NOTICE:
There are corrections pages 50 and 55 in this document.
M38000T2-CPE
Supported Devices:
740 Family
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corporation without notice. Please review the latest information published
by Renesas Electronics Corporation through various means, including the Renesas Electronics
Corporation website (http://www.renesas.com).
www.renesas.com
User's Manual
Rev.6.00 Oct 2010
