Instructions - Parts
Enclosed Wetcup
Recirculation Kit
For continuously circulating Throat Seal Liquid through enclosed wetcup on Check-Mate
®
MaxLife
Displacement Pump. For use with Single Supply and Tandem Supply Systems.
Part 255703
Important Safety Instructions
Read all warnings and instructions in this manual
and in your system operation and repair-parts
manuals. Save these instructions.
312494B
®
TI11914a
Advertisement
Table of Contents
Related Manuals for Graco 255703
Summary of Contents for Graco 255703
- Page 1 For continuously circulating Throat Seal Liquid through enclosed wetcup on Check-Mate ® MaxLife Displacement Pump. For use with Single Supply and Tandem Supply Systems. Part 255703 Important Safety Instructions Read all warnings and instructions in this manual and in your system operation and repair-parts manuals.
-
Page 2: Table Of Contents
Technical Specifications ..... 7 • Extended TSL life due to regular filter element Graco Standard Warranty ....8 cleaning or replacement. Graco Information . -
Page 3: Installation
Installation Installation Grounding 6. Remove 1/8 in. npt plug and fill port from wetcup cover. The equipment must be grounded. Grounding reduces the risk of static and electric shock by providing an escape wire for the electrical current due to static build up or in the event of a short circuit. - Page 4 Installation 10. Route fluid supply line (J) from diaphragm pump 12. Route fluid return line (H) from wetcup return line fit- fluid filter outlet (10) to recirculation fitting (20) on ting (4) to five-gallon metal pail (A). Use hole in pail displacement pump (L).
-
Page 5: Operation
Operation Operation Daily Inspection Perform the following inspections on a daily basis: First Time Operation • Check cycle/flow rate and adjust diaphragm pump 1. Fill five-gallon metal pail with 3 gallons (11.4 liters) air regulator (2) as needed. of Throat Seal Liquid (TSL) or a solvent that is com- patible with this kit and enclosed wetcup. -
Page 6: Parts
Parts Parts Ref. Part Description Qty. Ref. Part Description Qty. 235654 KIT, pail mount, 5 gallon 100615 BUSHING, hex; steel 246383 KIT, filter, 200 mesh 110147 REGULATOR, air; 1/4 npt & gauge 287902 KIT, filter cap 110223 VALVE, vented 2 way 117828 O-RING, PTFE encapsulated 110440 TEE, branch, male;... -
Page 7: Technical Specifications
Technical Specifications Technical Specifications Wetted parts ........303 and 304 grades of SST, Acetal, Anodized Aluminum, Brass, Buna-n, Nickel and Zinc plated Carbon Steel, Nylon, PTFE, Urethane, Zytel 312494B... -
Page 8: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
