King Tony 9TY145-004A-B Operation Manual

Transmission jack

Advertisement

9TY145-008A-B
NO.
THE CONSTRUCTION OF
TRANSMISSION JACK
Part
Description
Saddle
1
Ram
2
Cylinder
3
Hand Wheel
4
Foot Operated Pump
5
Wheel stand
6
Capacity: 0.8 Ton
Min. height :850mm
Max. height :1840mm
9TY145-015A-B
NO.
THE CONSTRUCTION OF
TRANSMISSION JACK
Part
Description
Saddle
1
Ram
2
Cylinder
3
Hand Wheel
4
Foot Operated Pump
5
Wheel stand
6
Capacity: 1.5 Ton
Min. height :1130mm
Max. height :1915mm
