Belt Drive
Wood Components (Included with Kit)
Part #
Description
QR2
XY Stepper Motor
Mount
Required Hardware
Part #
Description
Flanged Bearing
H86
F635Z
M5 x 30 Machine
H48
Screw
M5 Lock Nut
H49
Idler Fender
H50
Washer
H89
Small Black
Washer
GT2 Pulleys
H84
H37
M3 x 10 Machine
Screw
H88
M3 Washer
Qty
3
Qty
12
6
6
18
12
3
12
12
9
