- Page 1 HYDRAULIC GARAGE JACK OPERATION MANUAL 9TY133 Enjoy your work...
- Page 2 Capacity (T) Min height (mm) Max height (mm) 9TY133-25A-B READ ALL INSTRUCTIONS BEFORE USE • Study, understand, and follow all instructions before operating this device. • Failure to heed these markings may result in serious personal injury and / or property damage.
- Page 3 LUBRICATION AND CLEANING • Periodically clean and lubricate all moving parts and pivot points. AIR VENTING PROCEDURES • With the jack in the fully lowered position, unlock release valve, remove oil filler plug. • Pump the handle rapidly several mins. Reinstall oil filler plug. •...
- Page 4 PARTS LIST Part Description Part Description Screw Nut m16 Handle socket Cover plug Cylinder assembly Rear wheel assembly Spring Bolt m12x25 Linkage Back shaft Cotter pin Retaining ring Ø12 Retaining ring Ø25 Nut m12 Cover board Handle Linking pin Washer Lifting arm assembly Screw m6x10 Wall plate assembly...
