G) checkbox to send Power
7. To add notification targets, tap the "Add Notification
8. To delete a particular notification target, tap the
9. Tap the "Apply Changes" button (L) to save all
C
D
G
L
Figure 3-42. SNMP Notifications
Setting Name
A Notifications tab selected.
B Enable SNMP Traps to be sent.
C Notification Options.
D Select to send out periodic message.
E Select to send message at Gateway startup.
Select to send Power Zone Alarms and Warn-
F
ings in SNMP messages.
Select to send Power Zone events in SNMP
G
message.
H Add SNMP manager address.
J IP address of SNMP manager.
K Delete notification target entry.
L Apply changes.
3-42. Select the "Notifications" tab.
Figure
periodic notifications.
notifications at startup.
to send SNMP alarm and warning messages.
Zone Events.
Target" tab and enter the corect IP address.
trash button (K) on the right side of the screen.
settings.
Owner's Manual for Power Zone Gateway on PZ 410
A
B
E
F
K
J
H
