- Page 1 FACTORY AUTOMATION QUICK START GUIDE ODT-HH-MAH120 HANDHELD...
- Page 2 ODT-HH-MAH120 With regard to the supply of products, the current issue of the following document is appli- cable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotech- nik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary...
-
Page 3: Table Of Contents
ODT-HH-MAH120 Installation and Commissioning........ 4 Connection....................4 1.1.1 Connection via USB ..................5 1.1.2 Connection via RS 232................6 1.1.3 Connection via PS/2 ..................7 Operating modes ..................8 1.2.1 USB operating modes .................8 1.2.2 RS232 operating modes................9 Positioning and reading techniques............11 Optimizing reading performance ............12... -
Page 4: Installation And Commissioning
ODT-HH-MAH120 Installation and Commissioning Installation and Commissioning Connection You have the opportunity to connect the handheld to the following PC interfaces: • • RS232 • PS/2 The handheld is ready for immediate use once you have connected it to the computer. -
Page 5: Connection Via Usb
ODT-HH-MAH120 Installation and Commissioning Press the 8-pin DIN plug, including spacer disk and protective cap, onto the socket. Use a srewdriver and the screws provided to fasten the protective cap onto the bottom of the handle. 1.1.1 Connection via USB Connecting USB connecting cable to computer Insert the USB plug of the connecting cable in a free USB port on your computer. -
Page 6: Connection Via Rs 232
ODT-HH-MAH120 Installation and Commissioning Further USB configuration options, see chapter 1.2.1. 1.1.2 Connection via RS 232 Connecting RS 232 connecting cable to computer Turn the computer off. Connect the RS 232 plug of the connecting cable to the RS 232 port of the computer. -
Page 7: Connection Via Ps/2
ODT-HH-MAH120 Installation and Commissioning 1.1.3 Connection via PS/2 Connecting PS/2 connecting cable to computer Turn the computer off. Disconnect the connection to the computer if an external keyboard is connected to the computer. If you are using a USB keyboard, connect the keyboard with an appropriate adapter to the PS/2 connecting jack of the connecting cable. -
Page 8: Operating Modes
ODT-HH-MAH120 Installation and Commissioning Operating modes 1.2.1 USB operating modes Changing USB operating modes There are 3 operating modes for USB operation of the handheld. To change the USB operating mode, scan the relevant code in the following table. USB Keyboard Mode Scan this code to transmit all the scanned data from the handheld to the computer. -
Page 9: Rs232 Operating Modes
ODT-HH-MAH120 Installation and Commissioning 1.2.2 RS232 operating modes Changing RS232 communication parameters Scan the respective code to change the individual RS 232 connection settings (view table "RS232 communication settings" on page 9). RS232 communication settings Setting data bit 7 data bits... - Page 10 ODT-HH-MAH120 Installation and Commissioning Setting parity Even None Scan this code to reset the handheld to the RS232 default settings:...
-
Page 11: Positioning And Reading Techniques
ODT-HH-MAH120 Installation and Commissioning Positioning and reading techniques This handheld uses digital camera technology to record an image of the code to be read. After an image has been recorded, the handheld uses highly developed evaluation procedures to evaluate the data contained in the recording. -
Page 12: Optimizing Reading Performance
ODT-HH-MAH120 Installation and Commissioning Optimizing reading performance With this handheld, you can improve the reading performance by specifying the size and information density of the codes that are to be scanned. If you typically tend to read a wide variety of codes, scan the Wide-Field DOT (Default) code. -
Page 13: Factory Defaults
ODT-HH-MAH120 Installation and Commissioning Factory defaults Resetting the handheld to factory defaults To reset the handheld to the factory defaults of the operating mode, scan the appropriate code. Operating mode Code RS232 PS/2... - Page 14 Twinsburg, Ohio 44087 · USA Tel. +1 330 4253555 E-mail: sales@us.pepperl-fuchs.com Asia Pacific Headquarters Pepperl+Fuchs Pte Ltd. Company Registration No. 199003130E Singapore 139942 Tel. +65 67799091 E-mail: sales@sg.pepperl-fuchs.com www.pepperl-fuchs.com Subject to modifications 910483 / TDOCT-1203_ENG Copyright PEPPERL+FUCHS • Printed in Germany 12/2007...
